GA-K8A480M-9
AMD Socket 939 Processor Motherboard
User's Manual
Rev. 1002
12ME-K8A480M9-1002
This product must not be disposed of with your other household waste and must be handed over
to a designated collection point for the recycling of waste electrical and electronic equipment !

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GA-K8A480M-9 and is the answer not in the manual?

Questions and answers

Related Manuals for Gigabyte GA-K8A480M-9

Summary of Contents for Gigabyte GA-K8A480M-9

  • Page 1 GA-K8A480M-9 AMD Socket 939 Processor Motherboard User's Manual Rev. 1002 12ME-K8A480M9-1002 This product must not be disposed of with your other household waste and must be handed over to a designated collection point for the recycling of waste electrical and electronic equipment !
  • Page 3 Gigabyte's prior written permission. Specifications and features are subject to change without prior notice. Product Manual Classification In order to assist in the use of this product, Gigabyte has categorized the user manual in the following: For quick installation, please refer to the "Hardware Installation Guide" included with the product.

  • Page 4: Table Of Contents

    Table of Contents GA-K8A480M-9 Motherboard Layout ... 6 Block Diagram ... 7 Chapter 1 Hardware Installation ... 9 Considerations Prior to Installation ... 9 Feature Summary ... 10 Installation of the CPU and Fan Heat Sink ... 12 1-3-1 Installation of the CPU ... 12 1-3-2 Installation of the Fan Heat Sink ...
  • Page 5 Chapter 3 Drivers Installation ... 43 Install Chipset Drivers ... 43 Software Application ... 44 Software Information ... 44 Hardware Information ... 45 Contact Us ... 45 Chapter 4 Appendix ... 47 Unique Software Utilities ... 47 4-1-1 EasyTune 5 Introduction ... 47 4-1-2 Xpress Recovery Introduction ...

  • Page 6: Ga-K8A480M-9 Motherboard Layout

    GA-K8A480M-9 Motherboard Layout KB_MS ATX_12V Socket 939 AUDIO1 AZALIA_FP AUDIO2 PCIE_16_1 RTL8110S CD_IN CODEC COMB SPDIF_IO CPU_FAN ATi RS480 CLR_CMOS PCIE_1 BIOS PCI1 PCI2 SYS_FAN - 6 - IDE1 IDE2 ULi M1573 F_USB1 F_PANEL F_USB2 SATA3 SATA2 SATA1 SATA0...

  • Page 7: Block Diagram

    Block Diagram PCI-ECLK (100MHz) PCI Express x16 1 PCI Express x 1 Port PCI-ECLK (100MHz) PCI Express x1 Bus PCI Bus 8110S RJ45 2 PCI PCICLK (33MHz) CPUCLK+/-(200MHz) AMD K8 Socket 939 Host Interface SBLINK_CLK P/N (100MHz) NBSRC_CLK P/N (100MHz) NB_OSC (14.318MHz) RS480 66MHz...
  • Page 8 - 8 -...

  • Page 9: Chapter 1 Hardware Installation

    2. Damage as a result of violating the conditions recommended in the user manual. 3. Damage due to improper installation. 4. Damage due to use of uncertified components. 5. Damage due to use exceeding the permitted parameters. 6. Product determined to be an unofficial Gigabyte product. - 9 - Hardware Installation...

  • Page 10: Feature Summary

    For example, 4 GB of memory size will instead be shown as 3.xxGB memory during system startup. GA-K8A480M-9 Motherboard 64 / 64 FX processor (K8) - 10 -...
  • Page 11 Hardware Monitor System voltage detection CPU temperature detection CPU / System fan speed detection CPU warning temperature CPU / System fan failure warning CPU smart fan control Onboard SATA RAID Onboard ULi M1573 chipset supports data striping (RAID 0) or mirroring (RAID 1) function or striping + mirroring (RAID 0+1) or JBOD function supports data transfer rate of up to 150 MB/s supports hot plugging function...

  • Page 12: Installation Of The Cpu And Fan Heat Sink

    CPU and gently press the metal lever back into its original position. Please use extra care when installing the CPU. The CPU will not fit if positioned incorrectly. Rather than applying force, please change the positioning of the CPU. GA-K8A480M-9 Motherboard - 12 -...

