- Page 1 PERATION ANUAL ONTROL VERSION 29.22 04/2022 - Version 1 DoorTec Deutschland | www.doortec.online Änderungen vorbehalten | Subject to Modifications...
-
Page 2: Table Of Contents
Safety notice indicating a danger that could result in 2.2 Using the equipment for its intended purpose slight or moderate injuries. The control V7E is designed only for controlling gates and doors with mechanical or digital end position sys- NOTICE ! tems. -
Page 3: Safety Related Regulations
3. SAFETY-RELATED REGULATIONS WARNING ! For connecting, programming and servicing, the fol- • Ensure that children can not play with the door con- lowing regulations must be observed (the list is not trols or the hand transmitter. • Before setting the door in motion, make sure that no exhaustive). -
Page 4: Initial Operation
5. INITIAL OPERATION Before initial operation and at regular intervals of no more than one year, power-operated windows, doors and gates must be inspected by a qualified person (whereby written inspection records must be kept). After setting the system in operation, the operator of the door system, or the operator’s representatives, must be instructed in the operation of the system. - Page 5 5.3 Parameter Parameter overview Parameter Description Page Operation mode Reaction – Failure on photo or Safety edge Selection of limits Learning - Electronic Limit Open Fine Tuning of electronic Limit Open Learning - Electronic limit CLOSE Fine tuning of electronic limit CLOSE ½...
- Page 6 Parameter Description Page Auto close Car wash function Forced closing GO function (Step) Interlock function ON/OFF Run time control Reverse time safety edge Reserve time photo Service counter setup Service count reaction Delay time indication of missing encoder position Option relay K3 DoorTec Deutschland | www.doortec.online 04/2022 - Version 1 Änderungen vorbehalten | Subject to Modifications...
-
Page 7: Operation Mode
The factory setting is shown in bold letters. Parameter Value 01 = Hold to run OPEN Hold to run CLOSE (bridge in terminal X3 / 23-24 when there is no safety edge) 02 = Impulse OPEN Operation mode Hold to run CLOSE (bridge in terminal X3 / 23-24 when there is no safety edge) 03 = Impulse OPEN Impulse CLOSE... -
Page 8: Learning - Electronic Limit Open
Parameter Value Press STOP 2 times - Display shows ‚run‘. Run the door to open position. (By pressing OPEN or DOWN). Learning - Electronic limit OPEN Press the STOP push-button to confirm open limit. (The display will show open limit symbol about 2 sec. and the display will auto- matic switch back to active parameter number). -
Page 9: Fine Tuning Of Electronic Limit Close
Parameter Value Press STOP push-button until the display parameter value is active. Fine tune OPEN limit 6-9 more open, 1-4 less open. Press OPEN or CLOSE Fine tuning of electronic push-button to change value. limit CLOSE If the value is changed: Press STOP push-button (Display shows ”RUN”) Test the fine tuning by running the door up and down. -
Page 10: Auto Close ½ Open
Parameter Value 00 = No auto close from ½ open limit Auto close ½ open 01 = Auto close from ½ open limit Notice: Auto close must be activated in parameter 32. Note that actual edge must be connected but not activated before this setup. If the controller has observed a wrong edge select, the display will show ERR. -
Page 11: Wire Tightening
Parameter Value 00 = No wire tighten function 01 = Wire tighten 5 ms Wire tightening 02 = Wire tighten 10 ms 03 = Wire tighten 20 ms 04 = Wire tighten 30 ms Used to prevent that the wire is getting loose when the door is closed. Works as a small pull back time when the door stops on close limit. - Page 12 Parameter Value Only when car wash function is selected (parameter 33), closing even though photo has not been activated Forced closing 00 = No forced closing 01 = Forced closing after 2 min. 02 = Forced closing after 5 min. 03 = Forced closing after 10 min.
