1100T WIRELESS TRANSLATOR
Installation Guide
DESCRIPTION
The 1100T Wireless Translator allows
upgrades of non-DMP systems with
one-way, low frequency, wireless
transmitters to DMP. The 1100T is
compatible with transmitters that
operate at various MHz such as
Interlogix, Honeywell 5800, 2GIG, and
DSC. The translator operates with a
wireless connection to a DMP panel.
Transmitters that have been learned
into the 1100T are able to send
supervision and low battery messages
to the panel.
Compatibility
• All DMP XT Series panels and XR
Series panels with version 203 or
higher
• All 1100 Series Wireless Receivers
with version ???? or higher
• Interlogix 319.5 MHz
• Honeywell 5800 345 MHz
• 2GIG Series 345 MHz
• DSC 433 MHz
Note: The 1100T is not compatible
with life safety devices.
What is Included?
• 1100T Wireless Translator
• 12 VDC Power Supply
• Hardware Pack
1
PROGRAM THE PANEL
Because the 1100T is a wireless device, all panel programming must
be completed in Device Setup and zones should be programmed in
Zone Information.
For XR Series Panels
Device Setup
1. Enter 6653 (PROG) at the keypad.
Press CMD and select DEVICE SETUP.
2.
At DEVICE TYPE, press CMD to display options.
3.
4. Press CMD again to open the extended options menu.
5. Select 1100T and press CMD to save.
6. Enter the Serial number.
At 1100T FREQ, select any select key or area to select the
7.
non-DMP system. Default is HWL (Honeywell).
8. Press CMD.
Zone Information
1. In ZONE INFORMATION, enter the wireless zone number.
At *UNUSED*, enter the zone name.
2.
3. Select a ZONE TYPE.
4. At DMP WIRELESS, select NO.
5. At COMP WLS, select YES.
6. At COMP WLS SRL #, you can manually enter the serial
number of the transmitter or transmit the serial number to
the panel:
Manually: Press top row key 1 and then begin typing the
transmitters serial number.
Transmit: To transmit the serial number, choose LRN at
prompt to display TRANSMIT NOW. Tamper the transmitter.
Once the panel has received the tamper signal, the serial
number will display.
7. Press CMD.
For XT Series Panels
Device Setup
1. Enter 6653 (PROG) at the keypad.
2. Press CMD and select DEVICE SETUP.
At 1100T? NO YES, select YES and press CMD.
3.
4. Enter the Serial number.
5. At 1100T FREQ select any select key or area to select the
non-DMP system. Default is HWL.
6. Press CMD.
Zone Information
1. In ZONE INFORMATION, enter the wireless zone number.
2. At *UNUSED*, enter the zone name.
3. Select a ZONE TYPE.
4. At DMP WIRELESS select NO.
At COMP WLS select YES.
5.
6. At COMP WLS SRL #, see Step 6 from the XR Zone
Information section above.
7. Press CMD.
