Philips MC-320 Service Manual
Hide thumbs Also See for MC-320:

Advertisement

Quick Links

Micro System
Service
Service
Service
Service
Service
Service Manual
©
Copyright 2002 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system
or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
Published by SL 0321 Service Audio
Version 1.0
TABLE OF CONTENTS
Location of PCBs & Version Variations ...................... 1-2
Technical Specifications ............................................. 1-3
Measurement setup .................................................... 1-4
Service Aids, Safety Instruction, etc. .......................... 1-5
Preparations & Controls ............................................. 1-7
Disassembly Instructions ............................................... 2
Set Block diagram ......................................................... 3
Set Wiring diagram ........................................................ 4
Key Board ...................................................................... 5
Power Board .................................................................. 6
Tuner Board ................................................................... 7
MCU & CD Board .......................................................... 8
Connection Board .......................................................... 9
Main Board .................................................................. 10
Set Mechanical Exploded View & Parts List ............... 11
Printed in The Netherlands
Subject to modification
Page
CLASS 1
LASER PRODUCT
GB
MC-320
All Version
3140 785 32530

Advertisement

loading
Need help?

Need help?

Do you have a question about the MC-320 and is the answer not in the manual?

Questions and answers

Jose
March 26, 2025

How do you get the upper cover off…just four screws

1 comments:
Mr. Anderson
March 26, 2025

To remove the upper cover (Top Cabinet) of the Philips MC-320, follow these steps:

1. Remove the Brand Rim Left & Right (Step A).
2. Unscrew and remove the necessary screws labeled B1 (x4).
3. Lift and detach the Top Cabinet.

These steps are part of the disassembly instructions in the manual.

This answer is automatically generated

Summary of Contents for Philips MC-320

  • Page 1 LASER PRODUCT © Copyright 2002 Philips Consumer Electronics B.V. Eindhoven, The Netherlands All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without the prior permission of Philips.
  • Page 2 LOCATION OF PRINTED CIRCUIT BOARDS VERSION VARIATIONS Type/Versions MC-320 Features & Board in used RDS function ECO Standby Aux Input Digital Coaxial Out Line Out Subwoofer Out Headphone Out AC Voltage Selector Non-Cenelec Tuner Cenelec Tuner...
  • Page 3 SPECIFICATIONS GENERAL: Mains voltage /21 : 110V ~ 127V / 220V ~ 240V Tuning range : 153-279kHz Switchable /22/25 : 220V ~ 230V Grid : 3kHz /30 : 240V IF frequency : 450kHz ± 1kHz Aerial input : Frame aerial 18.1µH /15/33 : 220V /37 : 120V Maximum Sensitivity...
  • Page 4 MEASUREMENT SETUP Tuner FM Bandpass LF Voltmeter 250Hz-15kHz e.g. PM2534 e.g. 7122 707 48001 RF Generator e.g. PM5326 S/N and distortion meter e.g. Sound Technology ST1700B Use a bandpass filter to eliminate hum (50Hz, 100Hz) and disturbance from the pilottone (19kHz, 38kHz). Tuner AM (MW,LW) Bandpass LF Voltmeter...
  • Page 5 SERVICE AIDS Service Tools: ESD Equipment: Universal Torx driver holder ........4822 395 91019 Anti-static table mat - large 1200x650x1.25mm ... 4822 466 10953 Torx bit T10 150mm ..........4822 395 50456 Anti-static table mat - small 600x650x1.25mm ..4822 466 10958 Torx driver set T6 - T20 .........
  • Page 6 WAARSCHUWING WARNING Alle IC’s en vele andere halfgeleiders zijn All ICs and many other semi-conductors are gevoelig voor electrostatische ontladingen susceptible to electrostatic discharges (ESD). (ESD). Careless handling during repair can reduce life Onzorgvuldig behandelen tijdens reparatie kan drastically. de levensduur drastisch doen verminderen. When repairing, make sure that you are Zorg ervoor dat u tijdens reparatie via een connected with the same potential as the mass...
  • Page 7 PREPARATIONS AND CONTROLS...
  • Page 8 PREPARATIONS AND CONTROLS...
  • Page 9 PREPARATIONS AND CONTROLS...
  • Page 10 1-10 PREPARATIONS AND CONTROLS...
  • Page 11 DISASSEMBLY INSTRUCTIONS B1 (x4) A. To remove Brand Rim Left & Right B. To remove Top Cabinet C. To remove Bottom Cabinet D. To remove Tape Deck E. To remove Left & Right Metal Side Bars B2 (x4) F. To remove CD Bracket G.
