- Page 1 INSTALLATION MANUAL LED LCD TV Please read this manual carefully before operating your set and retain it for future reference. LY54** www.lg.com Printed in Korea...
-
Page 2: Table Of Contents
EZ-Manager 2.1 - Introduction EZ-Manager Wizard - Automatically for Setup - Automatically for Setup (USB Configuration) - Manually for Setup INSTALLATION MENU Introduction LG Hotel Mode Setup TV manager - 1. USB - 2. Diagnostics Password Change Set ID Setup Configuration setup... -
Page 3: Ez Manager
EZ MANAGER EZ-Manager 2.1 - Introduction The Pro:Centric Platform enables you to simply install, manage and use guest-centric solutions. The default Domain "procentric.local" and IP Server Address are needed to be registered in DNS TV will contact the IP Server using the default Domain "procentric.local" via IP on server search page. If TV doesn't contact the Server, TV will search the pre-defined channel earlier than all channels (DVB-C only) The frequencies of pre-defined channels are ‘794000, 714000, 634000, 554000, 474000, 394000,... - Page 4 EZ-Manager Wizard - Automatically for Setup 1. Select a Label and/or enter the Room Number using the numeric keypad on the remotes. To continue, move and select 'Next'. 2. This step automatically searches for the Pro:Centric Server. If was found the Pro:Centric data channel, select the "Next". 3.
- Page 5 Current : 02.00.00.01 EPK : 02.00.00.01 [LOGO] 1360X768.jpg [ Forced Update Option ] [EPK] M1A_DVB_CN_RevNo1901_V02.0... SPI Boot LG Boot Logo LG Boot Logo LG Boot Logo Apply Previous * If you have USB Memory for "lgsmartinstall" or "LGSMARTINSTALL" folder, this step automatically searches for the USB file list page.
- Page 6 EZ-Manager Wizard - Manually for Setup 1. Select a Label and/or enter the Room Number using the numeric keypad on the remotes. To continue, move and select 'Next'. 2. Please select the 'Manual Pro:Centric’. 3. Select the Pro:Centric Mode "GEM" or "Flash".
- Page 7 3. Downloading the Pro:Centric application files takes few minutes. 4. After the installation is completed, the following screen will be displayed.
-
Page 8: Installation Menu
The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’. The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators. -
Page 9: Lg Hotel Mode Setup
Previous S/W : 02.00.00.01 Micom : 02.14 Use the button to select the LG Hotel Mode Setup. Use the OK button and then button to select Hotel Mode Operation. *When 'Hotel Mode Operation' is set to Yes(Work), all functions of Hotel Mode apply. - Page 10 Operation’ and ‘Local Key Operation’ will be worked by below. (4-1) IR Operation Decide whether work the LG remote control or not. y Able to set Normal, Use PWR Only, Block All. y When ‘IR Operation’ is set to Block All, all normal remote keys don’t work. Use PWR Only (Block except power) makes block all remote keys except power key.
- Page 11 (4-2) Local Key Operation Decide to operate 'Local/Front Key' working behavior by setting ‘Local Key Operation’ as Normal, Use PWR Only, Block All. y When 'Local Key Operation' is set to Block All, all local keys don’t work. If value is Use PWR Only, it blocks all local keys except power key.
- Page 12 (5-3) Programme Change Decide to change channel or not by setting ‘Program Change' as ‘Yes’(Change Possible) or ‘No’(Change Impossible) when present source is TV. y When ‘Programme Change' is set to No (Change Impossible) » Program Key, Numeral Key, List Key, Q.View Key don't work and entering 'Channel Menu' in the Main Menu OSD is impossible.
- Page 13 (6) Power Management The Power Management feature will turn off the television receiver if no input control command is received from either the Local or IR Key within a selected hours. y Activity on either of these inputs shall restart the ‘Power Management’ timer and check key time interval again.
- Page 14 (8-3) A/V Setting If ‘A/V Setting’ is changed from ‘No’ to ‘Yes’, parameters that are set before entering ‘Installation Menu’ are applied whenever turn on power. y Following Parameters are applied to basic. » Picture section - PSM mode, Picture Data (Contrast, Brightness, Color, Sharpness, Tint) »...
