Operation
Manual
The Prince Castle 247SL & 248SL Toaster
Grill Series offers two practical options for
quick-and-easy bread product toasting. Both
models have pivoting sides allowing for easy
access to the platens for cleaning. The 248SL
Model has the added feature of a Club
sandwich level.
LIMITED WARRANTY
This product is warranted to be free from defects in material
and/or workmanship for a period of 1 year from date of original
installation, not to exceed 18 months from the date of
manufacture.
Any component which proves to be faulty in material and/or
workmanship will be replaced or repaired (at the option of Prince
Castle, Inc.) without cost to the customer for parts and labor.
This warranty covers on-location service (i.e. trip charges and/or
mileage). Travel mileage is limited to 100 miles (200 Kilometers)
round trip (one trip warranty) from an authorized service agency
or its sub-service agency.
247-502revA-EN
Product Identification
355 East Kehoe Blvd. • Carol Stream, IL 60188 USA
Telephone: 630-462-8800 • Toll Free: 1-800-PCASTLE
Fax: 630-462-1460 • www.princecastle.com
Models 247SL & 248SL
247SL Series
This warranty is subject to the following exceptions/conditions:
• Use of any non-genuine Prince Castle parts voids this
warranty.
• All labor to be performed during regular work hours. Overtime
premium (the incremental amount) will be charged to the
customer.
• Damage caused by carelessness, neglect and/or abuse (e.g.,
dropping, tampering or altering parts, equipment damaged in
shipment, by fire, flood or an act of God) is not covered under
this warranty.
• All problems due to operation at voltages other than that
specified on equipment nameplates are not covered by this
warranty. Conversion to correct voltage is the customer's
responsibility.
• This equipment must be serviced by Prince Castle Authorized
Service Agency or a Prince Castle Service Technician during
the warranty period.
Toaster Grills
248SL Series
Printed in USA 10/06 © 2006
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Prince Castle 247SL
Summary of Contents for Prince Castle 247SL
-
Page 1: Product Identification
248SL Series LIMITED WARRANTY This warranty is subject to the following exceptions/conditions: • Use of any non-genuine Prince Castle parts voids this This product is warranted to be free from defects in material warranty. and/or workmanship for a period of 1 year from date of original •... -
Page 2: Table Of Contents
Ordering Parts and Service ..... . . 16 Model 247SL Exploded View ..... . 17 Model 248SL Exploded View . -
Page 3: Installation
Before first use, clean and condition the platens (see Conditioning Platens). Setting the Controls The model 247SL & 248SL Toaster Grills provide two modes of operation: DEDICATED MODE and PRODUCT MODE. • DEDICATED MODE is a simple mode of operation for toasting buns, with a set toast time and temperature for one product “BUN1”. - Page 4 Toaster Grills Models 247SL & 248SL Product Selection (Product Mode Only) Press and release any of the four numbered buttons (i.e., 1, 2, LEDs 3 or 4) to select the product associated with that button. (See Figure 2.) The LED above the selected Product button glows steady green to indicate the current selection and the display will show the selected product’s name.
-
Page 5: View/Change Set Temperature
Toaster Grills Models 247SL & 248SL Resetting to Factory Presets To reset all settings to factory presets, at power-on immediately (within 3 seconds) press and hold the LOGO, UP and DOWN buttons simultaneously until the display shows “PSET”. Release all buttons. After about 10 seconds, the unit will operate with factory preset temperature, time and display name values. -
Page 6: View/Change Set Toasting Time
Toaster Grills Models 247SL & 248SL To Change the Set Temperature NOTE: While the unit is adjusting to the new set temperature, Press the button(s) used to view the set temperature. the product name flashes in the display. In the Dedicated Hold the button(s) for 6 seconds. - Page 7 Toaster Grills Models 247SL & 248SL In Dedicated Mode: Dedicated Mode Press and release the TIME button. The display will show the present toasting time for “BUN1”. In either mode, after 3 seconds the display will return to showing the currently selected product time. (See Figure 10.)
