Gladiator GACP15XXMG Dimensions

PRODUCT MODEL NUMBERS

GACP15XXMG
Electrical: 115-volt, 60-Hz, AC-only, 15- or
20-amp properly grounded circuit is required. A
time-delay fuse or circuit breaker and separate
circuit is recommended.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Garage Compactor

OVERALL DIMENSIONS

1
34 /
8
(86.7 cm)

CLEARANCE DIMENSIONS

"
24"
15"
(61 cm)
(38.1 cm)
without casters
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
38"
(96.5 cm)
15"
(38.1 cm)
with casters
1. Leave 6 in. (15.2 cm) of clearance
space to the right side of the
compactor in order to remove the
compactor bags.
2. Leave 23 in. (58.4 cm) of clearance
in front of the compactor in order to
fully open or remove the compactor
drawer.
24"
(61 cm)
Ref. 9871966
01-08-04