- Page 13 Parameter Value xx = Reverse time of Photo in 1/100 seconds. 30 = 0.30 seconds Reverse time photo Range 0.05 – 0.99 sec. This reverse time is also used as force reversing time. (when using a single phase motor the parameter is to be set to 50 to avoid problems with too fast reversing time) 00 = No Service countdown 01 = 15 open cycles before service (for test only)
-
Page 14: Led Codes
6. LED CODES (D15) Used when electronic limits is selected : Flashes on error Error Explanation Solving error Check connections. No answer from encoder Maybe RS485 A and B are interchanged. Limits not learned Learn limits. Service needed. Fatal error. Move the door man- ual to middle position without power. -
Page 15: Run Mode / Error Codes
7. RUN MODE The display will in run mode show status of limits, some inputs or error codes if they occurs. When power up the software version is showed shortly. Display Description Remark Nothing active Door is stopped between limits and no errors are found. 4 chairs symbol Open limit active Normal symbol as an aid in programming and troubleshooting. - Page 16 7.1 Error Codes Display Description Remark Monitoring failure of safety edge if this function is activated. Check Edge monitoring or adjust safety edge. Run time Door is stopped on run time control. Service counter decremented to 0. Service Reset for new countdown. Failure in photo circuit.
-
Page 17: Electronic Counter And Last 10 Errors
8. ELECTRONIC COUNTER AND LAST 10 ERRORS To select counter or error history – Close the door and switch DIL switch 2 to ON. The door cannot be moved when display status is active! Electronic Counter The display is flashing between and the most significant digits (1000 to 999000) and the least significant digits (000 –... -
Page 18: Pcb-Overview
9. PCB OVERVIEW STOP button Mains supply Relay K3 OPEN button Motor Auto. Close (ON/OFF) CLOSE button Control and safety devices Secondary safety edge LED Power Key pad Power supply selection LED Stop Antenna radio receiver Contactor OPEN LED limit CLOSE Plug in module: radio receiver Contactor CLOSE LED push button OPEN... -
Page 19: Connections
10. CONNECTIONS X3 10.5 Safety device - Pneumatic safety edge Parameter 21:04) 10.1 Command devices / 6 wire connection Safety edge 10.6 Additional safety edge The LED light when a button is actuated or when inter- rupting the STOP circuit. 10.2 Command devices / 4 wire connection 10.7 Photo Beam one way - Photo 2 (Testing required) - Page 20 10.8 Photo Beam Reflex - Photo 2 10.11 Limit switch - Mechanical limit switch (Testing required) Parameter 11:00) Colour code photo beam RAY-RT: 18: +24 V = brown 19: 0V = blue 20: Test = grey 21: Input = black 22: Input = white INFORMATION ! INFORMATION !
- Page 21 10.14 Plug-in modules 10.13 Light curtain P-N-P transistor • X7 RCM434A03 RADIO RECEIVER Plug-in module radio receiver • X8 TRAFFIC LIGHT LAMP PCB V.1 Plug-in module traffic lights 10.15 Single phase motor Supply 1x230V V7E terminals X1: L1 X1: L3 + N Semiconduc- Colour (linked with a wire)
-
Page 22: Technical Data
11. TECHNICAL DATA Enclosure data: 293 x 190 x 110 mm, ABS Protection: IP65 (with appropriate cable glands) Installation: Vertical on a vibration free and flat wall, min. hight: 1.1 m Mass: ca. 1.8 kg Humidity: Up to 93% RH non-condensing Temperature range: Operating: -10°... -
Page 23: Declaration Of Conformity
2. DECLARATION OF CONFORMITY EU DECLARATION of conformity Declaration under sole responsibility that the door control units: Mini Std. V.7E SR manufactured at and technical documentation: DALMATIC A/S LÆGÅRDSVEJ 9 DK-8520 LYSTRUP is in accordance with the following Directives: EMC Directive (Directive 2014/30/EU) relating to electromagnetic compatibility. Machinery Directive 2006/42/EC Low Voltage Directive 2014/35/EU) to electrical equipment intended for use within certain voltage limits. - Page 24 Rolling Shutter Operators DoorTec Sectional Door Operators PRODUCTS High-Speed Door Operators Chain Wheel Operators Controls Safety Systems Accessories 04/2022 - Version 1 DoorTec Deutschland | www.doortec.online Änderungen vorbehalten | Subject to Modifications...
