- Page 1 INSTALLATION MANUAL LED TV* Please read this manual carefully before operating your set and retain it for future reference. LY96** www.lg.com...
-
Page 2: Table Of Contents
EZ-MANAGER WIZARD - USB Download Menu LANGUAGE & COUNTRY SELECTION - Diagnostics Menu - Automatically for Setup - Manually for Setup - USB LG Smart Install Utility iNSTALLATiON MENu INTRODUCTION LG HOTEL MODE - Hotel Mode Operation - Power On Status... -
Page 3: Location And Function Of Controls
LOCATION AND FUNCTION OF CONTROLS LOCATiON ANd FuNCTiON OF CONTrOLS Parts and Button Screen Speakers Remote control and Intelligent sensors Power Indicator Joystick Button Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment. Joystick Button - This button is located below the TV screen. NOTE You can set the power indicator light to on or off by selecting general in the main menus. -
Page 4: Ezmanager
EZMANAGER EzMANAgEr y Image shown may differ from your TV. iNTrOduCTiON The Pro:Centric Platform enables you to simply install, manage and use guest-centric solutions. The default Domain “procentric.local” and IP Server Address are needed to be registered in DNS TV will contact the IP Server using the default Domain “procentric.local”... -
Page 5: Language & Country Selection
EZMANAGER LANguAgE & COuNTrY SELECTiON Confirm your location and language setting. Language ꕍ English Country ꕍ United Kingdom - Please select the Language and Country. Some countries need to select the Time zone. -
Page 6: Automatically For Setup
EZMANAGER Automatically for Setup From the TV Configuration Options screen, you can choose how to proceed with the configuration of this TV. Whether you will configure the TV for Pro:Centric operation via the wizard or use a USB memory device to configure the TV, you may first wish to set the Room Number on the TV. - If you intend to set Room Number as part of the TV configuration, use the Room Number option to assign the Room # for this TV before you continue with additional configuration. - Page 7 EZMANAGER This step automatically searches for the Pro:Centric Server. If was found the Pro:Centric data channel, select the ‘NEXT’.
- Page 8 EZMANAGER Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 9: Manually For Setup
EZMANAGER Manually for Setup Select a Label and/or enter the Room Number using the numeric keypad on the remotes or using the virtual keyboard on the TV screen. To continue, move and select ‘NEXT’. Please select the ‘MANuAL PrO:CENTriC’. - Page 10 EZMANAGER Configure the appropriate Pro:Centric settings in the TV.
- Page 11 EZMANAGER Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 12: Usb Lg Smart Install Utility
EZMANAGER uSB Lg Smart install utility Select the ‘uSB CONFigurATiON’ → ‘TV MANAgEr’. - If you have USB Memory for “LG_DTV” or “lg_dtv” folder, this step shows the USB file list for downloading the items. - Page 13 EZMANAGER Downloading the Pro:Centric application files takes few minutes. After the installation is completed, the following screen will be displayed.
-
Page 14: Installation Menu
The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’. The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators. -
Page 15: Lg Hotel Mode
TV Manager Radio Video Blank Use the button to select the Lg HOTEL MOdE SETuP. Use the ‘OK’ button and then button to select Hotel Mode Operation. - When ‘Hotel Mode Operation’ is set to Yes (Work), all functions of Hotel Mode apply. -
Page 16: Volume
INSTALLATION MENU Volume - Decide to apply volume policy of ‘Start Volume’, ‘Maximum Volume’ and ‘Minimum Volume’ as Yes(Work) or No(Do Not Work). - (0 ≤ Min ≤ Start ≤ Max ≤ 100) Start Volume y This entry sets the start volume level when is power on. - The level is specified as a number between minimum volume to maximum value. -
Page 17: Dtv Programme Update
INSTALLATION MENU - When 'Program Change’ is set to Yes(Change Possible), ‘Program Key’, ‘Numeric Key’, ‘List Key’, ‘Q.View’ Key does work and entering ‘Channel Menu' in the Main Menu OSD is possible. Menu display y Function to decide whether work with menu (including relevant menus too) of control key (Yes – Enter possible) or not (No –... -
Page 18: Radio Video Blank
INSTALLATION MENU radio Video Blank - Set to Yes(Work) or No(Do Not Work). - Programme that is set to ‘Radio Programme’ and only has Sound should decide whether to set ‘Video Blank’ or not. - When ‘Radio Video Blank’ is set to Yes(Work), ‘Video Blank’ works only in case of Radio Programme. -
Page 19: Network
INSTALLATION MENU NETWOrK NETWORK LG Hotel Mode MAC Address 12:34:56:78:12:34 Network ꕍ Network Setting Pro:Centric IP Stream Control Wake On LAN General Media Share TV Manager button to select the NETWOrK. Use the MAC Address - Displays the MAC address (not customizable). -
Page 20: Ip Stream Control
INSTALLATION MENU iP Stream Control Audio PTS Offset - Controlling output stream timing of audio. Video PTS Offset - Controlling output stream timing of video. Wake On LAN - Sets the Wake On LAN function to Enable or Disable. Use “Magic Packet”. -
Page 21: Pro:centric
INSTALLATION MENU PrO:CENTriC PRO:CENTRIC LG Hotel Mode ꕍ Mode Network Configuration Only WORF DISABLE Pro:Centric Room Number Setting ꕍ Media Type General Receive Data ENABLE Media Share ꕍ Data Channel Type DVB-C ꕍ Data Channel Freq(kHz) TV Manager ------ ꕍ... -
Page 22: Receive Data
INSTALLATION MENU y Data Channel Type - Sets the RF modulation type to DVB-T or DVB-C. The default value is DVB-T. y P:C IP Setting - It can be set using the or number buttons. (IP a) Sets the first number in the IPv4 address. (IP b) Sets the second number in the IPv4 address. -
Page 23: General
INSTALLATION MENU gENErAL GENERAL LG Hotel Mode Configuration Setup Network External Speaker Set ID Setup Pro:Centric Power Saving HCEC Setup General Clock Setup Password Change Media Share PreLoaded App Lock Mode TV Manager Confi guration Setup Select rCu - It is a mode to set whether to use Select RCU or not. When ‘Select RCU’ is set to ‘Enable’, You can adjust ‘Number of RCU’... - Page 24 INSTALLATION MENU y Type of Connector: D-Sub 9-Pin Male Signal Signal requirements RX RS232 Standard RS232 specification TX RS232 Standard RS232 specification IR from TV Power ground 6, 8 Not connected Male connector on box, +5VDC 10%, max 100mV ripple viewed towards connector.