- Page 15 (11) Radio Video Blank Manage video blank channel(sound only). This feature affects on analog channel (ATV) only. (11-1) Start PR. No. y Start channel number to video blank. y Available programme to set are 0~199(For Taiwan : TV 2~69, CATV 1~199). (11-2) No.
- Page 16 Public Display Settings / LG Hotel Mode Setup (Value Range Table) Item Enable Disable Initial Hotel Mode Operation Power On Status *STD Volume Start Volume Off, Minimum Volume ~ Maximum Volume Maximum Volume Minimum Volume ~ 100 Minimum Volume 0 ~ Maximum Volume...
-
Page 17: Tv Manager
Plug USB memory card into the USB port of the TV. Use the button to select the TV Manager option and then press the OK button. Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager TV manager Password Change Set ID setup... - Page 18 SPI Boot or LG Boot Logo. If you checked the LG Boot Logo checkbox, then the Splash image, if selected, will be unchecked. Also, if you select the LG Boot Logo and proceed with the download, the existing Splash image will be deleted.
- Page 19 USB Cloning An Installer can quickly set up and clone multiple TV sets at a property. These cloned TVs will all have the same Master TV Setup: Public Display Mode Installation Menu settings, User A/V settings and the Channel Map. This newer procedure significantly decreases the installation time that would be necessary if the standard RS-232C method were used instead.
- Page 20 Plug USB memory card into the USB port of the TV. Use the button to select the TV Manager option and then press the OK button. Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager TV manager Password Change Set ID setup...
- Page 21 Plug USB memory card into the USB port of the TV. Use the button to select the TV Manager option and then press the OK button. Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager TV manager Password Change Set ID setup...
- Page 22 Use the button to select the TV Manager option and then press the OK button. RS-232C IN Installation Menu (V 3.0) (CONTROL & SERVICE) ▲ LG Hotel Mode Setup TV Manager TV manager Password Change Set ID setup Configuration Setup...
-
Page 23: Diagnostics
It checks and records good and bad channel signals, and then provides the signal information to a USB storage device in XML file format. Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager TV Manager TV manager... - Page 24 (3) Saving signal status information of digital channels through SignalTrace in XML format y Go to Installation menu -> TV Manager -> Diagnostics -> Diagnostics Setup y Set the level value in Signal Tracer Set. (Disable, 10 to 90) TV Manager Diagnostics Setup Diagnostics Setup Signal Tracer Set...
-
Page 25: Password Change
Password Change y Image shown may differ from your TV. - To ensure more security, Password can be changed by installers’ own design. Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager Password Change Password Change Set ID setup... -
Page 26: Set Id Setup
Set ID Setup Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager Set ID Setup Password Change Set ID Lock ◄ ► Set ID setup Set ID Set ID Configuration Setup Previous Multi Timer Lock Mode External Speaker... -
Page 27: Configuration Setup
Configuration setup y Image shown may differ from your TV. Installation Menu (V 3.0) ▲ Configuration Setup LG Hotel Mode Setup Number of RCU ◄ ► TV Manager Splash Offset Time + 0 sec Password Change USB Auto Playback Disable... - Page 28 (5) Auto Sensing y If 'Auto Sensing' is set to 'To Set ⊙ ', the input is automatically switched when the input signal that you set to 'ON' is received. y If 'Auto Sensing' is set to 'Disable', the input is not switched when the input signal is received. y If SIMPLINK is set to On, HDMI is automatically set to Disable and can not work.
- Page 29 RS-232C IN (CONTROL & SERVICE) (8) DTV Channel Update (This feature is not available for all models.) y It is a mode to set whether to update dtv channel automatically or not. When DTV Channel Update is set to ’Auto’, the function to update TV’s programme map according to dtv programme’s stream information.
-
Page 30: Multi Timer
Multi Timer Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager Password Change Multi Timer Set ID Multi Timer Configuration Setup ◄ ► On Timer Multi Timer Multi Timer Off Timer Lock Mode External Speaker Previous HCEC Setup... -
Page 31: Lock Mode
Lock Mode Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager Password Change Set ID Lock Mode Configuration Setup Enable Data Service ◄ ► Multi Timer Enable Lock Mode Lock Mode Enable Factory Reset External Speaker Previous HCEC Setup... -
Page 32: External Speaker
External Speaker Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager Password Change External Speaker Set ID Configuration Setup Volume Control ◄ ► Multi Timer 0.01 Watt Output Lock Mode Sound Out To Set External Speaker External Speaker... - Page 33 SimpLink is supported. y LG Sound Sync(Optical) : [Only available for models with an optical port] Connect LG audio device with the SoundSync logo to the optical digital audio output port. LG audio device allows you to enjoy rich powerful sound easily.
