Installation or Removal of the Mulch
Plug (Fig. 5)
1. UNPLUG THE POWER CORD, AND WAIT FOR BLADE
TO COME TO A COMPLETE STOP.
2. To remove the mulch plug lift the chute cover and pull
out on the handle.
3. The mulch plug is inserted on an angle so it will require
some force when removing.
Fig. 5
Chute cover
Mulch plug
Adjust the Upper Handle Height (Fig. 6)
1. Loosen the upper handle knob.
2. Adjust the handle to the most comfortable of the
3 positions.
3. Tighten the upper handle knob as tight as you can.
Operating
Starting/Stopping the Mower
(Fig. 7)
1. For the proper operation of this lawn mower, you need
to insert the safety key in position. The lawn mower
can now be operated by moving the lever release first
to the left so you can access control lever. Hold the
switch control lever for operation.
2. To stop the lawn mower, release the switch control lever.
3. If your lawn mower is not going to be used for a while,
pull out the safety key. The machine will not operate
without the safety key inserted.
Fig. 7
Safety Key
Self-Propelled Lever (Fig. 8)
1. After starting the mower and to have it self propelled,
just pull up on the self-propelled lever to the handle bar
and the mower will drive itself.
2. To stop mower from moving forward just released the
Fig. 6
self-propelled lever (see fig. 8)
Fig. 8
Release lever to stop
forward motion
m
CAUTION:
the safety key or lever.
6
Switch
Control
Lever Release
Lever
Handle Bar
Self-Propelled
Lever (pull up to
start self drive)
Do not attempt to override the operation of
Switch
Control
Lever
