STAR-MAX GAS CHARBROILER
BARBECUE A GAZ STAR-MAX
8H-6015CBZ
8H-6036CBZ
8H-6015CBZS
8H-6036CBZS
8H-6115RCBZ
8H-6136RCBZ
Star
Manufacturing
International Inc.
10 Sunnen Drive
St. Louis, MO 63143
Phone: (314) 781-2777
Fax: (314) 781-3636
8H-6024CBZ
8H-6048CBZ
8H-6024CBZS
8H-6124RCBZS
8H-6124RCBZ
8H-6148RCBZ
1
Installation and
Operating Instructions
Instructions d'installation
et d'opération
2M-Z6390 Rev. -- 10/18/02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Star Manufacturing International 8H-6015CBZ
Summary of Contents for Star Manufacturing International 8H-6015CBZ
- Page 1 International Inc. Instructions d’installation 10 Sunnen Drive et d’opération St. Louis, MO 63143 Phone: (314) 781-2777 2M-Z6390 Rev. -- 10/18/02 Fax: (314) 781-3636 STAR-MAX GAS CHARBROILER BARBECUE A GAZ STAR-MAX 8H-6015CBZ 8H-6024CBZ 8H-6036CBZ 8H-6048CBZ 8H-6015CBZS 8H-6024CBZS 8H-6036CBZS 8H-6124RCBZS 8H-6115RCBZ 8H-6124RCBZ...
-
Page 2: Specifications
SPECIFICATIONS 8H-6015CBZ Type: Manual Control, Lava Rock 1 Control, 40,000* BTU, 300 sq. in. (1935 sq. cm) Grid Area Approximate weight: installed - 87 Lb (39.5 kg), shipping - 95 Lb, (43.2 kg) Dimensions: 15" - Width, 25-3/4" - Depth, 18-7/8" - Height (38.1 cm - Width, 65.4 cm - Depth, 48 cm - Height) - Page 3 8H-6136RCBZ Type: Manual Control, Radiant 3 Controls, 120,000* BTU, 720 sq. in. (4645 sq. cm) Grid Area Approximate weight: installed - 220 Lb (100 kg), shipping - 240 Lb, (109 kg) Dimensions: 36" - Width, 25-3/4" - Depth, 18-7/8" - Height (91.4 cm - Width, 65.4 cm - Depth, 48 cm - Height) 8H-6148RCBZ Type: Manual Control, Radiant...
-
Page 4: Safety Symbol
SAFETY SYMBOL This symbol is intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. -
Page 5: General Installation Data
GENERAL INSTALLATION DATA CAUTION For your safety, do not store or use gasoline or CAUTION other flammable vapors and liquids in the vicinity of this or any other appliance. Keep the This equipment is designed and sold for commercial appliance area clear and free from combustibles. use only by personnel trained and experienced in its operation and is not sold for consumer use in and For your protection, we recommend a qualified... -
Page 6: Gas Piping
CAUTION PROPANE GAS This charbroiler is equipped with fixed orifice hoods and is shipped from the factory for use with natural gas. DO NOT INSTALL WITHOUT ATTACHING To convert to propane gas, install the burner orifice FEET - DO NOT REMOVE FEET. hoods, located in the grease drawer, as follows: 1. - Page 7 SHUTTING DOWN INSTRUCTIONS LIGHTING Turn the burner valve knobs to the off position When broiler is first lit, it will smoke for approximately to turn burners off. 20-30 minutes until the preservation oils and impurities are burned off. PLACING LAVA ROCK ON GRATES Open the lava rock bags and place rock evenly on BROILING grates.
-
Page 9: Parts List
PARTS LIST EFFECTIVE 10/18/02 Updated 03-08-04 rb 8H-6015CBZ, 8H-6024CBZ, 8H-6036CBZ and 8H-6048CBZ Star-Max™ Gas Lava Rock Charbroiler-15", 24", 36", 48" MODEL Number Part Description Number Number Unit 2R-Z0934 (6015CBZ/6024CBZ/6036CBZ/6048CBZ) 1/2/3/4 KNOB-CONTROL H3-Z6333 (6015CBZ) FRONT PANEL H3-Z6332 (6024CBZ) FRONT PANEL H3-Z6334 (6036CBZ)
