GP2000H Series RS-232C Conversion Adapter
(GP2000H-AP232)
Installation Guide
Thank you for purchasing Pro-face's GP2000H Series RS-232C type Conversion
Adapter, hereafter referred to as the "Adapter"
Using this adapter allows the user to convert the GP2000H series I/F connector to a
terminal block.
Please confirm that the following items are all included in the adapter's package.
• Installation Guide (This manual)
• GP2000H RS-232C type Conversion Adapter
Prior to using this adapter, please be sure to read this manual Completely.
UL/c-UL(CSA) Approval
The GP2000H-AP232 are UL60950 approved product (UL file no. E171486) that can
be easily built into your product. When applying for UL approval for a product that
includes one of this Adapter, please be sure to pay special attention to the fact that all
products with built-in Adapter require UL inspection of the combination of the
Adapter and the product.
The Adapter components conform to the following standards:
UL60950 Third Edition, dated December 1, 2000 (Standard for Safety of Information
Technology Equipment, including Electrical Business Equipment)
CAN/CSA-C22.2 No. 60950-00 (Standard for Safety of Information Technology
Equipment, including Electrical Business Equipment)
GP2000H-AP232 (UL Registration Model: 3080028-21)
CE Marking
The GP2000H-AP232 is CE marked , EMC compliant products. This Adapter also
conform to EN55011 Class A, EN61000-6-2 directives.
For detailed CE marking information, please contact your local Adapter distributor.
- 1 -
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pro-face GP2000H-AP232
Summary of Contents for Pro-face GP2000H-AP232
- Page 1 Prior to using this adapter, please be sure to read this manual Completely. UL/c-UL(CSA) Approval The GP2000H-AP232 are UL60950 approved product (UL file no. E171486) that can be easily built into your product. When applying for UL approval for a product that...
- Page 2 <Cable Connection Information> Dsub 37 pin Connector: This connector connects to GP2000H series units. Use the separately sold RS-232C option cable (GP2000H-D232-3M or GP2000H-D232-10M) to connect the two. Dsub 25 pin Connector: This connector connects to the Host (Device/PLC). Use the separately sold RS-232C cable (GP410-IS00-O) to connect the two.
- Page 3 <Recommended Installation Method> Be sure to install the Conversion adapter from inside the panel. Use stud bolts 14mm [0.55in.] or longer, and secure them in place using M3 nuts. The necessary torque is 0.5 to 0.6 N•m. The drawing shown here is with the recommended connector and cover in place.
- Page 4 • The necessary torque is 0.5 to 0.6N•m. <Serial Interface> • The connector signals used in this document are based on the use of Pro-face's optional RS-232C cable. (GP2000H-D232-3M or GP2000H-D232-10M) For detailed signal information, please refer to the separately sold GP2000H Series User Manual.
- Page 5 Dsub 37 pin socket-type connector (connect the GP2000H) Pin No. Signal Name Description Frame Ground Frame Ground Enable to Receive Not Connected Not Connected DC +5V±5% Output 0.25A (from GP2000H) Carrier Detect Receive Data Not Connected RESERVE Reserved RESERVE Reserved OP.GND OP Ground DOUT.GND...
- Page 6 The DOUT ground is used in common with External Buzzer Output (BUZZ OUT), DOUT 0 (Zero) output (DOUT0.C), and DOUT 1 (One) output (DOUT1.C). Disabled when “GP-H70 compatible mode” (set via GP2000H) is used. Recommended Connector: Dsub 37 pin plug XM2A-3701<made by OMRON Corp.> Recommended Cover: Dsub 37 pin Cover XM2S-3711<made by OMRON Corp.>...
- Page 7 22-Line Terminal Block Pin No. Signal Name (Drawing Name) Description DOUT0.C (DO0) DOUT 0 Output RESERVE Reserved DOUT1.C (DO1) DOUT 1 Output RESERVE Reserved OP.C (OP) OP Output OP.GND (OPG) OP Ground BUZZ OUT (BZ) External Buzzer Output DOUT.GND (DOG) DOUT Ground EMG0A (EM0A)
- Page 8 Digital Electronics Corporation 8-2-52 Nanko Higashi, Suminoe-ku, Osaka 559-0031, Japan URL: http://www.pro-face.com/ © 2002 Digital Electronics Corporation. All rights reserved. GP2000H-AP232-MT01-CP 2002.7 B - 8 -...
