Pro-face GP2000H Series Installation Manual

GP2000H Series Special Purpose
for GP-H70 Conversion Adapter
(GP2000H-AP70CB-D232-3M)
Thank you for purchasing Pro-face's GP2000H Series Special Purpose RS-232C Cable
for GP-H70 Conversion Adapter, hereafter referred to as the "cable"
This product is designed to provide an RS-232C type connection to the GP-H70 Series
RS-232C Conversion Adapter.
Please confirm that the following items are included in the cable's package.
• Installation Guide (This manual)
• GP2000H Series Special Purpose RS-232C Cable for GP-H70 Conversion Adapter
(length: 3m [9.84ft.])
Prior to using this cable, please be sure to read this manual completely.
• Prior to connecting the cable, check that the GP2000H's power supply is
completely turned OFF to prevent an electric shock.
• Do not modify the cable, since it may lead to a fire or electric shock.
• This cable is not appropriate for use with aircraft control devices, aero-
space equipment, central trunk data transmission (communication) de-
vices, nuclear power control devices, or medical life support equipment,
due to these devices inherent requirements of extremely high levels of
safety and reliability.
• When using this cable with transportation vehicles (trains, cars and ships),
disaster and crime prevention devices, various types of safety equip-
ment, non-life support related medical devices, etc. redundant and/or
failsafe system designs should be used to ensure the proper degree of
reliability and safety.
RS-232C Cable
Installation Guide

Safety Precautions

WARNINGS
- 1 -