  • Page 13: Installation Of The Fan Heat Sink

    1-3-2 Installation of the Fan Heat Sink Fig.1 Before installing the heat sink, please first add an even layer of heat sink paste on the surface of the CPU. Install all the heat sink components (Please refer to the heat sink manual for detailed installation instructions). Fig.2 Please connect the heat sink power connector to the CPU_FAN connector located on the motherboard so that the heat sink can properly function to...

  • Page 14: Installation Of Memory

    DIMM socket. Then push it down. Fig.2 Close the plastic clip at both edges of the DIMM sockets to lock the DIMM module. Reverse the installation steps when you wish to remove the DIMM module. GA-K8A480M-9 Motherboard - 14 - Notch...
  • Page 15 Dual Channel Memory Configuration The GA-K8A480M-9 supports the Dual Channel Technology. When the Dual Channel Technology is activated, the bandwidth of memory bus will be double the original one. Due to CPU limitation, if you want to operate the Dual Channel Technology, please follow the guidelines below for Dual Channel memory configuration.

  • Page 16: Installation Of Expansion Cards

    Power on the computer, if necessary, setup BIOS utility of expansion card from BIOS. Install related driver from the operating system. Installing a PCI Express x 16 expansion card: GA-K8A480M-9 Motherboard Please carefully pull out the small white- drawable bar at the end of the PCI Express x 16 slot when you try to install/uninstall the VGA card.

  • Page 17: I/O Back Panel Introduction

    I/O Back Panel Introduction PS/2 Keyboard and PS/2 Mouse Connector To install a PS/2 port keyboard and mouse, plug the mouse to the upper port (green) and the keyboard to the lower port (purple). Parallel Port The parallel port allows connection of a printer, scanner and other peripheral devices. COM A (Serial Port) Connects to serial-based mouse or data processing devices.

  • Page 18: Connectors Introduction

    1) ATX_12V 2) ATX (Power Connector) 3) CPU_FAN 4) SYS_FAN 5) FDD 6) IDE1 / IDE2 7) SATA0/ATA1/SATA2/SATA3 8) F_PANEL GA-K8A480M-9 Motherboard 13 4 9) AZALIA_FP 10) CD_IN 11) SPDIF_IO 12) F_USB1 / F_USB2 13) COMB 14) C I 15) CLR_CMOS...
  • Page 19 1/2) ATX_12V/ATX (Power Connector) With the use of the power connector, the power supply can supply enough stable power to all the components on the motherboard. Before connecting the power connector, please make sure that all components and devices are properly installed. Align the power connector with its proper location on the motherboard and connect tightly.
  • Page 20 The FDD connector is used to connect the FDD cable while the other end of the cable connects to the FDD drive. The types of FDD drives supported are: 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB. Please connect the red power connector wire to the pin1 position. GA-K8A480M-9 Motherboard Pin No. Definition...
  • Page 21 6) IDE1 / IDE2 (IDE Connector) An IDE device connects to the computer via an IDE connector. One IDE connector can connect to one IDE cable, and the single IDE cable can then connect to two IDE devices (hard drive or optical drive). If you wish to connect two IDE devices, please set the jumper on one IDE device as Master and the other as Slave (for information on settings, please refer to the instructions located on the IDE device).

  • Page 22: F_Panel (Front Panel Jumper)

    F_PANEL connector according to the pin assignment below. HD (IDE Hard Disk Active LED) SPEAK (Speaker Connector) RES (Reset Switch) PW (Power Switch) MSG(Message LED/Power/Sleep LED) GA-K8A480M-9 Motherboard Speaker Connector Message LED/ Power Power/ Switch Sleep LED...
  • Page 23 9) AZALIA_FP (Front Audio Panel Connector) This connector is supported to connect HD(High Definition) Audio and AC'97 Audio. Check the pin assignment carefully while you connect the audio panel cable, incorrect connection between the cable and connector will make the device unable to work or even damage it. For optional audio panel cable, please contact your local dealer.
  • Page 24 USB cable, incorrect connection between the cable and connector will make the device unable to work or even damage it. For optional front USB cable, please contact your local dealer. GA-K8A480M-9 Motherboard Pin No. Definition Power...
  • Page 25 13) COMB (Serial Port Connector) Be careful with the polarity of the COM connector. Check the pin assignment carefully while you connect the COM cable, incorrect connection between the cable and connector will make the device unable to work or even damage it. For optional COM cable, please contact your local dealer.
  • Page 26 You may clear the CMOS data to its default values by this jumper. To clear CMOS, temporarily short 1-2 pin. Default doesn't include the "Shunter" to prevent from improper use this jumper. 16) BAT(Battery) GA-K8A480M-9 Motherboard Open: Normal Short: Clear CMOS Danger of explosion if battery is incorrectly replaced.

