- Page 1 Safety and Reference Please read this manual carefully before operating your set and retain it for future reference. OLED65G6P OLED77G6P www.lg.com *MFL69383631* P/NO : MFL69383631 (1601-REV00)
-
Page 2: Important Safety Instructions
Important Safety Instructions Read these instructions. Keep these instructions. Heed all warnings. Always comply with the following precautions Follow all instructions. to avoid dangerous situations and ensure peak performance of your product. • Do not use this apparatus near water. WARNING/CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN... - Page 3 • Use only with the cart, stand, tripod, bracket, or • CAUTION concerning the Power Cord table specified by the manufacturer, or sold with (Can differ by country): the apparatus. When a cart is used, use caution Check the specification page of this owner’s when moving the cart/apparatus combination to manual to be certain concerning current avoid injury from tip-over.
- Page 4 TV, unplug the power cord and contact an • Do not attempt to modify this product in any authorized service center. way without written authorization from LG • Keep the product away from direct sunlight. Electronics. Unauthorized modification could •...
-
Page 5: Viewing 3D Imaging (For 3D Models)
This noise watching the 3D video and take a rest. is common for products where thermal • Only use LG 3D glasses. Otherwise, you may not deformation is required. be able to view 3D videos properly. -
Page 6: Optional Extras
Preparing CAUTION • Do not use any unapproved items to ensure the safety and product’s lifespan. NOTE • Any damages or injuries by using unapproved • When the TV is turned on for the first time after items are not covered by the warranty. being shipped from the factory, initialization of •... -
Page 7: Lifting And Moving The Tv
Lifting and Moving the TV CAUTION • Avoid touching the screen at all times, as this When moving or lifting the TV, read the following may result in damage to the screen. to prevent the TV from being scratched or •... -
Page 8: Using The Button
Using the Button Mounting on a Table You can simply operate the TV functions, pressing 1 Lift and tilt the TV into its upright position on a or moving the button. table. - Leave a 10 cm (4 inches) (minimum) space from the wall for proper ventilation. -
Page 9: Mounting On A Wall
AV box before installing the be included with the wall mount. We recommend product on a wall mount. that you use an LG brand wall mount. The LG wall (For OLED65G6P) mount is easy to adjust or to connect the cables. -
Page 10: Connections (Notifications)
Connections (Notifications) Connecting to an Antenna or Cable Connect an antenna, cable, or cable box to watch You can connect various external devices to the TV. TV. The illustrations may differ from the actual Supported external devices are: HD receivers, DVD items and an RF cable is optional. -
Page 11: Battery Installation
Slim Remote Control (Depending upon model) Returns to the previous screen. The descriptions in this manual are based on * Clears all on-screen displays and returns to the buttons on the remote control. Please read TV viewing. this manual carefully and use the TV correctly. (Home) Accesses the Home menu. -
Page 12: Magic Remote Functions
Magic Remote Functions (Depending upon model) (POWER) Turns the TV on or off. Magic remote battery is low. When the message You can turn your set-top box on or off Change the battery. is displayed, replace the by adding the set-top box to the universal remote battery. -
Page 13: Open Source Software Notice Information
Blue) terms, warranty disclaimers and copyright notices Control buttons for media contents are available for download. LG Electronics will also You can zoom in on the area where the provide open source code to you on CD-ROM for remote control is pointed. -
Page 14: Troubleshooting
Troubleshooting Environment Condition • Operating Temperature • Cannot control the TV with the remote control. 0 °C to 40 °C (32 °F to 104 °F) - Check if anything such as tape has been placed • Operating Humidity over the receiver. Less than 80 % - Check if there is any obstacle between the •... -
Page 15: Fcc Notice
Regulatory FCC RF Radiation Exposure Statement [For having wireless function (WLAN, Bluetooth,...)] This equipment complies with FCC radiation exposure limits set forth for an uncontrolled FCC Notice environment. This transmitter must not be co- located or operating in conjunction with any other antenna or transmitter. -
Page 16: Note To Cable/Tv Installer
WARNING! WARNING (For Canada) Never place a television set in an unstable [For product having the wireless function using 5 location. A television set may fall, causing serious GHz frequency bands] personal injury or death. Many injuries, particularly to children, can be avoided by taking simple 1 The device for operation in the band 5150–5250 precautions such as: MHz is only for indoor use to reduce the... -
Page 19: Child Safety
CHILD SAFETY: PROPER TELEVISION PLACEMENT MATTERS THE CONSUMER ELECTRONICS INDUSTRY CARES • Manufacturers, retailers and the rest of the consumer electronics industry are committed to making home entertainment safe and enjoyable. • As you enjoy your television, please note that all televisions – new and old- must be supported on proper stands or installed according to the manufacturer’s recommendations. - Page 20 Englewood Cliffs NJ 07632 U.S.A 201 - 266 - 2534 LG Customer Information Center For inquires or comments, visit www.lg.com or call; The model and serial numbers of the TV are located on the 1-800-243-0000 USA, Consumer User back and one side of the TV.