-
Page 25: External Speaker
INSTALLATION MENU 15Min Auto Off - When ‘15Min Auto Off’ is set to ‘Enable’, TV will turn off if there is no signal in 15Min. Auto Sensing - If ‘Auto Sensing’ is set to ‘To Set ’, the input is automatically switched when the input signal that you set to “ON’... -
Page 26: Power Saving
INSTALLATION MENU Set id - Set the ‘Set ID’ of TV Set with 1~99. Power Saving Static Saving - It is the item for setting the level to reduce the backlight control from the items for saving the consuming power, which is increased or decreased by 10 steps from 0 to 100. 100 makes the consuming power set to the same one from the TV. -
Page 27: Clock Setup
INSTALLATION MENU StandBy - Set the sending and receiving scenario of OpStandBy(0x0c) command. - Ths detailed scenario is described on the table below. Send Receive Send Only Receive Only Forced initialize - This setting will be enabled When CEC mode is set as ‘TVLink-CEC’ - If ‘Enable”... -
Page 28: Password Change
INSTALLATION MENU Timezone(City) & Timezone(Offset) - In the case when there is difference between the time information received from the Teletext and the time of the current area, it can be set up to correct this. The initial value is 0, and it can be changed in the range of -12Hrs ~ +12Hrs. -
Page 29: Media Share
INSTALLATION MENU MEdiA SHArE MEDIA SHARE LG Hotel Mode SmartShare DISABLE Network Screen Share DISABLE DISABLE Pro:Centric ꕍ TV Name LG SMART+ TV General SoftAP DISABLE Use Default DISABLE Media Share ꕍ Security Key 00000000 TV Manager ► You can setting Whether to use for “SmartShare”... -
Page 30: Use Default
INSTALLATION MENU use default - If you want to use default password(this password was generated randomly), you must select ‘yes’ in this item. Security Key - When guests want to use TV’s SoftAP function, they need this password. If you want to change this default password, you need to Change ‘Use Default Setting’... -
Page 31: Tv Manager
INSTALLATION MENU TV MANAgEr uSB download Menu * uSB Cloning : An Installer can quickly set up and clone multiple TV sets at a property. These cloned TVs will all have the same Master TV Setup: Public Display Mode Installation Menu settings, User A/V settings and the Channel Map. - Page 32 INSTALLATION MENU Ez download - Ez Download is a function that enables users to download the desired items all at once, such as EPK (software update file), TLL (see Send to USB descriptions for more information regarding file types), Logo Image, etc (TLX, MICOM for Pro:Centric). Splash images and EPK files should be copied into the folder named LG_DTV on the USB.
- Page 33 INSTALLATION MENU Logo image download - If there are more than two USB Memory Device, It is possible to select the USB. - The download sequence is USB → filename → update. NOTE Splash Image update function supports only JPEG format file of less than 1 MB filesize. Except for JPEG images with progressive encoding.
- Page 34 INSTALLATION MENU update TV Software - This feature update EPK of TV through the hex file in USB. The target file is located in \lg_dtv folder. - If there are more than two USB memory Device, It is possible to select the USB. - The download sequence is USB →...
- Page 35 INSTALLATION MENU update Micom Software - This feature update MICOM of TV through the hex file in USB. The target file is located in \lg_dtv folder - If there are more than two USB memory Device, It is possible to select the USB. - The download sequence is USB →...
- Page 36 INSTALLATION MENU receive From uSB(TLL) - Once the internal TV data and its channel map information is written to the USB memory card, the user can start “Receive From USB” process with the data file generated and stored in USB memory card.
- Page 37 INSTALLATION MENU Send to uSB(TLL) - Send To USB” must be done first before “Receive From USB” process, as it generate the file to be used in “Send To USB”. While writing is in process, the user must not turn TV off nor unplug the USB memory card.
-
Page 38: Diagnostics Menu
INSTALLATION MENU diagnostics Menu This diagnostic function provides current status information of the TV in XML file format using a USB device. If the user sets a signal standard level, SignalTrace checks the signal strength status of the digital channel that the user tuned to. It checks and records good and bad channel signals, and then provides the signal information to a USB storage device in XML file format.
