Summary of Contents for Rollei SD20
- Page 1 Exquisit Micro-SD Card...
-
Page 2: Table Of Contents
Contents Precautions .................1 Preface..................1 Product Certification ..............1 Product Overview ................1 Product Structure ................2 Functions&Features ..............3 Installation..................4 Operating Instructions..............4-5 Parameter Settings ..............6-7 Operations................8-12 File Storage And Play..............13 Adapter ..................14 Standard Accessories..............14 Optional Accessories ..............15 Specifi Cations & Parameters .............15 Fcc Notices................ -
Page 3: Precautions
5.If the camera overheats, smokes or smell in charging, please disconnect the power supply immediately to avoid the risk of fire. 6.Put the Rollei Bullet 3S 720P beyond the reach of any child for charging, as the power cord may cause anaccidental suffocation or electric shock to the child. -
Page 4: Product Structure
Product Structure (outline drawing) 19 20 21 (1).TFT display screen (2).MENU key (3).Up key (4).Left key (5).Down key (6).Recall key (7).OK key (8.)Push button of TFT display screen clip (9).Lanyard hole (10).Buzzer (11).SD Card slot (12).Right key (13).USB output interface (14).Record (15).Green indicator of video/voice recording (16).Power switch... -
Page 5: Functions&Features
>Supporting a Micro SD card of 32G max. (not included); >High-quality color fidelity, clearer and more realistic image; >It can remote control video recording, stopping and shooting of the Rollei Bullet 3S 720P by using wireless remote control; unique code pairing function, avoiding interference of other remote control;... -
Page 6: Installation
★Please clean with clear water as quickly as possible after using and dry out to avoid rusting. 2.Installation of remote control There is a separate remote control attached to the Rollei Bullet 3S 720P. Please install the remote control onto the correct position based on the accessories below:... - Page 7 E.It cannot respond to operations of "<" and ">" under the preview state; F. The Rollei Bullet 3S 720P can be charged with the attached power supply or USB cable. The “Red Indicator of Working/Charging” on the top of the machine will twinkle slowly in charging and it will be bright constantly after fully charging.
-
Page 8: Parameter Settings
Parameter Settings: In preview mode, press “M” key to enter the menu interface, press “<” or “>” key to move the cursor left and right, and press “+” or “-” key to move the cursor up and down. After selecting the menu, press “OK” key to set the selected menu and to press “M”... - Page 9 Select the auto standby time of 0, 2 minutes, 5 minutes or 10 minutes. In case of no any mission and operation after selecting, the system will start timing and the Rollei Bullet 3S 720P will turn off input and output to enter the standby mode at the end of the time set. If there is any operation in timing, the system will re-time.If the video recording or shutter is operated in the standby...
-
Page 10: Operations
1.Insert the Micro SD Card. Note: Please select class 6 Micro SD cards. 2.Turn the power switch to “ON” to turn on the camera. The red indicator will be lightened and the Rollei Bullet 3S 720P will enter the preview mode. Note: a.In case of low battery power, you will find the battery icon “... - Page 11 3s,5s,10s,20s,30s . Press “M” key to exit the setup interface after setting the interval time. Press “Shutter” at this time, and the Rollei Bullet 3S 720P will start shooting one photo every 2s, 3s,5s,10s, 20s,30s , till to press “Shutter” key again to stop.
- Page 12 a.Audio file Press “<” or “>” key to select an audio file, and to press “OK” key can play/stop it. In playing, you can press “+”key and “-” key to adjust the volume and press “ ” key to pause/ play the file. Note: No function of fast forward and fast rewind in audio file.
- Page 13 Note: a.Use wireless remote control to control your Rollei Bullet 3S 720P to check whether the code pairing was successful. The control functions include:Video recording starting/stopping, photo shooting, waking in standby mode, and laser light turning on/off; Camera will tick once for each operation. In case of video recording stopping or laser light turning off, the camera will tick twice;...
- Page 14 11.USB connection: a.When there is no preset battery in the Rollei Bullet 3S 720P, use USB power adapter. All functions will be available; b.In startup state, use USB cable to connect with the computer, data stored in the camera memory and the Micro SD card can be read (at this time, LCD segment screen will display the USB connection state icon);...
-
Page 15: File Storage And Play
File Storage and Play ①USB Cable You can copy or cut the recorded video files to your computer via the USB cable, or remove the Micro SD card and insert it into a card reader to read the video data. USB Port USB Port USB Cable... -
Page 16: Adapter
ADAPTER This product always conforms to the authenticated AC adapter. The adapter should be marked one of the following: Note:When using the power adapter, make sure the rating voltage on it is compatible with that of the device to avoid potential damages resulting from incorrect usage of power supply. Standard Accessories Main body TFT display... -
Page 17: Optional Accessories
Optional Accessories Portable power supply Portable power supply HDMI cable Accessory for soft plastic (2500mAH) (850mAH) flat installation Accessory for installation helmet accessory onto helmet top Specifications & Parameters View Angle 170° Battery 1000mAh Lithium Battery Video Recording Duration About 2.5h Voice Control Standby Duration About 250h Operating Temperature... -
Page 18: Fcc Notices
FCC Notices 1. The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications to this equipment. Such modifications could void the user's authority to operate the equipment. 2. This device complies with Part 15 of the FCC Rules. (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
