- Page 1 Installation Tuscany Hoods TVWH360, CTVWH360 TVWH480, CTVWH480 TVWH660, CTVWH660...
-
Page 2: Table Of Contents
Our hoods are equipped with variable speed control blowers. These units will not function with a single speed ventilator. All Viking Range ventilator kits are designed specifically for use with Viking Range hoods. -
Page 3: Warnings
7. CAUTION!: To Reduce the Risk of Fire and Electric Shock, Install this rangehood only with This appliance is not to be used by persons remote blower models manufactured by Viking (including children) with reduced physical, sensory Range, model numbers – DEV900/DEV1200,... -
Page 4: Dimensions & Specifications
Dimensions & Specifications 36" W 35-7/8" (91.1 cm) 48" W 47-7/8" (121.6 cm) " * ( 3 0 6 " ( 1 5 ( 4 5 " " ( 6 1 *NOTE: Optional duct cover sold separately. 18”H. Wall Hoods Description 36”... -
Page 5: Clearance Dimensions
Clearance Dimensions 12” (30.5 cm) *optional duct cover 18” (45.7 cm) 66” min (167.6 cm) 30” min (76.2 cm) 72” max (182.9 cm) 36” max (91.4 cm) 36” (91.4 cm) -
Page 6: Interior Ventilator Dimensions
Interior Ventilator Dimensions Top View 36" W 17-15/16" (45.6 cm) 36" W 35-7/8" (91.1 cm) 4-5/8" (11.7 cm) 7" (17.8 cm) dia. duct location *300 or 600 CFM Interior Ventilator Installation for all Wall Hoods Top View 36" W 17-15/16" (45.6 cm) 36"... -
Page 7: Exterior Ventilator Dimensions
Exterior Ventilator Dimensions Top View 36" W 17-15/16" (45.6 cm) 36" W 35-7/8" (91.1 cm) 48" W 23-15/16" (60.8 cm) 48" W 47-7/8" (121.6 cm) 5-15/16" (15.1 cm) 66" W 32-15/16" (83.7 cm) 66" W 65-7/8" (167.3 cm) 10" (25.4 cm) dia. -
Page 8: Planning Information
Planning Information Proper installation of ducting is extremely 300 or 600 CFM important to ensure maximum performance from Roof Cap single blower any ventilation product. interior-power 7” round duct typical ductwork • All CFMs are based on tests at 0.1 static pressure: without applying static pressure, CFM would be greatly overstated. -
Page 9: Installation
Installation ( 4 . 6 ” 1-1/2” x 3/4” Slot for (3.8 cm) x ( 1.9 cm) Wood strip 5/16” 5/16” wood strip Nut driver Nut driver Measure down 1-13/16 (4.6 cm) from desired height of Use additional mounting screws to secure hood to hood and secure 1-1/2”... -
Page 10: Duct Cover Option
Duct Cover Option Measure distance from ceiling to canopy. Slide the duct cover in place and fasten from inside canopy using the sheet metal screws provided. To install ventillation kit refer to ventillation kit installation instructions. -
Page 11: Service & Registration
• Name of dealer from whom purchased Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-(845- 4641), or write to:... - Page 12 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) or visit our web site at vikingrange.com in the US or brigade.ca in Canada F21448B EN (031517)
