- Page 1 C365-5G-Mini COMMS365 5G Router USER MANUAL C365-5G-Mini User Manual CB-V1 .1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 2: Table Of Contents
3.5.2 VRRP............22 C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 3 3.6.10 Switch............53 C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
- Page 4 3.6.15 QoS............57 C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 5: Hardware Installation
2. Hardware Installation This chapter mainly describes the appearance, model and function of the C365-5G-MINI series and how to install and set the configurations. Dimensions Accessories Installation 2.1 Overall Dimension 2.2 The Ports C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 6: Installation
Wi-Fi antenna for GPS antenna 2.3 Installation The C365-5G-MINI should be installed and configured properly before using. The installation and configuration should be done under supervision or by a qualified engineer. Attention: Do not install or connect/disconnect the cable when its power is turned on. -
Page 7: The Installation Of The Terminal Block
2.5 The installation of the terminal block Only applicable if the router requires a terminal block. The C365-5G-MINI is provided with a DB9 connector as standard. Please use the DB9 cable to connect the C365-5G-MINI and the equipment directly. The following is for use with a terminal block: The C365-5G-MINI uses a pluggable terminal to connect the user’s data and the power supply. -
Page 8: Grounding
2.7 Power Supply The C365-5G-MINI can be used in difficult environments and usually the power range is very large. So, in order to overcome troublesome environments and improve the stability of the system, the C365-5G-MINI is designed with advanced power management technology. The DC power supply to the device is transferred using the terminal, PIN 2(GND) and PIN 1(Vin). -
Page 9: Software Configuration
How to config the web 3.1 Overview The C365-5G-MINI router has a built-in WEB interface configuration, management and debugging tools. The parameters require configuring first; these parameters offer flexibility for software upgrades and testing. Users can set up and manage the parameters of the router on its interface, detailed steps are below: 3.2 How to log into the Router... - Page 10 Set the PC IP as 192.168.1.xxx (xxx = 2~254), subnet mask: 255.255.255.0, default gateway: 192.168.1.1, primary DNS: 192.168.1.1. Option 2) DHCP Choose “Obtain an IP address automatically” and “Obtain DNS server address automatically”. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
- Page 11 Open the Web Browser, and type http://192.168.1.1 into the address field and press Enter. • Type Username “admin” and Password “admin” in the Login page, and then press the “Login” button. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 12: Router Status
The password can be changed using the setup wizard. See page 19. 3.3 Router status 3.3.1 Status overview Click “Status” in the navigation bar, and then click “Overview”. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 13: Network Status
3.3.2 Network status The network status page shows detailed information of the cell mobile interface, WAN and LAN. Cell mobile interface page: WAN status page: LAN status page: C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 14: Firewall Status
This page shows the system log from initial system boot up. The system log is not saved when the router restarts. It can be exported by clicking the “Export syslog” button. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 15: Kernel Log
This page shows the Kernel log from the system boot up. This log is not saved when the router restarts. It can be exported by clicking the “Export syslog” button. 3.3.7 Realtime graphs The real time graphs page shows real time system load, interfaces, traffic, etc. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 16: System Configuration
Displays system time, and the user can Sync this time with the browser by clicking the “Sync with browser” button. • Hostname This is the router’s name; the default name is Cell Router. • Time zone Select a suitable time zone. The default value is UTC. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 17 Log level, the default setting is debug which is the highest level, Emergency is the lowest level. • Cron log level This is the log level for process Cron. • Language The default language is set to “Auto”. The user can choose English or Chinese. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 18: Password
This is the NTP server list, multiple NTP servers are accepted. The user can click the button to delete an entry or click the button to add a new entry. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 19: Backup/Restore
The router will do a basic check of the uploaded file. If it is not a compatible file, an error will be generated. For example: If the firmware file is OK, a verification page will appear, then click the “Proceed” button, and the system will restart. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 20: Reset
Reset all the configurations back to factory settings. After clicking the “Reset” button, a window will appear, click the “cancel” button to cancel. click the “OK” button to continue. 3.4.8 Reboot Click the “Reboot” button and the system will restart in several seconds. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 21: Services Configuration