-
Page 8: View/Change Duty Time Alarm
Toaster Grills Models 247SL & 248SL View/Change Duty Time Alarm A. Press and hold the LOGO button. Immediately press Press and release the UP or DOWN buttons to change the TIME button. the currently selected product’s duty time. B. Release all buttons. The display will show the present When finished, press and release the TIME button to save duty time for “BUN1”... -
Page 9: View/Calibrate Platen Temperature
Toaster Grills Models 247SL & 248SL View/Calibrate Platen Temperature Important! Do NOT perform this procedure until the Toaster Grill has been on for at least 45 minutes. and the temperature has stabilized. Do NOT use the Toaster Grill during the first 45 minutes. - Page 10 NOTE: A yellow temperature port is located on the back of the A. Plug an external temperature meter into the external 247SL Model, behind the platen (same as the Lower External port of the heater platen. Port in on 248SL Model figure above). (See Figure 16.) B.
-
Page 11: Change Product Name (Product Mode Only)
Toaster Grills Models 247SL & 248SL Change Product Name (Product Mode Only) Place the Toaster Grill in PRODUCT MODE (refer to When the desired character is displayed in the first “Mode Selection”). position, release the UP or DOWN arrow, and press and release button 3 to move on to the second display Press one of the four numbered buttons (i.e., 1, 2, 3 or 4) -
Page 12: Adjusting Bun Crush Settings
Toaster Grills Models 247SL & 248SL Adjusting Bun Crush Settings To adjust the bun crush settings, use the knob located on the front of the unit’s base. There are 10 incremental settings, each increasing the center gap by approximately 2 mm. -
Page 13: Conditioning The Platens
Toaster Grills Models 247SL & 248SL Conditioning the Platens A. Rub a generous amount of the Release Agent over the To minimize bun-sticking, the platens should be wiped entire surface of the platen until well coated. weekly with Toaster Grill Release Agent. -
Page 14: Cleaning
Toaster Grills Models 247SL & 248SL Cleaning A. Periodically and upon shutdown, use a clean, dry soft WARNING cloth to wipe down the Toaster Grill unit. Do Not Clean with Water Jet. B. When the platens are cool, you may also use a mild soap solution on a damp soft cloth to remove stubborn food remains, if necessary. -
Page 15: Troubleshooting Guide
Toaster Grills Models 247SL & 248SL Troubleshooting Guide WARNING WARNING SHOCK HAZARD! Live circuits are exposed! Use extreme Inspection, testing and repair of electrical equipment are to care during electrical circuit tests. Do NOT attempt any be performed by qualified service personnel ONLY. Unplug troubleshooting without proper authorization to do so. -
Page 16: Ordering Parts And Service
Center for credit, it is necessary that you: 1-800-722-7853 for assistance. A. Obtain authorization from your Service Center; B. Call your local Prince Castle Service Center. Fill in name B. Request Warranty fulfillment from your Service Center and number here: All Prices are F.O.B. -
Page 17: Model 247Sl Exploded View
Toaster Grills Models 247SL & 248SL Exploded Views Parts Breakdown Part No. Description Part No. Description 248-141S Overlay Kit 248-048S Safety Latch Kit * 248-140S Display Printed Circuit Board Kit 248-114S Knob Kit 66-017S Strain Relief Kit 248-045S Rear Bun Fence Kit... -
Page 18: Model 248Sl Exploded View
Toaster Grills Models 247SL & 248SL Parts Breakdown Part No. Description Part No. Description 248-141S Overlay Kit 248-048S Safety Latch Kit 248-140S Display Printed Circuit Board Kit 248-114S Knob Kit 66-017S Strain Relief Kit 248-045S Rear Bun Fence Kit 248-151S... -
Page 19: Model 247Sl Wiring Diagram
Toaster Grills Models 247SL & 248SL Wiring Diagrams Model 247SL 247-502revA-EN Printed in USA 10/06 © 2006... -
Page 20: Model 248Sl Wiring Diagram
Toaster Grills Models 247SL & 248SL Model 248SL Printed in USA 10/06 © 2006 247-502revA-EN...
