Typical wire size resistance:
18 AWG solid: Approximately 8 ohms/1,000 ft.
16 AWG solid: Approximately 5 ohms/1,000 ft.
14 AWG solid: Approximately 3 ohms/1,000 ft.
12 AWG solid: Approximately 2 ohms/1,000 ft.
Example: Assume you have 10 devices on a zone and each re-
quires 50 mA average and 2000 Ft. of 14 AWG wiring (total
length=outgoing +return). The voltage at the end of the loop is
0.050 amps per device x 10 devices x 3 ohms/1,000 ft. x 2000 ft
=3 volts drop.
NOTE: If class "A" wiring is installed, the wire length may be up
to 4 times the single wire length in this calculation.
The same number of devices using 12 AWG wire will produce only
2 volts drop. The same devices using 18 AWG wire will produce
8 volts drop. Consult your panel manufacturer's specifications, as
well as SpectrAlert's operating voltage range to determine accept-
able voltage drop.
Figure 1A: Current Draw Measurements (RMS)
NOTE: All 'S' and 'P' models were only tested at the 8-17.5 and
16-33 Volt-FWR/DC limits. This does not include the 80% low-
end or 110% high-end voltage limits.
Strobe Current Draw
Operating
Current
Strobe
Candela
Setting 12V
15
112
15/75
135
30
75
110
NOTE: 12 VDC 2-wire horn/strobe current is shown in Figure 1D.
24VDC 2-wire horn/strobe current draw is shown in Figure 1E.
Horn/Strobe current draw can be calculated by adding the strobe
current draw (Figure 1A) for chosen candela setting to the horn
current draw (Figure 1C) for chosen setting.
Figure 1B: Horn Sound Measurements (dBA):
Selectable Horn Tones
Temporal
Low Electromechanical
Volume
3000 Hz Interrupted
High Electromechanical
Volume
3000 Hz Interrupted
Non- Low Electromechanical
Temporal Volume
3000 Hz Interrupted
High Electromechanical
Volume
3000 Hz Interrupted
D900-37-00
FWR DC
Operating
Current
Strobe
24V 12V 24V
64 127 59
74 127 69
93 90
158 160
208 209
8-17.5V 16-33V
67 75
68 75
71 80
72 81
71 79
72 79
76 84
77 86
