- Page 1 STACYC model 18EDRIVE STACYC model 20EDRIVE O R I G I N A L I N S T R U C T I O N S S T A C Y C , I N C . 6 7 9 5 C O R P O R A T I O N...
-
Page 2: Table Of Contents
TABLE OF CONTENTS: Introduction ..........................Warnings/Cautions/Notes/Intended Use ................Specification Drawings Bike Specifications ....................Battery Specifications ....................Throttle Components & Features ................... LED Information Chart ......................Pre Ride Inspection & Checklist ....................Battery & Charger Charging The Battery ....................Battery Installation ....................Battery Removal ...................... -
Page 3: Introduction
STACYC™ will take your child and you to places you did not imagine were possible. However, before you and your child depart, please be sure to check and obey all local laws. - Page 4 We care about the safety and comfort of our customers. This manual will guide you through the proper techniques in operating your cycle. For any additional information, please visit:www.STACYC.com STACYC™ model 18EDRIVE and 20EDRIVE Read and understand this entire manual before allowing a child to use this product.
- Page 5 Children under 8 years of age should not use charger. No children should ride any cycle if they cannot sit on the seat and touch both feet flat on the ground at the same time. Because products, like cycles, can and do present potential hazards plainly asso- ciated with their use, it is well recognized THE NEED FOR EXERCISE OF PARENTAL RE- SPONSIBILITY IN SELECTING RIDING PRODUCTS APPROPRIATE TO THE AGE, SIZE AND DEVELOPMENTAL PROGRESS OF A CHILD, OR PARENTAL SUPERVISION IN SITUATIONS...
- Page 6 any local laws or regulations, which may affect the locations where the cycle may be used. Do not activate the speed control on the hand grip unless you are sitting on the bike with both hands gripping the handlebar, both feet flat on the ground, and ready to ride.
- Page 7 1. Handlebar: Aluminum bicycle handlebar 2. Handlebar Grip: Left side handlebar grip 3. Rear Brake Lever: Adjustable rear brake lever 4. Throttle: Twist type throttle with Battery Level indicator lights 5. Front fork: Aluminum Rigid or Suspension fork depending on model 6.
- Page 8 22. Drive sprocket: Proprietary steel drive sprocket 23. Drive motor: 18V electric motor 24. Electric Speed Controller (ESC): 18V, Electric Speed Controller 25. Motor Cage: Frame component housing motor 26. Stem: Aluminum bicycle stem, attaching the front fork to the handlebar 27.
-
Page 9: Throttle Components/Features
THROTTLE COMPONENTS/FEATURES: Power Button Throttle grip Rotation ◀ Battery level LED Power Button Power Button No illuminated light when “OFF” Illuminated light when “ON” LED → GREEN LED → YELLOW LED → RED P a g e |... -
Page 10: Led Information Chart
LED INFORMATION POWER SITUATION/ REACTION BUTTON INDICATOR cycle powered off NONE NONE battery not charged NONE NONE POWER cycle powered on and in “LOW/TRAINING” BUTTON power mode cycle powered on and in “MEDIUM” POWER YELLOW power mode BUTTON cycle powered on and in “ADVANCED/FAST” POWER GREEN power mode... -
Page 11: Pre Ride Inspection & Checklist
PRE-RIDE INSPECTION & CHECKLIST: Never ride your cycle on public streets, roads, highways, at night or when visibility is limited. Inspect cycle for damage. Do not ride a damaged cycle. Power Button: Ensure the Power switch is in the “OFF” position during the Pre-Ride Inspection and remains “OFF”... -
Page 12: Charging The Battery
CHARGING THE BATTERY: Remove the battery from the cycle. Plug the charger into an outlet and slide the battery into place on charger. New batteries can take longer to charge. Allow the battery to charge until the green LED is solid before removing the battery from the charger. A flashing green status LED indicates the battery is in the final stage of charging which includes cell balanc- ing, which is very important to the life of the battery. -
Page 13: Battery Installation
BATTERY INSTALLATION: Note: The cycle should be turned OFF and the battery removed when unit is not in use. If the power switch is left on, the battery loses its charge. 1. Locate battery and orient as shown, it is easier if you turn the handlebars left or right 45 degrees. - Page 14 THROTTLE OPERATION: (Confirm Speed Mode & Check Battery Level) Operation of throttle is only for those supervised by an adult. In no circumstances should a child be allowed to operate the cycle without proper training and super- vision. If the child cannot walk, run, coast and brake, they are surely not ready for throttle control.
