- Page 1 OWNER’S MANUAL LED TV * * LG LED TV applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. LY33** LY34** LY54** www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS LICENSES 20 SPECIFICATIONS OPEN SOURCE SOFTWARE 23 IR CODES NOTICE 24 EXTERNAL CONTROL ASSEMBLING AND DEVICE SETUP PREPARING 24 RS-232C Setup 24 Type of Connector: Unpacking D-Sub 9-Pin Male Separate Purchase 24 RS-232C Configurations Parts and Button 25 Communication Parameters Using the Joystick Button 25 Command Reference List Lifting and Moving the TV 26 Transmission / Receiving... -
Page 3: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 4: Assembling And Preparing
ASSEMBLING AND PREPARING NOTE Image shown may differ from your TV. Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual. The available menus and options may differ from the input source or product model that you are using. -
Page 5: Separate Purchase
Separate Purchase Separate purchase items can be changed or modified for quality improvement without any notification. Contact your dealer to buy these items. These devices only work with certain models. LG Audio Device LED Clock LEC-002 (Only LY54 series) The model name or design may be changed depending on the upgrade of product functions, manufacturer’s... -
Page 6: Parts And Button
ASSEMBLING AND PREPARING Parts and Button Screen Speakers Remote control sensor Power Indicator Joystick button (* This button is located below the TV screen.) NOTE You can set the power indicator light to on or off by selecting OPTION in the main menus. -
Page 7: Using The Joystick Button
ASSEMBLING AND PREPARING Using the Joystick Button You can simply operate the TV functions, pressing or moving the joystick button up, down, left or right. Basic Functions When the TV is turned off, place your finger on the joystick button Power On and press it once and release it. When the TV is turned on, place your finger on the joystick button and press it once for a few seconds and release it. -
Page 8: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and Moving the TV y When transporting a large TV, there should be at least 2 people. y When transporting the TV by hand, hold the TV When moving or lifting the TV, read the following to as shown in the following illustration. prevent the TV from being scratched or damaged and for safe transportation regardless of its type and size. -
Page 9: Setting Up The Tv
ASSEMBLING AND PREPARING Setting up the TV Attaching the Stand CAUTION When attaching the stand to the TV, place * Image shown may differ from your TV. the screen facing down on a cushioned table or flat surface to protect the screen from scratches. A Stand Base B Stand Base M4 x L14 (Except for 32LY33**, 32LY34**, 32LY54**) M4 x L20... -
Page 10: Mounting On A Table
* This feature is not available for all models. bracket on a solid wall perpendicular to the floor. When you attach the TV to other building materials, please contact qualified personnel. LG recommends that wall mounting be performed by a qualified professional installer. 10 cm 10 cm 10 cm... - Page 11 If you install the TV on a ceiling or slanted wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Do not over tighten the screws as this may cause damage to the TV and void your warranty.
-
Page 12: How To Use Dual Lock
ASSEMBLING AND PREPARING How to use Dual Lock™ (Only LY54**) Fix the set-top box to the TV and use it when you want to. 1 After removing the protection paper from the Dual Lock, stick it to the TV and the set-top box as shown. Dual Lock™... -
Page 13: Making Connections
MAKING CONNECTIONS MAKING Antenna Connection CONNECTIONS Connect the TV to a wall antenna socket with an RF cable (75 Ω). * Image shown may differ from your TV. * Any separate cable is not provided. This section on MAKING CONNECTIONS mainly uses diagrams for the LY33** models. Connect various external devices to the TV and switch input modes to select an external device. -
Page 14: Satellite Dish Connection
MAKING CONNECTIONS Satellite Dish Connection Network Setup (Only satellite models) Wired network connection Connect the TV to a satellite dish to a satellite (Only LY34**, LY54**) socket with a satellite RF cable (75 Ω). This TV can be connected to a Pro:Centric server /DVI IN via the LAN port. -
Page 15: Other Connections
MAKING CONNECTIONS Other Connections Connect your TV to external devices. For the best picture and audio quality, connect the external device and the TV with the HDMI cable as shown. ANTENNA/ * Image shown may differ from your TV. CABLE IN ANTENNA/ * Any separate cable is not provided. CABLE IN (Only Support Network Model) EXTERNAL OPTICAL EXTERNAL... - Page 16 MAKING CONNECTIONS OPTICAL OPTICAL TERNAL DIGITAL DIGITAL R OUT AKER OUT AUDIO OUT PCMCIA Card AUDIO OUT (RGB) (RGB) H/P OUT UDIO IN PCMCIA Card ANTENNA/ ANTENNA/ NENT/RGB/DVI) /RGB/DVI) Mobile Phone CABLE IN CABLE IN PCMCIA Card PONENT NENT PCMCIA Card RS-232C IN RS-232C IN RGB IN (PC)
-
Page 17: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons on the remote control. Please read this manual carefully and use the TV correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching ends to the label inside the compartment, and close the battery cover. - Page 18 REMOTE CONTROL (Only LY54**) (POWER) Turns the TV on or off. ꕊ ENERGY SAVING Adjusts the brightness of the screen to reduce energy consumption. ENERGY AV MODE INPUT AV MODE Selects an AV mode. INPUT Changes the input source. SAVING TV/RAD Selects Radio, TV and DTV programme. Number buttons Enters numbers.