  • Page 27: Chapter 2 Bios Setup

    BIOS needs to be reset to its original settings. If you wish to upgrade to a new BIOS, either Gigabyte's Q-Flash or @BIOS utility can be used. Q-Flash allows the user to quickly and easily update or backup BIOS without entering the operating system.

  • Page 28: The Main Menu (For Example: Bios Ver. : D6)

    Optimized Defaults indicates the value of the system parameters which the system would be in best performance configuration. Set Supervisor Password Change, set, or disable password. It allows you to limit access to the system and Setup, or just to Setup. GA-K8A480M-9 Motherboard Load Fail-Safe Defaults Load Optimized Defaults Set Supervisor Password Set User Password Save &...

  • Page 29: Standard Cmos Features

    Set User Password Change, set, or disable password. It allows you to limit access to the system. Save & Exit Setup Save CMOS value settings to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup. Standard CMOS Features CMOS Setup Utility-Copyright (C) 1984-2005 Award Software Date (mm:dd:yy)
  • Page 30 The BIOS determines how much extended memory is present during the POST. This is the amount of memory located above 1 MB in the CPU's memory address map. Total Memory This item displays the memory size that used. GA-K8A480M-9 Motherboard - 30 -...

  • Page 31: Advanced Bios Features

    Advanced BIOS Features CMOS Setup Utility-Copyright (C) 1984-2005 Award Software Hard Disk Boot Priority First Boot Device Second Boot Device Third Boot Device Password Check : Move Enter: Select F5: Previous Values Hard Disk Boot Priority Select boot sequence for onboard(or add-on cards) SCSI, RAID, etc. Use <...

  • Page 32: Integrated Peripherals

    Enable onboard 2nd channel IDE port. (Default value) Disabled Disable onboard 2nd channel IDE port. On-Chip USB 1.1 Controller Enabled Enable USB 1.1 controller. (Default value) Disabled Disable USB 1.1 controller. GA-K8A480M-9 Motherboard Integrated Peripherals [Enabled] [HD Audio] [Enabled] [Enabled] [Enabled] [Enabled]...
  • Page 33 USB Keyboard Support Enabled Enable USB Keyboard Support. Disabled Disable USB Keyboard Support. (Default value) USB Mouse Support Enabled Enable USB Mouse Support. Disabled Disable USB Mouse Support. (Default value) On-Chip USB 2.0 Controller Disable this function if you are not using onboard USB 2.0 feature. Enabled Enable USB 2.0 Controller.

  • Page 34: Power Management Setup

    LAN can awake the system from any suspend state. Disabled Disable Modem Ring on/wake on Lan function. (Default value) Enabled Enable Modem Ring on/wake on Lan. GA-K8A480M-9 Motherboard Power Management Setup [S1(POS)] [Blinking] [Instant-off]...
  • Page 35 USB Dev WakeUp You can enable this function when ACPI Suspend Type set to S3(STR). Disabled Disable this function. Enabled Enable USB device can wakeup system from S3. (Default value) Resume by Alarm You can set "Resume by Alarm" item to enabled and key in Date/time to power on system. Disabled Disable this function.

  • Page 36: Pnp/Pci Configurations

    : Move Enter: Select F5: Previous Values PCI 1 IRQ Assignment Auto 3,4,5,7,9,10,11,12,14,15 PCI 2 IRQ Assignment Auto 3,4,5,7,9,10,11,12,14,15 GA-K8A480M-9 Motherboard PnP/PCI Configurations [Auto] [Auto] +/-/PU/PD: Value F10: Save ESC: Exit F6: Fail-Safe Defaults F7: Optimized Defaults Auto assign IRQ to PCI 1. (Default value) Set IRQ 3,4,5,7,9,10,11,12,14,15 to PCI 1.

  • Page 37: Pc Health Status

    PC Health Status CMOS Setup Utility-Copyright (C) 1984-2005 Award Software Reset Case Open Status Case Opened Vcore DDR25V +3.3V +12V Current CPU Temperature Current CPU FAN Speed Current SYSTEM FAN Speed CPU Warning Temperature CPU FAN Fail Warning SYSTEM FAN Fail Warning CPU Smart FAN Control : Move Enter: Select...

  • Page 38: Mb Intelligent Tweaker(M.i.t.)

