FROST-FREE REFRIGERATOR
BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
Write Serial Number (on lower left corner of
inside cabinet) here:
_______________________
Serial No.:
INSTRUCTION MANUAL
Model No.
AL54
Felix Storch, Inc.
An ISO 9001:2008 registered company
770 Garrison Avenue
Bronx, NY 10474
www.summitappliance.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Summit Professional AL54SSTB
Summary of Contents for Summit Professional AL54SSTB
- Page 1 FROST-FREE REFRIGERATOR INSTRUCTION MANUAL AL54 Model No. BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS. Felix Storch, Inc. Write Serial Number (on lower left corner of An ISO 9001:2008 registered company inside cabinet) here: 770 Garrison Avenue Bronx, NY 10474 _______________________ Serial No.:...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Appliance Safety Important Safeguards Location of Parts Installation Instructions Before Using Your Appliance Installation of Your Appliance Electrical Connection Extension Cord Reversing the Door Swing of Your Appliance Installing the Stainless Steel Handle Operating Your Appliance 8-10 Control Panel Sabbath Mode Temperature Memory Function... -
Page 3: Appliance Safety
APPLIANCE SAFETY Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is the Safety Alert Symbol. The symbol alerts you to potential hazards that can kill or injure you and others. - Page 4 - Avoid open flames and anything that creates a spark, - Disconnect from the power supply, - Air the room in which the appliance is located for several minutes and - Contact the Service Department for advice. The more coolant there is in an appliance, the larger the room it should be installed in. In the event of a leakage, if the appliance is in a small room, there is the danger of combustible gases building up.
-
Page 5: Location Of Parts
LOCATION OF PARTS Digital Control Panel Stainless Steel Door LED Light Shelves (3) Stainless Steel Handle Door Racks (2) Ventilation Grille Adjustable Legs Security Lock... -
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS BEFORE USING YOUR APPLIANCE Remove the exterior and interior packing. Before connecting the appliance to the power source, let it stand upright for approximately 2 hours. This will reduce the possibility of a malfunction in the cooling system from handling during transportation. -
Page 7: Extension Cord
that matches the rating label on the appliance. This provides the best performance and also prevents overloading house wiring circuits that could cause a fire hazard from overheating. Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight out from the receptacle. -
Page 8: Installing The Stainless Steel Handle
hand side. 5. Screw the alternative left top hinge (6), included in the fittings, on the left hand side of cabinet. (Fig. 3) 6. Relocate the door to the designated position. Then screw the bottom hinge assembly on the left designated position and tighten it after the door is leveled. -
Page 9: Sabbath Mode
Used to increase (warm) the set temperature by 1°C/1ºF. DOWN Used to decrease (cool) the set temperature by 1°C/1ºF. ºF/ºC Selector Select the temperature display in Fahrenheit or Celsius degrees. To change the temperature from Fahrenheit to Celsius or from Celsius to Fahrenheit, press and hold the LIGHT key for 5 seconds. Setting the Temperature Control ... -
Page 10: Temperature Memory Function
TEMPERATURE MEMORY FUNCTION In the event of a power interruption (power surge, breaker switch, etc.), the unit can remember the previous temperature settings, and when the power is recovered, the cabinet temperature will return to the same setting temperature as before the power went off. DEFROSTING ... -
Page 11: Care And Maintenance
CARE AND MAINTENANCE CLEANING YOUR APPLIANCE Turn off the power, unplug the appliance, and remove all items, including shelves. Wash the inside surfaces with a solution of warm water and baking soda (about 2 tablespoons of baking soda to a quart of water). ... -
Page 12: Troubleshooting
TROUBLESHOOTING You can solve many common problems easily, saving you the cost of a possible service call. Try the suggestions below to see if you can solve the problem before calling the servicer. Troubleshooting Guide PROBLEM POSSIBLE CAUSE REMEDY Appliance is not connected to a power ... - Page 13 “E0” indicates a communication error for Call for service. 3-zone models. “E1” or “E2” indicates that the air Display “E0”, “E1”. “E2”, temperature sensor has failed. “E3” or “E4” indicates that the defrost “E3”, “E4”, “E5” or “E7”. sensor in the evaporator has failed.
-
Page 14: Limited Warranty
LIMITED WARRANTY ONE-YEAR LIMITED WARRANTY Within the 48 contiguous United States, for one year from the date of purchase, when this appliance is operated and maintained according to instructions attached to or furnished with the product, warrantor will pay for factory-specified parts and repair labor to correct defects in materials or workmanship. Service must be provided by a designated service company.
