Right View - Gateway NV75S02u Quick Start Manual

# Icon Item
4 HDMI port
5 USB 2.0 port
6 Microphone jack
Headphones /
7
speaker jack
R
IGHT VIEW
# Icon Item
1 USB port
2 Optical drive
Optical disk access
3
indicator
Optical drive eject
4
button
Emergency eject
5
hole
6 Ethernet (RJ-45) port
7 DC-in jack
10 - Quick start guide
Description
Supports high-definition digital video
connections.
Connect to USB devices (e.g., USB mouse,
USB camera).
Accepts inputs from external microphones.
Connects to audio line-out devices (e.g.,
speakers, headphones).
- Supports compatible 3.5 mm headsets with
built-in
handheld headsets).
1 2
Description
Connect to USB devices (e.g., USB mouse,
USB camera).
- If the port is black, it is USB 2.0 compatible,
if the port is blue (optional) it is also USB 3.0
compatible.
Internal optical drive; accepts CDs or DVDs.
Lights up when the optical drive is active.
Ejects the optical disk from the drive.
Ejects the optical drive tray when the computer
is turned off.
- Carefully insert a straightened paper clip to
eject the optical drive tray.
Connects to an Ethernet 10/100/1000-based
network.
Connects to your computer's AC adapter.
microphone (e.g.
3 4 5 6 7
Acer smart