    The option will display "Locked" and read only if the CPU ratio is not changeable. Auto Detect PCI Clk Enabled Detect PCI clock automatically. (Default value) Disabled Disable this function. GA-K8A480M-9 Motherboard Frequency/Voltage Control [Default] [Enabled] +/-/PU/PD: Value F10: Save...

  • Page 39: Load Fail-Safe Defaults

    Load Fail-Safe Defaults CMOS Setup Utility-Copyright (C) 1984-2005 Award Software Standard CMOS Features Advanced BIOS Features Integrated Peripherals Power Management Setup PnP/PCI Configurations PC Health Status MB Intelligent Tweaker(M.I.T.) ESC: Quit F8: Q-Flash Fail-Safe defaults contain the most appropriate values of the system parameters that allow minimum system performance.

  • Page 40: Set Supervisor/User Password

    Setup Menu. If you select "Setup" at "Password Check" in Advance BIOS Features Menu, you will be prompted only when you try to enter Setup. GA-K8A480M-9 Motherboard Load Fail-Safe Defaults Load Optimized Defaults...

  • Page 41: Save & Exit Setup

    2-11 Save & Exit Setup CMOS Setup Utility-Copyright (C) 1984-2005 Award Software Standard CMOS Features Advanced BIOS Features Integrated Peripherals Power Management Setup PnP/PCI Configurations PC Health Status MB Intelligent Tweaker(M.I.T.) ESC: Quit F8: Q-Flash Type "Y" will quit the Setup Utility and save the user setup value to RTC CMOS. Type "N"...
  • Page 42 GA-K8A480M-9 Motherboard - 42 -...

  • Page 43: Chapter 3 Drivers Installation

    Chapter 3 Drivers Installation Pictures below are shown in Windows XP. Insert the driver CD-title that came with your motherboard into your CD-ROM drive, the driver CD-title will auto start and show the installation guide. If not, please double click the CD-ROM device icon in "My computer", and execute the Setup.exe.

  • Page 44: Software Application

    Software Application This page displays all the tools that Gigabyte developed and some free software. You can click an item to install it. Software Information This page lists the contents of software and drivers in this CD-title. GA-K8A480M-9 Motherboard - 44 -...

  • Page 45: Hardware Information

    Hardware Information This page lists all device you have for this motherboard. Contact Us Please see the last page for details. - 45 - Drivers Installation...
  • Page 46 GA-K8A480M-9 Motherboard - 46 -...

  • Page 47: Chapter 4 Appendix

    Enters the PC Health setting page Confirmation and Execution button Toggles between Easy and Advance Mode Display panel of CPU frequency Shows the current functions status Log on to GIGABYTE website Display EasyTune 5 Help file Quit or Minimize EasyTune 5 software...

  • Page 48: Xpress Recovery Introduction

    Once you have completed this step, subsequent access to Xpress Recovery can also function by pressing the F9 key during computer power on. Verifying DMI Pool Data Boot from CD: Xpress Recovery V1.0 (C) Copy Right 2003. GIGABYTE Technology CO. , Ltd. 1. Execute Backup Utility 2. Execute Restore Utility 3. Remove Backup Image 4.
  • Page 49 Press DEL to enter SETUP / Q-Flash, F9 For Xpress Recovery 08/16/2002-I845GE-6A69YG01C-00 Xpress Recovery V1.0 (C) Copy Right 2003. GIGABYTE Technology CO. , Ltd. If you have already entered Xpress Recovery by booting from the CD-ROM, you can enter Xpress Recovery in the future by pressing the F9 key.
  • Page 50 If you wish to remove the need for password entry, please select "Set Password" and under "New Password/Confirm Password", make sure there is no entry and then press "Enter" to remove password requirement. 5. Exit and Restart: Exit and restart your computer. GA-K8A480M-9 Motherboard - 50 -...

