SNOWJOE SUNJOE SPX6001C-XR-RM Operator's Manual page 7

Know Your Cordless Pressure Washer
Read the owner's manual and safety instructions carefully before operating the cordless pressure washer. Compare the
illustration below to the cordless pressure washer in order to familiarize yourself with the location of the various controls and
adjustments. Save this manual for future reference.
1
2 3
4
5
6
7
8
9
10
11
1. Trigger gun
2. Safety lock
3. Trigger
4. Trigger gun holder
5. Spray wand
6. Base unit
7. Front wheel (2)
8. Battery indicator
9. Push button for battery indicator
10. iONMAX iBAT40XR lithium-
ion battery featuring exclusive
EcoSharp technology
®
11. iONMAX iCHRG40 lithium-ion
battery charger
FRONT
12
13 14
12. Push lock button
13. Quick-connect collar
14. High-pressure hose
15. Battery compartment
16. Control panel
17. Bucket handle
18. Tow handle
19. Bucket lid
20. High-pressure hose strap
21. Bucket buckle (2)
22. Water outlet/high-pressure hose
connection
23. Needle clean-out tool
BACK
19
18
20
17
21
16
22
15
23
24
25
26 27
7
32
31
30
28
24. Garden hose adapter/connection
25. 40º Quick-Connect nozzle (gray)
26. 25º Quick-Connect nozzle (green)
27. 15º Quick-Connect nozzle (yellow)
28. 0º Quick-Connect nozzle (orange)
29. Soap dispenser attachment
30. All-direction wheel (2)
31. Water bucket
32. Nozzle storage board
33. High-pressure hose connection
34. Trigger lock
33 34
29
