WHYNTER 32 Bottle French Door Dual Temperature Zone

Freestanding Wine Cooler

MODEL# : WC-321DD

SB/W

Instruction Manual

Thank you for your purchase of this WHYNTER product. Please read this Instruction Manual carefully before using product

to ensure proper use. Keep this manual in a safe place for future reference.

Table of Contents

Need help?

Do you have a question about the WC-321DA and is the answer not in the manual?

Questions and answers

Summary of Contents for Whynter WC-321DA

Page 1 Freestanding Wine Cooler MODEL# : WC-321DD SB/W Instruction Manual Thank you for your purchase of this WHYNTER product. Please read this Instruction Manual carefully before using product to ensure proper use. Keep this manual in a safe place for future reference.
Page 2: Table Of Contents
TABLE OF CONTENTS Parts and Features …………………….………...3 Technical Data ……………………………………4 Important Safety Instructions……………………5 - 6 Installation …………………………………………7 Operations …………………………………………8 - 9 Care and Maintenance……………………………9 Troubleshooting………………………....10 - 11 Warranty …………..………………………....12...
Page 3: Parts And Features
1. Parts and Features 1. INTERIOR LIGHT 2. FAN MASK 3. WINE RACK 4. STAND 5. DOOR HINGE 6.TEMPERATURE DISPLAY 7.TEMPERATURE CONTROLLER 8. DOOR FRAME 9. TEMPERED GLASS DOOR 10.HANDLE BAR...
Page 4: Technical Data
2. Technical Data Model no. WC-321DD Capacity 100L (32 standard wine bottles) Voltage 110v Current 3.0 Amp Input power 210W Power 1.5(59°F) Consumption(KW.h/24h) ﹥64°F Max Temperature Difference Temperature Control 46-66 °F Range Net weight 69.5 lbs Gross weight 75 lbs 20.67"...
Page 5: Important Safety Instructions
3. Important Safety Instructions To reduce the risk of fire, electrical shock, or injury when using your appliance, follows these basic precautions   Do not use if the power supply cord is damaged. If damaged, it must be replaced by a qualified electrician.
Page 6  An empty cooler can be a hazardous for children or small pets. If disposing of the cooler remove gasket seals, latches, lids or the entire door from your unused appliance, or take other action to ensure the cooler is harmless. ...
Page 7: Installation
4. Installation Before using your wine cooler  Remove the exterior and interior packaging material  Stand the unit upright for approximately 2 hours before connecting to the power source. This will reduce the possibility of a malfunction in the cooling system from handling during transportation.
Page 8: Operations
5. Operations Temperature Setting It is recommended that you install the wine cooler in a place where the ambient temperature is between (60- 80°F). If the ambient temperature is above or below recommended temperatures, the performance of the unit may be affected. For example, placing in extreme cold or hot conditions may cause interior temperature to fluctuate thus the set temperature may not be achievable.
Page 9: Care And Maintenance
Bottle Capacity This wine cooler is designed to store 6 bottles in the upper zone and 15 bottles in the lower zone. The bottle capacity listed for your wine cooler is an estimated maximum capacity based on a standard 750ml wine bottle. For other size bottles, the capacity will vary.
Page 10: Troubleshooting
7. Troubleshooting You can solve many common problems by referring the troubleshooting suggestions listed below. Symptoms Possible causes Solutions The wine cooler There is a power failure. Ensure the cooler is plugged in and the power outlet does not turn on. The cooler is not plugged in.
Page 11 The unit is not level. Make sure the cooler is on a level surface. The door will not shut properly. The door gasket is dirty. Clean the door gasket. The door gasket is malformed. Make sure the door gasket is properly sealing. The shelves are incorrectly Correctly install the shelves.
Page 12: Warranty
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. WHYNTER SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY.

This manual is also suitable for:

Wc-321dd