  • Page 51: Flash Bios Method Introduction

    Updating BIOS with Q-Flash Utility on Dual BIOS Motherboards. Some of Gigabyte motherboards are equipped with dual BIOS. In the BIOS menu of the motherboards supporting Q-Flash and Dual BIOS, the Q-Flash utility and Dual BIOS utility are combined in the same screen.
  • Page 52 Action bar: Contains the names of four actions needed to operate the Q-Flash/Dual BIOS utility. Pressing the buttons mentioned on your keyboards to perform these actions. GA-K8A480M-9 Motherboard Select Language Load Fail-Safe Defaults Load Optimized Defaults...
  • Page 53 Using the Q-Flash utility: This section tells you how to update BIOS using the Q-Flash utility. As described in the "Before you begin" section above, you must prepare a floppy disk having the BIOS file for your motherboard and insert it to your computer.
  • Page 54 Primary Slave : None Secondary Master : CREATIVEDVD-RM DVD1242E BC101 Secondary Slave : None Press DEL to enter SETUP / Dual BIOS / Q-Flash / F9 For Xpress Recovery 09/23/2003-i875P-6A79BG03C-00 GA-K8A480M-9 Motherboard Dual BIOS Utility Main Bios Disable Boot From Main Bios...

  • Page 55: Updating Bios With Q-Flash Utility On Single-Bios Motherboards

    Press Y on your keyboard to save and exit. Part Two: Updating BIOS with Q-Flash Utility on Single-BIOS Motherboards. This part guides users of single-BIOS motherboards how to update BIOS using the Q-Flash CMOS Setup Utility-Copyright (C) 1984-2004 Award Software Standard CMOS Features Advanced BIOS Features...
  • Page 56 After BIOS file is read, you'll see a confirmation dialog box asking you "Are you sure to update BIOS?" Please do not take out the floppy disk when it begins flashing BIOS. GA-K8A480M-9 Motherboard Q-Flash Utility V1.30 Keep DMI Data...
  • Page 57 Press Y button on your keyboard after you are sure to update BIOS. Then it will begin to update BIOS. The progress of updating BIOS will be shown at the same time. Flash Type/Size...SST 49LF003A >>>>>>>>>>>>>>>>>>>... Enter : Run Don't Turn Off Power or Reset System Press any keys to return to the Q-Flash menu when the BIOS updating procedure is completed.
  • Page 58 Please search for BIOS unzip file, downloading from internet or any other methods (such as: K8A480M-9.D6). Complete update process following the instruction. GA-K8A480M-9 Motherboard Utility Fig 2. Installation Complete and Run @BIOS Click Sart/ Programs/ GIGABYTE/@BIOS Fig 4. Select the desired @BIOS server - 58 -...
  • Page 59 III. In method I, if the BIOS file you need cannot be found in @BIOSTM server, please go onto Gigabyte's web site for downloading and updating it according to method II. IV. Please note that any interruption during updating will cause system unbooted...

  • Page 60: Serial Ata Bios Setting Utility Introduction

    Spanning stores data onto a drive until it is full, then proceeds to store files onto the next drive in the array. When any disk member fails, the failure affects the entire array. JBOD is not really a RAID and does not support fault tolerance. GA-K8A480M-9 Motherboard - 60 -...
  • Page 61 6) Complete RAID utility installation. More information on steps 4 and 5 is provided. (For more detailed setup information, please visit "Support\ Motherboard\ Technology Guide section" on our website at http:\\www.gigabyte.com.tw to read or download the information you need.) Configuring the ALi RAID BIOS The ULi RAID BIOS setup utility lets you choose the RAID array type and which hard drives you want to make part of the array.
  • Page 62 Press Y, and then some necessary information will be written to the drives, which will destroy the original data in the drives. Make sure the data in drives is no longer in use before creating RAID 0. GA-K8A480M-9 Motherboard www.uli.com.tw SPACE:...
  • Page 63 Next, the Array Name input line appears for the user to key in a name for the newly created array. The effective characters for an array name is 0-9, A-Z, a-z, space and underscore. RAID BIOS Setup Utility (c) 2005 ULi Electronics Inc. Create RAID 0 Striping for Performance Create RAID 1 Mirroring for Reliability Create RAID 0+1 for Striping, Mirroring...
  • Page 64 Press Y, and then some necessary information will be written to the drives, which will destroy the original data in the drives. It is recommended to use new drives to create RAID 1. If existing drive is to be used, backup all necessary data before creating RAID 1. GA-K8A480M-9 Motherboard www.uli.com.tw SPACE: Select...
  • Page 65 Next, the Array Name input line appears for the user to key in a name for the newly created array. The effective characters for an array name is 0-9, A-Z, a-z, space and underscore. Lastly a prompt message "Duplicate Data from M to m (Y/N)?" asks whether to do drive copy. The source and target drives are indicated by "M"...
  • Page 66 Channel 1 Master : ST3120026AS Channel 2 Master : HDS722512VLSA80 Channel 3 Master : HDS722512VLSA80 Capacity RAID Array A : RAID Array B : RAID Array C : GA-K8A480M-9 Motherboard www.uli.com.tw SPACE: Select Moving Cursor Enter : Select & Finish...
  • Page 67 After the RAID array has been created successfully, its information shows up at RAID Array List. RAID BIOS Setup Utility (c) 2005 ULi Electronics Inc. Create RAID 0 Striping for Performance Create RAID 1 Mirroring for Reliability Create RAID 0+1 for Striping, Mirroring Create JBOD for integrated Capacity Stripe Size Delete RAID Settings &...
  • Page 68 "M" and "m" in Drive Select Menu respectively. Press Y to start the rebuild process and data duplication. The process status bar shows up during the duplication process. After configuration of RAID Array, press ESC to exit ULi RAID BIOS setup utility. GA-K8A480M-9 Motherboard - 68 -...