Action when failed: there are two options. “Restart module” and “Restart router”. “Restart module” will fix the problem on the radio module, and “Restart router” will fix the problem on the whole system including the radio module. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 22: Vrrp
1 and 255. • Priority: Routers with the highest priority in the same VRRP cluster will act as the master. The required number is between 1 and 255. 3.5.3 Failover (link backup) C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 23: Dtu
3.5.4 DTU Notes: 1) This feature is for C365-5G-MINI models with the DTU option. 2) This feature conflicts with the “Connect Radio module” and “GPS send to serial” option. Please disable the “DTU” feature if you wish to continue using the “Connect Radio Module” or “GPS send to serial”... -
Page 24: Snmp
If the centre is not required, the user can click the “Delete” button to delete it, or set it to be disabled. Notes: The maximum number of DTU centre is 32. 3.5.5 SNMP C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 25 • Encryption password: SNMPv3 encryption password, at least 8 characters are required. After all items are setup, then click the “Save & Apply” button to enable the SNMP functionality. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 26: Gps
It will just send the received GPS signal to your GPS processor device or server. If the GPS processor device is connected to the C365-5G-MINI Router via the Serial Port, then please choose “Serial”. If the GPS processor device is a remote server, please choose “Serial”. -
Page 27: Sms
Wi-Fi on Command: Enter the command for turning on the Wi-Fi. For the SMS feature, please keep the parameter as default. • Wi-Fi off Command: Enter the command for turning off the Wi-Fi. For the SMS feature, please keep the parameter as default. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 28 • Delete Phone number: Click the “Delete” button. • SMS command: Enable the SMS command feature on this phone number. • SMS alarm: This phone number can receive SMS Alarm. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 29: Vpn
Pre-shared Keys: This is known as the PSK, the length is 16 to 32. • Local subnet: The subnet of the local subnet which connects to the IPSEC VPN. • Remote subnet: The remote subnet which connects to the IPSEC VPN. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 30: Pptp
This page displays a list of configured PPTP instances and their states. The user can click the “Edit” button to modify it or click the “Delete” button to delete an instance. PPTP Client configuration C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 31 ARP Proxy: If the remote IP has the same subnet as the LAN, then check it for an active connection. • Debug: For the PPTP server debug. The log can be monitored in the system log. • Username: The server authentication username • Password: The server authentication password. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 32: L2Tp
Set it to a value sufficient for a successful L2TP connection for you. The purpose is to ensure that the netifd sent the connect request yet xl2tpd failed to complete it without the netifd noticing. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 33: Openvpn
Note: for the Open VPN configuration page, you can hover the mouse over the title on item to get more help information. If the item that you require is not displayed then please check the “Additional Field” dropdown list at the bottom of page. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 34: Gre Tunnel
Remote Netmask: The remote LAN subnet mask • Local Tunnel IP: Virtual IP address. This cannot be in the same subnet as the LAN network. • Local Tunnel Mask: Virtual IP mask. • Local Gateway: C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 35: Ddns
Log to syslog: Writes log messages to syslog. Critical Errors will always be written to syslog. • Log to file: Writes detailed message to the log file. The file will be truncated automatically. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 36 Read the log file of DDNS. Note: If using the DDNS server (no-ip.com) please can you check the “Use HTTP Secure” box and enter “8.8.8.8” for the DNS-Server. Example as per below. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 37: Connect Radio Module
Serial parity: Options of none/odd/even • Serial databits: Options of 7 bits and 8 bits • Serial stopbit: Options of 1 bits and 2 bits • Serial Flow Control: Options of none/hardware/software C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 38: Network Configuration
1) If checked the ” Wired-WAN port acts as LAN “, the H685 does not have WAN RJ45 port. 2) Please do not use any features for WAN RJ45 if check the ” Wired-WAN port acts as LAN “ C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 39: Mobile Configuration
Username: Fill in the related parameters. Get this parameter from the SIM Card Provider or Carrier. Notes: If your SIM card has no username, please input our default value, otherwise the router may not dialup. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 40: Cell Mobile Data Limitation