-
Page 19: Maintenance
MAINTENANCE / TROUBLESHOOTING MAINTENANCE Cleaning your TV Clean your TV regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges. -
Page 20: Specifications
SPECIFICATIONS SPECIFICATIONS Product specifications may be changed without prior notice due to upgrade of product functions. 32LY33** 39LY33** 42LY33** MODELS 32LY330C-ZA 39LY330C-ZA 42LY330C-ZA Dimensions With stand (mm) 732 x 481 x 207 885 x 567 x 218 961 x 612 x 218 (W x H x D) Without stand (mm) 732 x 431 x 55.5... - Page 21 SPECIFICATIONS 47LY54** MODELS 47LY540H-ZA Dimensions With stand (mm) 1073 x 676 x 246 (W x H x D) Without stand (mm) 1073 x 629 x 55.8 Weight With stand (kg) 12.7 Without stand (kg) 12.3 Power requirement AC 100-240 V~ 50 / 60 Hz Power consumption 110 W CI Module Size...
- Page 22 SPECIFICATIONS RGB-PC, HDMI/DVI-PC Supported Mode HDMI/DVI-DTV Supported Mode Vertical Vertical Horizontal Horizontal Resolution Frequency Resolution Frequency Frequency (kHz) Frequency (kHz) (Hz) (Hz) 31.469 59.94 640 x 350 31.468 70.09 720 x 480 31.5 720 x 400 31.469 70.08 720 x 576 31.25 640 x 480 31.469...
-
Page 23: Ir Codes
IR CODES IR CODES * This feature is not available for all models. Code (Hexa) Function Note Remote control Button (Power On/Off) (POWER) TV/RAD Remote control Button Remote control Button SUBTITLE Remote control Button RATIO Remote control Button INPUT Remote control Button 10-19 Number Key 0-9 Remote control Button LIST Remote control Button Q.VIEW Remote control Button... -
Page 24: External Control Device Setup
EXTERNAL CONTROL DEVICE SETUP EXTERNAL CONTROL DEVICE SETUP RS-232C Setup RS-232C Configurations Connect the RS-232C (serial port) input jack to an exter- 7-Wire Configurations nal control device (such as a computer or an A/V control (Standard RS-232C cable) system) to control the product’s functions externally. Connect the serial port of the control device to the RS- EXTERNAL 232C jack on the product back panel. -
Page 25: Communication Parameters
EXTERNAL CONTROL DEVICE SETUP Communication Parameters Baud rate: 9600 bps (UART) Stop bit: 1 bit Data length: 8 bits Communication code: ASCII code Parity : None Use a crossed (reverse) cable. Command Reference List (Depending on model) (Depending on Model) DATA DATA COMMAND1 COMMAND2 (Hexadeci- COMMAND1... -
Page 26: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving Protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the TV.(j, k, m or x) [Command 2] : Second command to control the TV. [Set ID] : You can adjust the set ID to choose desired monitor ID number in option menu. Adjustment range is 1 to 99. - Page 27 EXTERNAL CONTROL DEVICE SETUP 01. Power (Command: k a) 04. Volume Mute (Command: k e) ► To control Power On/Off of the set. ► To control volume mute on/off. You can also adjust mute using the MUTE button on remote Transmission[k][a][ ][Set ID][ ][Data][Cr] control.
- Page 28 EXTERNAL CONTROL DEVICE SETUP 09. Tint (Command: k j) 13. Balance (Command: k t) ► To adjust the screen tint. ► To adjust balance. You can also adjust tint in the PICTURE menu. You can also adjust balance in the AUDIO menu. Transmission [k][j][ ][Set ID][ ][Data][Cr] Transmission [k][t][ ][Set ID][ ][Data][Cr] Data Red : 00 to Green : 64...
- Page 29 EXTERNAL CONTROL DEVICE SETUP 18. Tune Command (Command: m a) 16. Auto Configure(Command: j u) ► Select channel to following physical number. ► To adjust picture position and minimize image shaking auto- Transmission [m][a][ ][Set ID][ ][Data0][ ][Data1][ ][Data2][Cr] matically. It works only in RGB (PC) mode. Data00 : High channel data Transmission [j][u][ ][Set ID][ ][Data][Cr] Data01 : Low channel data...
- Page 30 EXTERNAL CONTROL DEVICE SETUP 22. Input select (Command: x b) (Main Picture Input) ► To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data Structure External Input Input Number External Input Data Analogue Component HDMI Input Number Data Input1 Input2...
- Page 31 The model and serial numbers of the TV is located on the back of the TV Record it below should you ever need service. Model Serial...