  • Page 69: Installing The Raid Drivers

    Installing the RAID drivers To install Windows 2000/XP onto a Serial ATA hard disk sucessfully, you need to install required driver for the SATA controller on your motherboard during OS installation. Without the driver, the hard disk may not be recognized during the Windows setup process.

  • Page 70: 4- / 6- / 8- Channel Audio Function Introduction

    Click the icon to select the function. GA-K8A480M-9 Motherboard 4-1-5 2- / 4- / 6- / 8- Channel Audio Function Introduction This motherboard provide 6 audio connector. You are able to use 2-/ 4-/6-/8-channnels audio feature by audio software selection.
  • Page 71 STEP 3: Click "Speaker Configuration" then click on the left selection bar and select "2CH Speaker" to complete 2 channel audio configuration. 4 Channel Audio Setup STEP 1 : Connect the front channels to "Front Speaker Out", the rear channels to "Rear Speaker Out". STEP 2 : Following installation of the audio driver, you find a Sound Effect...
  • Page 72 Click the icon to select the function. STEP 3: Click "Speaker Configuration" then click on the left selection bar and select "6CH Speaker" to complete 6 channel audio configuration. GA-K8A480M-9 Motherboard - 72 - Front Speaker Out Rear Speaker Out Center/Subwoofer...
  • Page 73 8 Channel Audio Setup STEP 1 : Connect the front channels to "Front Speaker Out", the rear channels to "Rear Speaker Out", the Center/ Subwoofer channels to "Center/Subwoofer Speaker Out", and the side channels to "Side Speaker Out". STEP 2 : Following installation of the audio driver, you find a Sound Effect icon on the lower right hand taskbar.

  • Page 74: Troubleshooting

    Below is a collection of general asked questions. To check general asked questions based on a specific motherboard model, please log on to http://www.gigabyte.com.tw Question 1: I cannot see some options that were included in previous BIOS after updating BIOS. Why? Answer: Some advanced options are hidden in new BIOS version.
  • Page 75 - 75 - Appendix...
  • Page 76 GA-K8A480M-9 Motherboard - 76 -...
  • Page 77 - 77 - Appendix...
  • Page 78 GA-K8A480M-9 Motherboard - 78 -...
  • Page 79 Address: No.6, Bau Chiang Road, Hsin-Tien, Taipei 231, Taiwan TEL: +886-2-8912-4888 FAX: +886-2-8912-4003 Tech. Support : http://tw.giga-byte.com/TechSupport/ServiceCenter.htm Non-Tech. Support(Sales/Marketing) : http://ggts.gigabyte.com.tw/nontech.asp WEB address (English): http://www.gigabyte.com.tw WEB address (Chinese): http://chinese.giga-byte.com U.S.A. G.B.T. INC. TEL: +1-626-854-9338 FAX: +1-626-854-9339 Tech. Support : http://tw.giga-byte.com/TechSupport/ServiceCenter.htm Non-Tech.
  • Page 80 China NINGBO G.B.T. TECH. TRADING CO., LTD. Tech. Support : http://tw.giga-byte.com/TechSupport/ServiceCenter.htm Non-Tech. Support(Sales/Marketing) : http://ggts.gigabyte.com.tw/nontech.asp WEB address : http://www.gigabyte.com.cn Shanghai TEL: +86-021-63410999 FAX: +86-021-63410100 Beijing TEL: +86-10-62102838 FAX: +86-10-62102848 Wuhan TEL: +86-27-87851061 FAX: +86-27-87851330 GuangZhou TEL: +86-20-87586074 FAX: +86-20-85517843 Chengdu...