Warning percent of data used: If the used data reaches this percentage, a data limitation alarm SMS will be sent. • Used(MB): The data has been consumed during this period. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 41: Lan Settings
Use built-in IPv6-management: The default is checked. If IPv6 is not needed, it can be set to be unchecked. • Override MAC address: Override the LAN MAC address. • Override MTU: Maximum Transmission Unit. • Use gateway metric: The LAN subnet’s metric to gateway. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 42 IPv4-Netmask: Override the netmask sent to clients. Normally it is calculated from the subnet that is served. • DHCP-Options: Define additional DHCP options, for example ‘6,192.168.2.1,192.168.2.2’ which advertises different DNS servers to clients. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 43: Wired-Wan
Protocol: The default protocol is a DHCP client. If it should be changed to another protocol, such as PPPoE, select protocol PPPoE, then click the “Switch protocol” button. After this click the “Switch protocol” button, as shown below: C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 44: Wi-Fi Settings
Edit: Modify detailed information of the wireless network. • Remove: Delete a wireless network. • Associated Stations: This is a list of the connected wireless stations. 3.6.6.1 Wi-Fi General Configuration C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 45: Wi-Fi Advanced Configuration
Distance Optimization: Distance to farthest network member in meters. • Fragmentation Threshold • RTS/CTS Threshold 3.6.6.3 Wi-Fi Interface Configuration • ESSID: Extended Service Set Identifier. It is the broadcast name. • Mode: Supported options. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 46 Hide Extended Service Set Identifier: Hide SSID means this Wi-Fi cannot be scanned by others. • WMM Mode: • Encryption: • Key: This is the password to join a wireless network. If the encryption is set to “No Encryption”, no password is needed. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 47: Wi-Fi Ap Client
Step 4) Click submit if everything is configured. Below is the Wi-Fi configuration page. Don’t change the operating frequency, make sure the ESSID and BSSID is from the Wi-Fi you want to join. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 48: Interfaces Overview
Step 5) Click the “Save & Apply” button to start the AP client. 3.6.7 Interfaces Overview The Interfaces overview shows all interfaces status, including uptime, MAC-address, RX, TX and IP address. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 49: Firewall
Internal zone: The recommend zone is LAN. • Internal IP address: Redirect matched incoming traffic to the specific host. • Internal port: Redirect matched incoming traffic to the given port on the internal host. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 50: Traffic Rules
Source NAT list and create source NAT rule: Traffic rule configuration page: This page allows you to change the advanced properties of the traffic rule entry, such as matched source and destination hosts. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 51 Destination address: Traffic rule - check if the incoming packet’s destination IP address is the same. • Destination port: Traffic rule - check if the incoming packet’s TCP/UDP port is the same. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
-
Page 52: Dmz
3.6.8.5 Security • SSH access from WAN: Allow or deny users access of the C365-5G-MINI router from THE remote side. • Ping from WAN to LAN: Allow or deny ping requests from the remote side to the internal LAN subnet. -
Page 53: Static Routes
3. “Tagged” means the Ethernet frame transmits from this port with a VLAN tag. 4. “Off” means that this port does not belong to VLAN. For the default setting, port 0 belongs to VLAN1, but not to VLAN 2. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 54: Dhcp And Dns
Domain whitelist: List of domains to allow RFC1918 responses for. • Suppress logging: Suppress logging of the routine operation of these protocols • Allocate IP sequentially: Allocate IP addresses sequentially, starting from the lowest available address. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 55: Diagnostics
“Ping” button. Wait a couple of seconds, the result will be shown below. 3.6.13 Loopback Interface The default Loopback interface has an IP address 127.0.0.1, the user can change it here. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 56: Dynamic Routing
Note: How to configure these services? For example, the router’s LAN IP is 192.168.10.1. If you want to configure the OSPF, you will need to set the OSPF to “Enable” first, then open the PuTTy configurations in the below window.: C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... -
Page 57: Qos
QoS (Quality of Service) can prioritize network traffic by address, port or service. • Enable: Enable QoS on this interface. • Classification group: Specify class group used for this interface. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com... - Page 58 Ports: Packets matching this, belong to the bucket defined in the target. If more than 1 port is required, then they must be separated by a comma. • Number of bytes: Packets matching this, belong to the bucket defined in the target. C365-5G-Mini User Manual CB-V1.1 www.comms365.com | 01234 865880 | sales@comms365.com...
