- Page 1 - 200 Zylight F8 LED Fresnel User Instructions v1.4 F8-D*, F8-T*, F8-B...
- Page 2 CRI (color rendering index) and a quality of light matched only by traditional sunlight and incandescent bulbs, while using a fraction of the energy. The F8-200 LED Fresnel is part of Zylight’s pursuit of high quality, affordable, intelligent xtures.
-
Page 3: Optional Accessories
You may also visit us on the web at www.zylight.com for any comments or suggestions. Service Hours are Monday through Friday 9:00 a.m. to 5:00 p.m. -
Page 4: Safety Precautions
clearly written on the outside of the return package. A brief description of the problem as well as the R.A. number must also be written down on a piece of paper included in the shipping carton. If the unit is under warranty, you must provide a copy of your proof of purchase invoice. - Page 5 “FAN FAULT” will display in the unlikely event of a fan obstruction or failure. Please refer any error codes to Zylight’s service department. • To reduce the risk of electrical shock or re, do not submerge this xture in water.
- Page 6 First Set Up – Assembly Instructions To optimize the correct performance of your xture, please follow these simple assembly instructions, and refer to this manual if you ever need to reattach the yoke assembly to your xture. In some instances, the yoke assembly will be shipped separated from your xture.
- Page 7 Fig 1 Fig 2 Fig 3 Fig 4 Fig 5 Fig 6 Fig 7 Fig 8 Page 6...
-
Page 8: Barn Door Installation
Barn Door Installation The F8 includes a set of compact 4-way barn doors as part of the kit. The barn doors are installed by way of 4 barn door ears. There are two positions for the barn door ears – open (the packed position) and locked (or the forward position). - Page 9 Fig 5 Fig 6 Fig 7 Fig 8 Fig 9 Fig 10 Always tether the barn doors with a safety cable to prevent accidental separation! There are two holding positions on the barn door ears (Fig 8). The smaller clip, closest to the Fresnel lens position has a 9”...
- Page 10 AC Adapter Bag (P/N 19-02042) Side AC Adapter Bracket (P/N 26-02034) Power Supply: The Zylight F8 Fresnel is powered through a standard 4-pin XLR connector by either the included F8-200 Worldwide AC Adapter, or by the Zylight F8-200 Battery Module.
-
Page 11: Focus Adjustment
Focus Knob Yoke/Handle Yoke/Handle Mount Mount Dimmer Power Input MODE Knob to set DMX Address & ZyLink DMX Breakout Jack On/Off & Dimming To turn on the F8-200 press and release the Dimmer knob. Press and release again to turn the light off. Turn the Dimmer knob to the right to increase brightness and to the left to decrease brightness. -
Page 12: About Dmx
ZyLink Wireless Control The F8-200 has built-in wireless control for adjustment up to 50’ (15m) away using the Zylight Remote or other Zylight instrument (available separately). ZyLink Operation: To enable ZyLink control, push & quickly release the MODE knob, then turn the knob to select the desired wireless channel (1-10). -
Page 13: Dmx Control
DMX Breakout Jack. The F8 is a self-terminating device and the use of a DMX terminator or Zylight DMX interface box will not be necessary when the F8 is the last light in your DMX chain, or if you are running separate lines to each of your xtures. -
Page 14: Dmx Channel Assignments
DMX cables must be acceptable for DMX data transmission (not microphone cable) and should follow the standard pin-out. The maximum DMX data run from any DMX source to the last xture in a chain is 1000 feet (300m). DMX-512 pin-out: 1 Common (Shield) 2 Data –... -
Page 15: Year Limited Warranty
Warranty 2-YEAR LIMITED WARRANTY Zylight LLC warrants to the original end user customer of its products that its products are free from defects in material and workmanship under normal use for two (2) years from the date of purchase. Except as provided herein, Zylight LLC makes no express warranties, and any implied warranties, including those of merchantability and tness for a particular purpose, are limited in duration to the duration of the written limited warranties contained herein. - Page 16 This is not a service contract, and this warranty does not include maintenance, cleaning, or periodic check-up. During the period speci ed above, Zylight will replace defective parts at its expense, and will absorb all expenses for warranty service and repair labor by reason of defects in material or workmanship.
-
Page 17: Parts Diagram
F8-200 Fresnel Parts Diagram Page 16... - Page 18 F8-200 Fresnel Parts Diagram Page 17...
-
Page 19: Specifications
XLR 4-pin AC Power Supply 120 – 240V AC, 50/60Hz Color Temperature Fixed. F8-T200 (#26-01044-Blk, #26-01046-White) 3200K F8-D200 (#26-01043-Black, #26-01045-White) 5600K F8-B (#26-01055)365nm CRI Index F8-T (3200K) 94+ CRI, F8 D (5600K) 92+ CRI Beam Angle 16°- 70°, Variable Spot-Flood Method of Focus Rear knob. - Page 20 Zylight LLC World Headquarters: 10718 McCune Avenue Los Angeles, CA 90034 978-244-0011 info@zylight.com...
