  • Page 1 1100T Series Wireless Translator INSTALLATION AND PROGRAMMING GUIDE...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS About the Translator ........1 Compliance Listing Specifications ..14 Learn Feature ............1 Commercial Fire ..........14 Tampers ..............1 Product Specifications ......15 Compatibility ............2 Full Compatibility Guide ........2 Patents ............15 Translator Features ........3 Accessories ..........
  • Page 5: About The Translator

    DMP. The 1100T is compatible with transmitters that operate at various MHz such as Interlogix, Honeywell 5800, 2GIG, and DSC. The translator operates with a wireless connection to a DMP receiver on a DMP panel and is available as an 1100T or 1100TF version. Learn Feature Tampers...
  • Page 6: Compatibility

    Compatibility • All DMP XT Series panels and XR Series panels with version 211 or higher • All 1100 Series Wireless Receivers with versions 207 or higher—excluding the 1100R Repeater Warning: The 1100T Wireless Translator is not compatible with systems using the 1100R Wireless Repeater.
  • Page 7: Translator Features

    TRANSLATOR FEATURES DMP Antenna Non-DMP Charge Status Survey LED Antenna MODEL 1100T +BAT- +12V- Green Status LED Status LED Tamper Switch Figure 1: Product Features Digital Monitoring Products, Inc. 1100T Wireless Translator Installation and Programming Guide...
  • Page 8: Pre-Installation

    PRE-INSTALLATION Before installing the translator, the DMP panel and receiver must already be powered on and set up in their final locations. See the panel and receiver guides for their installation information. INSTALL THE TRANSLATOR Wire the Power Supply The 1100T Wireless Translator can be powered from a 12 VDC external power supply. In addition to powering the translator, the power supply also charges the back-up battery.
  • Page 9: Program Device Setup

    Program Device Setup The translator must first be programmed as a device in Device Setup. Zones should be programmed in Zone Information. Go to DEVICE SETUP and press CMD. At DEVICE NO, enter the desired device number for the 1100T. Available addresses: •...
  • Page 10: Select A Location For The Translator

    Select a Location for the Translator The 1100T translator provides a Survey LED capability to allow one person to confirm communication with the panel while the cover is removed. While remaining in panel programming, hold the translator in the exact desired location.
  • Page 11 At DMP WIRELESS, select NO. At COMP WLS, select YES. At COMP WLS SRL #, either manually enter the serial number of the transmitter or transmit the serial number to the panel: • Manually: Press the first select key or area and type in the transmitter’s serial number.
  • Page 12: Mount The Translator

    Mount the Translator The translator must be mounted using the provided #6 screws in the four mounting holes. Mount the translator in a secure, dry place away from metal objects to protect the unit from damage due to tampering or the elements. Mount the translator a minimum of 4 feet from any wireless panels or receivers.
  • Page 13: Walk Test

    Walk Test To test the system, perform a standard walk test. Non-DMP wireless devices are not compatible with the DMP Wireless Walk Test. See the panel programming guides for more information. XR Series Panels Reset the control panel by placing and removing a jumper on RESET. At the keypad, enter 8144 (WALK).
  • Page 14 XT Series Panels Reset the control panel by placing and removing a jumper on RESET. From the keypad, enter 8144 (WALK). Select STD to test all programmed zones. Once in the Walk Test, walk around and trip each protective device. Continue tripping devices until the entire system is tested.
  • Page 15: Additional Information

    ADDITIONAL INFORMATION Replace the Battery DMP recommends replacing the battery every three years. Open the translator housing to expose the inside of the 1100T. Remove the PCB board Unplug the battery connector, then remove the old battery Connect the battery connector Snap the PCB Board back in place.
  • Page 16: Status Leds

    Status LEDs The green and red status LEDs in the lower right corner of the 1100T provide visual indication of DMP 1100 wireless synchronization status. • Green ON and red OFF indicates the 1100T is in sync with the DMP 1100 wireless receiver.
  • Page 17: 1100T Supported Zones

    1100T Supported Zones The supported zones per DMP panel are as follows: DMP PANEL AVAILABLE ZONES ZONE RANGES XTLplus and XTLtouch 1 - 99 XT50 with built-in receiver 11 - 14, 21 - 24, 31 - 34, 41 - 44, 51 - 54, 61 - 64, 71 - 74, 81 - 84, 80, 85 - 99 XT30 and XT50 (1100D Series) 11 - 14, 21 - 24, 31 - 34, 41 - 44, 51 - 54, 61 - 64, 71 - 74, 81 - 84 XR150 (1100X Series)
  • Page 18: Compliance Listing Specifications

    Battery The 9800BAT2400 provides 24-hour standby operation for Commercial Fire installations. Install the 1100TF in accordance with NFPA 70 and NFPA 72 Chapter 29. Supervision Time 1100T and Non-DMP Sensor supervision time must be set to 4 hours or less.
  • Page 19: Product Specifications

    Operating Voltage 12 VDC, 31 mA Standby Battery 1100T Voltage 3.7 VDC Type Lithium Polymer, rechargeable Capacity 800 mAh Standby 4 hours 1100TF Voltage 3.7 VDC Type Lithium Polymer, rechargeable Capacity 2400 mAh Standby 24 hours Frequency Range 905-924 MHz Dimensions 5.50”...
  • Page 20: Patents

    PATENTS U.S Patent No. 7,239,236 DMP Wireless Sensors ACCESSORIES 1100RBAT800/8 Replacement rechargeable battery (8 pack) 9800BAT2400/8 Battery for Commercial Fire (24-hour Standby) 505-12 12 VDC Power Supply 372-500-W Plug-In DC Power Supply ES501 Transformer Enclosure (4.25 W x 5.625 H x 2.5 D inches) ES502 Transformer Enclosure (4.25 W x 5.625 H x 3.75 D inches) 1100T Wireless Translator Installation and Programming Guide...
  • Page 21: Certifications

    Household Burglar Alarm System Units UL 2610 Commercial Premises Security Alarm Units and Systems ORDERING INFORMATION 1100T Wireless Translator 1100TF Wireless Translator with 24-hour standby battery for Fire Applications Digital Monitoring Products, Inc. 1100T Wireless Translator Installation and Programming Guide...
  • Page 22: Fcc Information

    FCC INFORMATION This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
  • Page 23: Industry Canada Information

    INDUSTRY CANADA INFORMATION This device complies with Industry Canada License-exempt RSS standard(s). Operation is subject to the following two conditions: This device may not cause interference, and This device must accept any interference, including interference that may cause undesired operation of the device. Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence.
  • Page 24 LT-2243 1.01 21132 © 2021 Digital Monitoring Products, Inc.
