Technical Data

Battery Voltage ........................................... 40 V D.C.
*
Battery Capacity ......................................... 5.0 Ah
Charge Time Max ....................................... 3.5 hours
Battery Run Time Max ................................ 31 min
Motor .......................................................... 600 W brushless
Max Water Inlet Temperature ..................... 104ºF/40ºC
Removable Bucket Capacity .......................5.3 gal (20 l)
High Pressure Hose Length ........................ 20.3 ft (6.2 m)
Soap Dispenser Attachement Capacity ..... 8.5 fl oz (250 ml)
Max Water Inlet Pressure ........................... 0.7 MPa
Max Flow ....................................................1 GPM
†
Rated Flow ................................................. LOW 0.68 GPM
Max Pressure ............................................ 1160 PSI
†
Rated Pressure ............................................LOW 500 PSI
Weight (unit + battery) ................................ 22.7 lbs (10.3 kg)
Weight (unit + battery + charger) ................ 23.8 lbs (10.8 kg)
* Initial no-load voltage, when fully charged, peaks at 40 volts; nominal voltage
under typical load is 36 volts.
†
Max rating per CSA test standards. Maximum internal pressure is 1160 PSI and
flow is 1 GPM. Under typical load, working pressure is 800 PSI (high setting),
650 PSI (medium setting), 500 PSI (low setting) and flow is 0.79 GPM (high
setting), 0.74 GPM (medium setting) and 0.68 GPM (low setting).
Unpacking

Carton Contents

• Water bucket assembly
• Bucket lid
• Base unit
• Trigger gun
• Spray wand
• Four (4) Quick-Connect nozzles (0º, 15º, 25º, and 40º)
• Needle clean-out tool
• Soap dispenser attachment
• Trigger gun holder
• High-pressure hose
• Garden hose adapter (female coupler)
• iONMAX iBAT40 lithium-ion battery featuring exclusive
EcoSharp technology
®
• iONMAX iCHRG40 lithium-ion battery charger
• Manuals with registration card
1. Carefully remove the pressure washer and check to see
2. Inspect the product carefully to make sure no breakage or
IMPORTANT! The equipment and packaging material are
\not toys. Do not let children play with plastic bags, foils,
or small parts. These items can be swallowed and pose a
suffocation risk!
m
MEDIUM 0.74 GPM
complete. Failure to comply could result in accidental starting
HIGH 0.79 GPM
and possible serious personal injury.
Assembly
MEDIUM 650 PSI
1. The washer must be used on a secure and stable surface
HIGH 800 PSI
Fig. 1
2. Open the box, take out the bucket lid, bucket and the
8
that all of the above items are supplied.
damage occurred during shipping. If you find damaged or
missing parts, DO NOT return the unit to the store. Please
call the Snow Joe + Sun Joe
®
1-866-SNOWJOE (1-866-766-9563).
NOTE: Do not discard the shipping carton and packaging
material until you are ready to use your new cordless
pressure washer. The packaging is made of recyclable
materials. Properly dispose of these materials in
accordance with local regulations.
WARNING!
Do not insert the battery until assembly is
in a standing, upright position (Fig. 1).
base unit (Fig. 2).
customer service center at
®
