DIMM sockets as following:
Channel 0 : DDRII1, DDRII2
Channel 1 : DDRII3, DDRII4
If you want to operate the Dual Channel Technology, please note the following explanations
due to the limitation of Intel chipset specifications.
1. Dual Channel mode will not be enabled if only one DDRII memory module is installed.
2. To enable Dual Channel mode with two or four memory modules (it is recommended to
use memory modules of identical brand, size, chips, and speed), you must install them
into DIMM sockets of the same color.
The following is a Dual Channel Memory configuration table: (DS: Double Side, SS: Single Side,
X:Empty)
DDR II 1
2 memory modules DS/SS
X
4 memory modules
DS/SS
(Note) When memory modules of different size and chips are installed, a message which indicates
that memory is configured to Flex memory mode operation will appear during POST.
Intel Flex Memory Technology offers easier upgrades by allowing different memory sizes to
®
be populated and remain in dual-channel mode.
Dual Channel Memory Configuration
The GA-965P-DS3/S3 supports the Dual Channel Technology. After operat-
ing the Dual Channel Technology, the bandwidth of memory bus will double.
The GA-965P-DS3/S3 includes 4 DIMM sockets, and each Channel has two
DDR II 2
X
DS/SS
DS/SS
- 17 -
DDR II 3 DDR II 4
DS/SS X
X DS/SS
DS/SS DS/SS
