*MFL71179712* (1902-REV00) SM81* SM86* SM90* www.lg.com (M5 x L25) (M4 x L12) 55SM81*, 65SM86*, 55SM86* 65SM90* Head Head Head washer Head washer Head Head washer Head washer washer washer washer : Depending on model...
Head washer 90° 55SM8100PPA 1232 263.1 63.6 18.7 17.2 55SM8600PPA 1451 323.7 25.8 24.1 65SM8600PPA 1455 323.7 62.5 28.1 26.4 65SM9000PPA Power requirement AC 100-240 V ~ 50/60 Hz...
Warning! Safety • Ventilation - Install your TV where there is proper ventilation. Do not install in instructions a confined space such as a bookcase. - Do not install the product on a carpet or cushion. - Do not block or cover the product with cloth or other materials while unit is plugged in.
• Use only an authorized attachments / accessories approved by in electric shock or product damage. LG Electronics. Otherwise, this may result in fire, electric shock, malfunction, or product damage. • Never disassemble the AC adapter or power cord. This may result in...
Preparing Separate Purchase Separate purchase items can be changed or modified for quality • If the TV is turned on for the first time after it was shipped from the improvement without any notification. Contact your dealer to buy these factory, initialization of the TV may take a few minutes.
Lifting and moving the TV • Avoid touching the screen at all times, as this may result in damage to the screen. • When attaching the stand to the TV set, place the screen Please note the following advice to prevent the TV from being scratched facing down on a cushioned table or flat surface to protect or damaged and for safe transportation regardless of its type and size.
Securing TV to the Wall • Do not apply foreign substances (oils, lubricants, etc.) to the screw parts when assembling the product. (Doing so may damage the product.) • If you install the TV on a stand, you need to take actions to prevent the product from overturning.
LG recommends that wall mounting be performed by a qualified professional installer. We recommend the use of LG’s wall mount bracket. LG’s wall mount bracket is easy to move with cables connected. When you do not use LG’s wall mount bracket, please use a wall mount bracket where the device is adequately secured to the wall with enough space to allow connectivity to external devices.
Connections Other connections Connect your TV to external devices. For the best picture and audio Connect various external devices to the TV and switch input modes to quality, connect the external device and the TV with the HDMI cable. select an external device. For more information of external device’s Some separate cable is not provided.
Using Button External Devices Available external devices are: Blu-ray player, HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and You can simply operate the TV functions, using the button. other external devices. • The external device connection may differ from the model. •...
Using Magic Remote To use the button, press and hold for more than 1 second. Control (POWER) Turns the TV on or off. (STB POWER) You can turn your set-top box on or off by adding the set-top box to the universal remote control for your TV. (Depending on model) Number buttons Enters numbers.
Troubleshooting Registering Magic Remote Control Cannot control the TV with the remote control. How to register the Magic Remote Control • Check the remote control sensor on the product and try again. To use the Magic Remote, first pair it with your TV. •...
Generated Sound • “Cracking” noise: A cracking noise that occurs when watching or turning off the TV is generated by plastic thermal contraction due to temperature and humidity. This noise is common for products where thermal deformation is required. • Electrical circuit humming/panel buzzing: A low level noise is generated from a high-speed switching circuit, which supplies a large amount of current to operate a product.
Specifications Broadcasting Specifications Digital TV Analogue TV Television system ISDB-T NTSC-M Program coverage VHF, UHF, CATV Maximum number of storable ISDB-T & Analogue TV : 3000 programs External antenna impedance 75 Ω Wireless module(LGSBWAC92)Specifications Wireless LAN (IEEE 802.11a/b/g/n/ac) Frequency range Output power (Max.) 2400 to 2483.5 MHz 18 dBm...
• Using cabinets or stands recommended by the manufacturer of the LG Electronics will also provide open source code to you on CD-ROM television set. for a charge covering the cost of performing such distribution (such •...
The model and serial number of the product are located on the back and on one side of the product. Record them below in case you ever need service. Model Serial No.