- Page 34 Speaker output SETUP Connect the external speaker to the external speaker out jack on the TV. EXTERNAL SPEAKER OUT RIGHT LEFT NOTE y External speaker must be used three plug(SE : Single Ended, Stereo) as shown in the drawings and external speaker fully inserted with external Speaker Jack.
-
Page 35: Hcec Setup
HCEC Setup Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager HCEC Setup Default Password Change CEC Mode ◄ ► Set ID IR Decoding Configuration Setup Device ID Multi Timer StandBy Lock Mode Forced Initialize External Speaker HTNG HotelMode... - Page 36 (c) Stand By y Sets the sending and receiveing scenario of OpStandBy(0x0c) command. y The detailed scenario is described on the table below. Send Receive Send Only Receive Only (d) Forced Initialize y If 'No' is selected, a command should be sent and received between the TV and a -device for proper initialization.
-
Page 37: Ir Setup
IR Setup Installation Menu (V 3.0) ▲ LG Hotel Mode Setup TV Manager IR Setup Password Change Paywall Disable ◄ ► Set ID Input Source Configuration Setup Programme Multi Timer Standard Lock Mode Ring 1 External Speaker Ring 2 HCEC Setup... - Page 38 (4) Ring 1 y Select Ring 1 programme by setting ‘Ring 1’ as ‘Yes’ or ‘No’. y When ‘Ring 1’ is set to Yes, the Programme works as a PPV programme which is shown using Ring1 card. y It is possible to set ‘Ring 1’ using ‘Green’ key of remote controller. (5) Ring 1 y Select Ring 2 programme by setting ‘Ring 2’...
-
Page 39: Network Setup
Network Setup y Image shown may differ from your TV. Installation Menu (V 3.0) ▲ Network Setup LG Hotel Mode Setup Network Setting Press OK TV Manager Network Status Press OK Password Change IGMP Version Set ID MAC Address CO :F6:41:BE:24: 3C... -
Page 40: Pro:centric
Pro:Centric y Image shown may differ from your TV. Installation Menu (V 3.0) ▲ TV Manager Pro:Centric Password Change Mode Flash ◄ ► Set ID WORF Configuration Setup Room Number Setting Press OK Multi Timer Media Type Lock Mode Receive data Enable External Speaker RF Type... - Page 41 (5) Receive data • Set to Enable or Diable. • If the setting is "Enable", receive data via RF or IP. • If the setting is "No", data carousel is not supported. It can be downloaded via only USB. (6) RF Type •...
-
Page 42: Power Saving
Power Saving y Image shown may differ from your TV. Installation Menu (V 3.0) ▲ Password Change Set ID Configuration Setup Power Saving Multi Timer 100(OFF) Static Saving ◄ ► Lock Mode Keyless Off Hours External Speaker Previous HCEC Setup IR Setup Network Setup Pro:Centric... -
Page 43: Clock Setup
Clock Setup y Image shown may differ from your TV. Installation Menu (V 3.0) ▲ Clock Setup Set ID Clock Display ◄ ► Configuration Setup Dimming Standby Multi Timer Dimming PowerOn Lock Mode Clock Source External Speaker Input HCEC Setup Program/Frequency IR Setup Network Setup... - Page 44 NOTE y Options of Clock Display, Dimming Standby and Dimming PowerOn are only available for the models that support the external LED clock. y For clock setup, select 'YES' for Clock Display only if the LED clock is connected to your TV. If you do not use the LED clock, select 'NO' for Clock Display.
-
Page 45: Download Extra Contents
DOWNLOAD EXTRA CONTENTS Download Extra Contents(flash file) toTV set The Pro:Centric application can be downloaded to your TV. FLASH ( * .SWF) / GEM supporting file An SWF file complied with Flash Lite 3.0 or earlier (the 3.0 version is recommended) •... - Page 46 You can see a new Application File on TV. Continue to replace ‘Extra Contents’ with one in USB memory? Select ‘Yes’. MENU INPUT Wait till the download process is completed. After completion of download, TV set will restart automatically. TV is in updating process. Please wait for a while.
