Summary of Contents for Iiyama ProLite XB2788QS-B1
- Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a...
- Page 3 IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands Model No. : PL2788Q We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com You can access the Web page of diff...
-
Page 4: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES..................4 CHECKING THE CONTENTS OF THE PACKAGE ......4 WALL MOUNTING ................5 FITTING AND REMOVAL OF BASE : ProLite XB2788QS ....6 FITTING AND REMOVAL OF BASE : ProLite X2788QS ....7 CONTROLS AND CONNECTORS : ProLite XB2788QS ....8 CONTROLS AND CONNECTORS : ProLite X2788QS....9... -
Page 5: For Your Safety
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fi re, electric shock or damage. - Page 6 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 7: Special Notes On Lcd Monitors
CUSTOMER SERVICE If you have to return your unit for service and the original packaging has been NOTE discarded, please contact your dealer or iiyama service center for advice or replacement packaging. CLEANING If you drop any materials or liquids such as water into the monitor when cleaning, WARNING unplug the power cable immediately and contact your dealer or iiyama service center. -
Page 8: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce. -
Page 9: Wall Mounting
WALL MOUNTING WARNING When you use with the wall mounting, in consideration of thickness of the mounting stage, tighten the M4 Screw with washer which “L” length is 7mm to fasten the monitor. Using the screw longer than this may cause electric shock or damage because it may contact with the electrical parts inside the monitor. -
Page 10: Fitting And Removal Of Base : Prolite Xb2788Qs
FITTING AND REMOVAL OF BASE : ProLite XB2788QS CAUTION Put the monitor on a stable surface. The monitor may cause injury or damage if it falls or is dropped. Do not give a strong impact to the monitor. It may cause damage. ... -
Page 11: Fitting And Removal Of Base : Prolite X2788Qs
FITTING AND REMOVAL OF BASE : ProLite X2788QS CAUTION Put the monitor on a stable surface. The monitor may cause injury or damage if it falls or is dropped. Do not give a strong impact to the monitor. It may cause damage. ... -
Page 12: Controls And Connectors : Prolite Xb2788Qs
CONTROLS AND CONNECTORS : ProLite XB2788QS <Front> <Back> Power Switch ( Power Indicator Blue: Normal operation NOTE Orange: Power Management Input / Select Button (INPUT/SELECT)* Scroll up / Audio Adjust Button ( Scroll down / i-Style Color Button ( / i )* Menu Button (MENU/EXIT) Speakers Keyhole for Security Lock... -
Page 13: Controls And Connectors : Prolite X2788Qs
CONTROLS AND CONNECTORS : ProLite X2788QS <Front> <Back> Power Switch ( Power Indicator NOTE Blue: Normal operation Orange: Power Management Input / Select Button (INPUT/SELECT)* Scroll up / Audio Adjust Button ( Scroll down / i-Style Color Button ( / i )* Menu Button (MENU/EXIT) Speakers Keyhole for Security Lock... -
Page 14: Connecting Your Monitor : Prolite Xb2788Qs
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. -
Page 15: Connecting Your Monitor : Prolite X2788Qs
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. -
Page 16: Computer Setting
COMPUTER SETTING Signal Timing Change to the desired signal timing listed on page 27: COMPLIANT TIMING. ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : ProLite XB2788QS For optimal viewing it is recommended to position yourself directly opposite to the full face of the monitor, then adjust the monitor’s height and angle to your own preference. -
Page 17: Adjusting The Viewing Angle : Prolite X2788Qs
ADJUSTING THE VIEWING ANGLE : ProLite X2788QS For optimal viewing it is recommended to look at the full face of the monitor. Hold the stand so that the monitor does not topple when you change the monitor’s angle. 3°... -
Page 18: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 27. You are also able to adjust the picture by following the button operation shown below. -
Page 19: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Input Select Direct Adjustment Item Problem / Option Button to Press Select the DVI input. HDMI Select the HDMI input. DisplayPort Select the DisplayPort input. Input Select Search for an available input source and select AUTO automatically. However it will automatically be selected when just one source is using. - Page 20 Picture Adjustment Item Problem / Option Button to Press Too dark Brightness * Too bright Too dull Contrast * Too intense You can change the picture quality from 0 to 100 (soft to sharp). Press the Button to change the picture quality in numerical order.
- Page 21 Audio Direct Adjustment Item Problem / Option Button to Press Too soft Volume Too loud Turn off the sound temporarily. Mute Direct Return the sound volume to the previous level. Off Line-In Select the Line-In input. Audio Input * HDMI Select the HDMI input.
- Page 22 Color * Adjustment Item Problem / Option Button to Press Warm Reddish white Greenish white Normal Cool Bluish white Too weak User Color Green Too strong Blue Return to a state set by color adjustment except Off i-Style Color. For general windows environment and monitor Standard default setting.
- Page 23 Language Adjustment Item Problem / Option Button to Press English English Česky Czech French Russian Français Русский Deutsch German Japanese Language Nederlands Dutch Simplifi ed Chinese Polski Polish Traditional Chinese Italiano Italian OSD Settings Adjustment Item Problem / Option Button to Press OSD is too left OSD H.
- Page 24 The FreeSync function on HDMI is turned off . iiyama Logo displayed when the monitor is turned on. Opening Logo iiyama Logo does not display when the monitor is turned Off The Power Indicator is turned On. The Power Indicator is turned Off .
- Page 25 ● Lock Mode <OSD Menu> 1. The OSD lock will be activated by pressing the front buttons MENU and for about 5 seconds. If you try to access the OSD by pressing any of the buttons MENU, and INPUT, message "OSD Locked"...
-
Page 26: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below. -
Page 27: Trouble Shooting
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem... -
Page 28: Recycling Information
A strange noise The Audio Cable is properly connected. is heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. 24 TROUBLE SHOOTING / RECYCLING INFORMATION... -
Page 29: Appendix
APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS : ProLite XB2788QS Size Category 27" Panel technology IPS Panel Technology Size Diagonal: 27" (68.5cm) Pixel pitch 0.233mm H × 0.233mm V Brightness 350cd/m (Typical) Panel Contrast ratio 1000 : 1 (Typical), Adv. -
Page 30: Specifications : Prolite X2788Qs
SPECIFICATIONS : ProLite X2788QS Size Category 27" Panel technology IPS Panel Technology Size Diagonal: 27" (68.5cm) Pixel pitch 0.233mm H × 0.233mm V Brightness 350cd/m (Typical) Panel Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left : 89 degrees each, Up / Down: 89 degrees each (Typical) Response time 5ms (Gray to Gray) DVI : Approx. -
Page 31: Dimensions : Prolite Xb2788Qs
DIMENSIONS : ProLite XB2788QS 643.5mm/25.3” 54.5mm/2.1” 599.5mm/23.6” 300.0mm/11.8” ) : Maximum adjustment range * Protruding portion(s) not included. DIMENSIONS : ProLite X2788QS 643.5mm/25.3” 54.5mm/2.1” 599.5mm/23.6” 270.0mm/10.6” * Protruding portion(s) not included. APPENDIX 27... -
Page 32: Compliant Timing
COMPLIANT TIMING Horizontal Vertical Video Mode Dot Clock Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 640 × 480 37.500kHz 75.000Hz 31.500MHz 37.879kHz 60.317Hz 40.000MHz SVGA 800 × 600 46.875kHz 75.000Hz 49.500MHz 48.363kHz 60.004Hz 65.000MHz 1024 × 768 60.023kHz 75.029Hz 78.750MHz VESA 63.981kHz 60.020Hz 108.000MHz SXGA...