-
Page 21: External Control Device Setup
OWNER’S MANUAL EXTERNAL CONTROL DEVICE SETUP Please read this manual carefully before operating the set and retain it for future reference. www.lg.com... -
Page 22: Key Codes
KEY CODES KEY CODES • This feature is not available for all models. Code Code Function Note Function Note (Hexa) (Hexa) CH +, PR + R/C Button List R/C Button CH -, PR - R/C Button Exit R/C Button Volume + R/C Button PIP(AD) R/C Button... - Page 23 (TV) (PC) • LGTV supports PL2303 chip-based (Vendor ID : 0x0557, Product ID : 0x2008) USB to serial converter RS-232C IN which is not made nor provided by LG. (CONTROL & SERVICE) (PC) (TV) • It can be purchased from computer stores that carry accessories for IT support professionals.
- Page 24 EXTERNAL CONTROL DEVICE SETUP (TV) (PC) (TV) (PC) Phone jack Type RS-232C IN • You need to purchase the phone-jack to RS-232 cable required for the connection between the PC and (CONTROL & SERVICE) (PC) (TV) the TV, which is specified in the manual. RS-232C IN (CONTROL &...
-
Page 25: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters • Baud rate : 9600 bps (UART) • Stop bit : 1 bit • Data length : 8 bits • Communication code : ASCII code • Parity : None • Use a crossed (reverse) cable. Command reference list (Depending on model) DATA... -
Page 26: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV. (j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the [Set ID] to choose desired monitor ID number in option menu. Adjustment range in TV is 1 to 99. - Page 27 EXTERNAL CONTROL DEVICE SETUP * Commands may work differently depending on model and signal. 01. Power (Command: k a) Ack [d][ ][Set ID][ ][OK/NG][Data][x] ► To control Power *On or Off of the set. * In case of video mute on only, TV will display On Transmission[k][a][ ][Set ID][ ][Data][Cr] Screen Display(OSD).
- Page 28 EXTERNAL CONTROL DEVICE SETUP Data Min : 00 to Max : 64 * (Depending on model) Ack [i][ ][Set ID][ ][OK/NG][Data][x] 14. Bass (Command: k s) 09. Tint (Command: k j) ► To adjust Bass. ► To adjust the screen tint. You can also adjust in the AUDIO menu.
- Page 29 EXTERNAL CONTROL DEVICE SETUP Set ID = All = 00 5th Band 20(decimal) Data 00 & 01 = Channel Data is 10 = 00 0a Acknowledgement [v][ ][Set ID][ ][OK/NG][Data][x] Data 02 = Analog Antenna TV = 00 Result = ma 00 00 0a 00 * It depends on model, and can adjust when sound mode is EQ adjustable value.
- Page 30 EXTERNAL CONTROL DEVICE SETUP Number Data 05 = Digital Antenna TV = 02 - 22 : Antenna TV (DTV) – Don’t Use Physical Total = ma 00 00 00 11 00 01 02 Channel Number - 26 : Cable TV (CADTV) - Don’t Use Physical 2.
- Page 31 11 11 EXTERNAL CONTROL DEVICE SETUP 24. Input select (Command: x b) (Main Picture Input) ► To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data X : don’t care 00 : DTV 01 : CADTV 02 : Satellite DTV 10 : ATV Ack [t][ ][Set ID][ ][OK][Data00][Data01][Data02] ISDB-BS (Japan)
- Page 32 EXTERNAL CONTROL DEVICE SETUP 27. Auto Configure (Command: j u) (Depending on model) ► To adjust picture position and minimize image shaking automatically. It works only in RGB (PC) mode. Transmission [j][u][ ][Set ID][ ][Data][Cr] Data 01 : To set Ack [u][ ][Set ID][ ][OK/NG][Data][x]...
- Page 33 Guide de confi guration rapide Avant d’utiliser l’appareil, veuillez lire attentivement ce guide et conservez-le pour pouvoir vous y reporter ultérieurement. CR2032 OLED65G6P OLED77G6P (M8 X L77) (M4 X L12) (M10 x L70) (M4 x L10) www.lg.com P/No: MFL69383610 (1601-REV00)
- Page 34 ENGLISH Read Safety and Reference. ESPAÑOL Leer Seguridad y Consultas. FRANÇAIS Lisez Sécurité et références.
- Page 35 OLED65G6P...
- Page 36 OLED77G6P...
- Page 40 ENGLISH OLED65G6P OLED77G6P MODELS (OLED65G6P-U) (OLED77G6P-U) 1,461 x 883 x 243 (mm) 1,734 x 1,055 x 317 (mm) Stand type 57.5 x 34.7 x 9.5 (inches) 68.2 x 41.5 x 12.4 (inches) Dimensions (W x H x D) 1,461 x 892 x 68 (mm) 1,734 x 1,067 x 83 (mm) Wall mount type 57.5 x 35.1 x 2.6 (inches)
