1100T Wireless
Translator
INSTALLATION AND PROGRAMMING GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1100T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for DMP Electronics 1100T

  • Page 1 1100T Wireless Translator INSTALLATION AND PROGRAMMING GUIDE...
  • Page 3: Table Of Contents

    Select a Location for the Translator ..... 6 Program Zone Information ......6 Mount the Translator .......... 8 Walk Test..............9 Additional Information ......11 Replace the Battery ..........11 Status LEDs ............11 Non-DMP Sensor Supervision Time .... 12 1100T Supported Zones ........12...
  • Page 5: About The Translator

    ABOUT THE TRANSLATOR The 1100T Wireless Translator allows upgrades of non-DMP systems with one way, low frequency, wireless transmitters to DMP. The 1100T is compatible with transmitters that operate at various MHz such as Interlogix, Honeywell 5800, 2GIG, and DSC.
  • Page 6: Compatibility

    2GIG Series 345 MHz • DSC 433 MHz • Encryption from 1100T to DMP Receiver requires panel Version 211 or higher and Receiver Version 301 or higher Full Compatibility Guide For a full list of compatible non-DMP products, see the...
  • Page 7: Translator Features

    TRANSLATOR FEATURES DMP Antenna Non-DMP Charge Status Survey LED Antenna MODEL 1100T +BAT- +12V- Green Status LED Status LED Tamper Switch Figure 1: Product Features Digital Monitoring Products, Inc. 1100T Wireless Translator Installation and Programming Guide...
  • Page 8: Pre-Installation

    INSTALL THE TRANSLATOR Wire the Power Supply The 1100T Wireless Translator can be powered from a 12 VDC external power supply. In addition to powering the translator, the power supply also charges the back-up battery. If the DC power source is removed, the power failure is indicated as an open condition on the translator device number.
  • Page 9: Program Device Setup

    At 1100T? NO YES, select YES and press CMD. Enter the Serial number. At 1100T FREQ, press any select key or area to select the non-DMP system. Default is HWL (Honeywell). At SUPRVSN TIME, select the supervision time required for the 1100T. DMP default supervision time is 240 minutes.
  • Page 10: Select A Location For The Translator

    Select a Location for the Translator The 1100T translator provides a Survey LED capability to allow one person to confirm communication with the panel while the cover is removed. While remaining in panel programming, hold the translator in the exact desired location.
  • Page 11 At the transmitter supervision time, press a select key to choose from 0H, 4H (if zone type is FI, CO, or SUPV), 12H, or 24H. Default is 24H. 10. Save and exit programming. Digital Monitoring Products, Inc. 1100T Wireless Translator Installation and Programming Guide...
  • Page 12: Mount The Translator

    #6 screws to secure the 1100T to Mounting Hole the wall. Use one of the provided screws to secure the wall tamper. Figure 2: Inside of the 1100T Housing 1100T Wireless Translator Installation and Programming Guide Digital Monitoring Products, Inc.
  • Page 13: Walk Test

    Once in the Walk Test, walk around and trip each protective device. Continue tripping devices until the entire system is tested. Press the select key or area directly below END to stop the Walk Test. Digital Monitoring Products, Inc. 1100T Wireless Translator Installation and Programming Guide...
  • Page 14 Each time a FI, FV, SV, or CO zone trips, a Sensor Reset occurs. • Press the select key or area directly below END to stop the Walk Test. 1100T Wireless Translator Installation and Programming Guide Digital Monitoring Products, Inc.
  • Page 15: Additional Information

    Snap the PCB Board back in place. Snap the cover back on the 1100T. Status LEDs The green and red status LEDs in the lower right corner of the 1100T provide visual indication of DMP 1100 wireless synchronization status. •...
  • Page 16: Non-Dmp Sensor Supervision Time

    Default Supervision time for Non-DMP sensors is 24 Hours. Additional supervision times available include: • • 4 H - Fire, CO, or Supervisory zone type • 12 H Follow manufacturer guidelines for supervision times required on non-DMP sensors. 1100T Wireless Translator Installation and Programming Guide Digital Monitoring Products, Inc.
  • Page 17: Compliance Listing Specifications

    Commercial Fire Power Supply When using the Model 372-500-W plug- in power supply for Commercial Fire installations, mount the 1100T on a UL- listed gangbox and connect by conduit to a listed transformer enclosure such as the ES501 or ES502.
  • Page 18: Product Specifications

    5.50” W x 3.75” H x 1.00” D 13.97cm W x 9.53 cm H x 2.54 cm D Temperature 32 ° - 120 ° F Humidity PATENTS U.S Patent No. 7,239,236 DMP Wireless Sensors 1100T Wireless Translator Installation and Programming Guide Digital Monitoring Products, Inc.
  • Page 19: Accessories

    Control Units and Accessories for Fire Alarm Systems UL 985 Household Fire Warning System UL 1023 Household Burglar Alarm System Units UL 2610 Commercial Premises Security Alarm Units and Systems Digital Monitoring Products, Inc. 1100T Wireless Translator Installation and Programming Guide...
  • Page 20 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. 1100T Wireless Translator Installation and Programming Guide Digital Monitoring Products, Inc.
  • Page 21 Information furnished is believed to be accurate and reliable. This information is subject to change without notice. Digital Monitoring Products, Inc. 1100T Wireless Translator Installation and Programming Guide...
  • Page 22 1100T Wireless Translator Installation and Programming Guide Digital Monitoring Products, Inc.
  • Page 23 Digital Monitoring Products, Inc. 1100T Wireless Translator Installation and Programming Guide...
  • Page 24 LT-2243 1.01 21072 © 2021 Digital Monitoring Products, Inc.
