Specifications for Gateway Solo™
5100 Multimedia Notebook
(Specifications are subject to change without notice or obligation.)
Processor
®
™
Mobile Pentium
Processor module with MMX
Technology at 133,
®
166, 200, 233, or 266 MHz or Pentium
II Processor module at 233
or 266 MHz
External cache: 256K or 512K SRAM Pipelined Burst L2 Cache,
write-back architecture
Core logic: Intel 440BX
System clock frequency: 66 MHz
BIOS: Phoenix Plug and Play NoteBIOS with DMI 2.0 support, 256K
Flash ROM
System memory
Main memory: 16 MB on board with two SO-DIMM sockets.
Accepts SDRAM modules, expandable to 144 MB, using one or two
modules of 16, 32, or 64 MB capacity
LCD panel
Size: 14.1" TFT, Resolution: XGA (1024 X 768), Color Depth:
65,536 colors (16-bit) at XGA
Video
Video subsystem: Chips & Technology 65555 high performance
multimedia flat panel/CRT GUI accelerator. Interface: 32-bit burst
mode PCI bus (Rev. 2.1 compliant) with 64-bit memory interface
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gateway Solo 5100
Summary of Contents for Gateway Solo 5100
- Page 1 Specifications for Gateway Solo™ 5100 Multimedia Notebook (Specifications are subject to change without notice or obligation.) Processor ® ™ Mobile Pentium Processor module with MMX Technology at 133, ® 166, 200, 233, or 266 MHz or Pentium II Processor module at 233...
- Page 2 External video: Supports simultaneous LCD/External monitor, variable sync for compatibility with a wide range of monitors, projector, and LCD projection panels Composite video output: Supports NTSC and PAL standards for composite video connection to standard NTSC/PAL device External resolutions/color depth: 640x480 at 16 million colors, 800x600 at 16 million colors, 1024x768 at 65,536 colors, 1280x1024 interlaced with 256 colors Video memory: 2 MB EDO...
- Page 3 2 DMA channels. Software Wavetable support Volume control: Rotary hardware control on left side of unit. Rotating wheel towards rear increases volume of internal speakers and speaker out connector. Specifications for Gateway Solo™ 5100 Multimedia Notebook...
- Page 4 Speakers: Two speakers built into palm rest Microphone: Omni-directional microphone at left side of palm rest at front of keyboard Connectors: Microphone in, line in, line out, headphone out Compression: ADPCM, ESPCM compression available for lower bit rates Physical specifications System unit weight: 6 lbs.
