EZ LAN Adapter
Installation Guide
This product is a conversion adapter that
attaches to the USB (Type A) interface on the
display unit so you can use it as an Ethernet
Interface. This product supports GP 4000 Series
and GP4000R Series (both are UL-certified).

Safety Precautions

If the equipment is used in a manner not
specified by the manufacturer, the protection
provided by the equipment may be impaired.
DANGER
POTENTIAL FOR EXPLOSION
Suitable for use in Class I, Division 2,
Groups A, B, C, D or non-hazardous
locations only.
Substitution of any components may impair
suitability for Class I, Division 2.
Do not connect or disconnect this product
unless power has been switched off or the
area is known to be non-hazardous.
Failure to follow these instructions will result
in death or serious injury.
HAZARD OF ELECTRIC SHOCK OR
EXPLOSION
Do not disassemble or remodel this product
in any way. Doing so may cause an electric
shock or fire.
Do not use this product in areas where
flammable gases are present. Doing so may
cause an explosion.
Do not allow water to enter the connector. Do
not touch the connector with wet hands.
Doing so may cause an electric shock.
Failure to follow these instructions will result
in death or serious injury.
The information in this document is subject to change without notice.
Copyright © 2017.6 Digital Electronics Corporation. All Rights Reserved.
QGH29096 02
Digital Electronics Corporation
Schneider Electric Osaka Building,
4-4-9 Kitahama,Chuo-ku, Osaka 541-0041 JAPAN
http://www.pro-face.com/
DANGER
Printed in
UNINTENDED EQUIPMENT OPERATION OR
LOSS OF CONTROL
Do not use or store this product at
temperatures outside the range specified in
this guide.
Do not use or store this product in direct
sunlight or excessively dusty or dirty
environments.
Do not use or store this product in an
environment where it may be exposed to
chemical vapors or fumes.
Failure to follow these instructions can result
in death, serious injury, or equipment damage.
LOSS OF COMMUNICATION
Do not connect or disconnect this product during
communication. Doing so may cause a communi-
cation error.
Failure to follow these instructions can result
in equipment damage.
NOTE: When disposing of this product, follow
your country's regulations for similar types of
industrial waste.

Package Contents

(1) EZ LAN Adapter (PFXZCGEUUE1) x 1
(2) Attachment screws (M3) x 2
(3) Installation guide (this document)
This product has been carefully packed with
special attention to quality. However, should you
find anything damaged or missing, please
contact your local distributor.
1
WARNING
NOTICE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFXZCGEUUE1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Pro-face PFXZCGEUUE1

  • Page 1 Failure to follow these instructions will result in death or serious injury. Package Contents DANGER (1) EZ LAN Adapter (PFXZCGEUUE1) x 1 (2) Attachment screws (M3) x 2 HAZARD OF ELECTRIC SHOCK OR (3) Installation guide (this document) EXPLOSION This product has been carefully packed with •...
  • Page 2 General Specifications  General Specifications Modular jack (RJ-45), IEEE802.3i/IEEE802.3u, Ethernet I/F 10BASE-T/100BASE-TX Connector type USB I/F Type A (plug), USB 2.0 High-Speed (480 Mbps)  Electrical Specifications Rated input voltage 5 Vdc (powered from USB bus) Input voltage limits 4.75...5.25 Vdc Power consumption 0.63 W or less ...
  • Page 3: Ethernet Interface

    Interface  Ethernet Interface Pin Arrangement Pin # Signal Name Meaning Output Send Data (+) Output Send Data (-) Input Receive Data (+) Active Link No connection No connection Input Receive Data (-) No connection No connection Shell Functional Ground (common with NOTE: •...
  • Page 4 Dimensions 4.13 1.06 19.68 1 Ethernet Interface (Device/PLC side) 2 USB Connector (display unit side) Attachment Method NOTE: Attach this product to the panel when the display unit does not have screw holes on its rear side as shown in the image below. ...
  • Page 5 1) Using a Phillips screwdriver, attach one screw • Make sure this product is placed inside the (M3) to the display unit’s rear side. Use a torque edges of the display unit. of 0.5 N•m (4.4 lb-in). Correct Rear face of Display 2) Attach this product to the display unit.
  • Page 6 You can access our support site whenever a strong acid compound to clean the unit. you need help with a solution. Failure to follow these instructions can result http://www.pro-face.com/trans/en/manual/ in equipment damage. 1001.html When this product gets dirty, soak a soft cloth in water with a neutral detergent, wring the cloth tightly and wipe this product.