-
Page 15: Changing Power Modes
6. Exercise caution around moving parts and wheels. 7. Contact customer service or go visit: www.STACYC.com if unsure about any operational procedure. CHANGING POWER MODES (TO BE PERFORMED BY ADULTS ONLY) Your cycle is equipped with 3 power modes for different skill levels. - Page 16 Power Button”ON” Throttle→”FULL” position LED→flashing GREEN Power Button”OFF” Power Button”ON” 5 Green flashes with 5 beeps, all Throttle→”FULL” position Throttle→”FULL” position LEDS stay lit, release throttle, all HOLD THROTTLE IN FULL LED→flashing YELLOW LED lights off, ready to choose POSITION 5 yellow flashes power model Select Program:...
- Page 17 P a g e |...
-
Page 18: The Starting Process
THE STARTING PROCESS: SIT, PUSH, COAST, BRAKE, PRACTICE (Perform under adult supervision, wearing protective equipment, in an open and safe area) Non-powered training: (Turn Power Button to the “OFF” position and remove battery) 1. Sit on bike with feet on ground. Familiarize rider with seat, foot platform, brake(s), handlebars , throttle and their function. - Page 19 Turn Power Button to the “ON” position. YELLOW Ensure LED is lit, indicating “Standard Mode” selected. If not, see Throttle operation and Changing Power Mode sections in this manual. Adult should supervise child as the top speed and acceleration have both increased in this mode. The child must demonstrate the ability to roll off throttle and use the brake to slow to a stop, and maintain a safe distance for obstacles and other riders.
- Page 20 WARNING: DO NOT OVER TIGHTEN Tighten stem bolts with 6mm Allen to 45 IN-LBS (5Nm) WARNING: DO NOT OVER TIGHTEN Replacement Parts: For the complete selection of replacement parts visit www.STACYC.com. Repair Centers: For a list of authorized service centers visit www.STACYC.com. Test Brake: 1.
- Page 21 Remove Allen and washer. Remove Drive Sprocket Remove Sprocket Hub Inspect Polymer Insert(s) If compressed, torn, severed, or otherwise distorted contact STACYC or authorized dealer for replacement parts Re-Insert Polymers into Sprocket Hub Align Drive Sprocket on Sprocket Hub Using 3 Pins...
-
Page 22: Repair & Maintenance
Note: Chain may be greasy and dirty. Turn power switch to “OFF” position, remove battery, allow cycle to cool before beginning repair or maintenance: Ensure the power button is “OFF”. Ensure the battery is removed and cycle has had adequate time to cool. (up to 30 minutes) Secure the cycle for repair or maintenance. -
Page 23: Error Codes
Note: Low seat height is recommended. Low seat height allows the operator to easily reach the ground for more secure footing, and increases rider confidence. Battery and Battery Disposal: Refer to battery manufacturer documentation for proper battery maintenance. Battery Disposal: Your cycle uses sealed lithium cell batteries which must be recycled or disposed of in an environmentally safe manner. - Page 24 Service Center in your area, visit our website at www.STACYC.com PRODUCT PARTS: Visit www.STACYC.com for information on spare part availability. (Illustrations may not reflect exact appearance of actual product, specifications subject to change without notice.) P a g e |...
-
Page 25: Warranty
NOTICE: YOUR INSURANCE POLICY MAY NOT PROVIDE COVERAGE FOR ACCIDENTS INVOLVING THE USE OF THIS RIDE-ON PRODUCT. TO DETERMINE IF COVERAGE IS PROVIDED, YOU SHOULD CONTACT YOUR INSURANCE COM- PANY OR AGENT. LIMITED WARRANTY The manufacturer warranties this product to be free from material and manufacturing defects from date of purchase as described below. - Page 26 For additional information, please visit: www.STACYC.com P a g e | P a g e |...
