- Page 1 MSI UB11BM (MS-6823A) Wireless 11b Internal USB Adapter User’s Guide...
-
Page 2: Fcc Caution
FCC Caution The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC RF Radiation Exposure Statement: The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. -
Page 3: Important Safety Precautions
Important Safety Precautions Always read and follow these basic safety precautions carefully when handling any piece of electronic component. Keep this User’s Guide for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equipment from overheating. - Page 4 Internet over your existing wireless network easily, without disassembling your computer. The UB11BM has a data rate up to 11Mbps, and can auto-negoti- ate to 5.5, 2, 1Mbps to be compatible with any IEEE 802.11b device.
- Page 5 >>> 1.2 How UB11BM Works Ad-hoc Mode : An Ad-hoc network is a local area network or other small network, especially one with wireless or temporary plug-in connections, in which some of the network devices are part of the network only for the duration of a communications session.
-
Page 6: Specifications
>>> 1.3 Specifications Form Factor USB 1.1, internal connector Operation voltage 5VDC (±0.5V) Standard IEEE 802.11b Frequency Range 2.4GHz to 2.497GHz Data Rate 1, 2, 5.5, and 11Mbps Network Protocol Support TCP/IP, NetBEUI, IPX/SPX Operating Channels - USA/Canada: 11 channels - Europe: 13 channels - Japan: 14 channels Media Access Protocol... -
Page 7: System Requirements
>>> 1.4 System Requirements Before installing the UB11BM, your PC should meet the following items: - One desktop/notebook PC with an available internal USB connector. - Windows 98SE/ME/2000/XP operating system. ® - Minimum 5MB free disk space for installing the driver and utilities. -
Page 8: Product View
>>> 1.6 Product View USB Connector... -
Page 9: Software Installation
Setup CD to copy files during the installation. Please NOTE that the UB11BM should be installed into your computer before installing the driver and utility. Then, the operating system will detect a new device and start to configure the new device. - Page 10 Step 1. Insert the software CD into your CD-ROM drive, and the Setup program should launch automatically. If the Autorun program doesn’ t launch automatically, click Start E:\setup.exe at the taskbar and select Run..Type (where your CD-drive) in the Open box and click OK to launch the Setup program manually.
- Page 11 Windows Setup CD during the installation. Please insert the Setup CD by the on-screen instruction to continue the installation. Click Finish when the installation is completed. The MSI Wire- Step 4. less LAN icon* will appear in the status area.
-
Page 12: Wireless Network Utility
Wireless Network Utility After installing the driver, MSI UB11BM provides a convenient and powerful utility that allows you to set up, configure, and know your networking status easily and clearly. >>> 4.1 Introduction The MSI Wireless LAN icon - Not connected to the network. - Page 13 If your MSI wireless LAN adapter supports Software AP function, you can see this item in the sub-menu, and which allows you to use your MSI wireless adapter as a virtual access point. For details, refer to the MSI Software AP/ Gateway User’s Guide.
