Z50 SPECIFICATIONS
MECHANICAL
SIZE:
5.4" x 2.0" x 2.0" [137mm x 51mm x 51mm]
WEIGHT:
11oz. [314g]
MOUNTING:
Two: 1/4"-20 Socket
ELECTRICAL
INPUT:
9-20V DC
DC PLUG:
OD: 5.5mm, ID: 2.1mm
AC ADAPTER:
100-240V, 50-60Hz
POWER:
30W max. [2.5A max. @ 12V]
OUTPUT
BEAM ANGLE:
163°
DIMMING:
1% - 100%
PRESETS:
Color Mode - Two: User defined
White Mode - Two: 3200K, 5600K
LED LIFE:
10,000 Hours
THE ZYLIGHT Z50 IS PROTECTED BY THE FOLLOWING U.S.
AND FOREIGN PATENTS WITH OTHER U.S. AND FOREIGN
PATENTS PENDING:
US 6,016,038
US 6,608,453
US 6,150,774
US 6,777,891
US 6,211,626
US 6,788,011
US 6,340,868
US 6,806,659
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. Changes or modifications not expressly approved
by the party responsible for compliance could void the user's authority to operate the equipment.
Per FCC 15.105(a), Note: This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accor-
dance with the instruction manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Zylight LLC
PO Box 54
Chelmsford, MA 01824
www.zylight.com
© Copyright 2003-2006 Zylight LLC. All rights reserved. 24-07001 Rev. 2
CA 2,302,227
EP 1 016 062 B1
AU 757000 B2
HK 1025416
DE 698 07 092 C0
Z50
Intelligent LED Light
USER GUIDE
Advertisement
Related Manuals for Zylight Z50
Summary of Contents for Zylight Z50
- Page 1 Zylight LLC PO Box 54 Chelmsford, MA 01824 www.zylight.com © Copyright 2003-2006 Zylight LLC. All rights reserved. 24-07001 Rev. 2...
- Page 2 Adding a Z50 to an Existing Group To add a Z50 to an existing group, the process is the same as in How To ZyLink™. Simply push in and hold the button on the light you wish to POWER add to the group until the output changes and the target group flashes. If there Thank you for choosing Zylight.
- Page 3 All lights in the group will turn off. Repeat the process to turn the lights back on again. DO NOT unplug or remove power from any Z50 in a group or that particular light will be un-linked.
- Page 4 Turn the big knob clockwise to increase the Z50’s intensity, counter-clockwise to decrease intensity. Power Consumption The powerful Z50 can draw up to 30 Watts at full power (2.5 Amps @ 12 Volts, Modes or 2.1 Amps @ 14.4 Volts). When powering the Z50 from a battery, be sure The Z50 operates in two modes: .
