Summary of Contents for Tricity Bendix DSiE328W
- Page 1 OPERATING AND INSTALLATION INSTRUCTIONS MODEL NO. DSIE328...
-
Page 2: Technical Details
TECHNICAL DETAILS MODEL NO. DSIE328 Voltage: 230/240 Volts AC 50Hz Wattage: 10.2/11.1kW Height: 900mm Width: 500mm Depth: 600mm Weight: 55kg This appliance complies with: European Council Directive 73/23/EEC. EMC Directive 89/336/EEC. CE Marking Directive 93/68/EEC. -
Page 3: Table Of Contents
CONTENTS Technical Details ........................... Contents ..............................Preface ..............................Safety ..............................Before Installation .......................... During Installation .......................... After Use ............................General ............................Introduction ............................Rating Plate ............................ Installation ............................General Notes on Using Your Appliance ..................About Condensation and Steam ....................Oven Indicator Neons ........................ - Page 4 CONTENTS Defrost Feature ............................23 Uses of Defrost Feature ......................... 23 Selecting Defrost ..........................23 Things to Note ..........................23 Hints and tips ..........................23 Care and Cleaning ..........................24 Cleaning Materials ......................... 24 Cleaning the Sealed Hotplates and Hotplate Trims ............... 24 Things to Note ..........................
-
Page 5: Preface
They have been approved by BEAB (British Electrotechnical Approvals Board) and are covered by a 12 month parts and labour guarantee. To get the best from your new Tricity Bendix appliance, we ask that you PLEASE READ THESE INSTRUCTIONS CAREFULLY. Particular attention should be made to cooking times and temperatures, which may differ, from your previous appliance. -
Page 6: Safety
SAFETY DURING OPERATION THESE WARNINGS ARE PROVIDED IN THE INTERESTS OF YOUR SAFETY. Do not use this appliance if it is in ENSURE THAT UNDERSTAND contact with water. Never operate it THEM ALL BEFORE INSTALLING OR with wet hands. USING THE APPLIANCE. This appliance is designed to be PLEASE operated by adults. -
Page 7: After Use
Take care to follow the result in a fire, especially in the recommendations given for tending grill pan. the food when grilling. Do not leave utensils containing foodstuffs, e.g. fat or oil in or on the appliance in case it is inadvertently Do not leave the handle in position switched on. -
Page 8: Introduction
INTRODUCTION WARNING: THIS APPLIANCE MUST BE EARTHED To move the appliance, open the main oven door, RATING PLATE and lift the appliance by holding inside the top of the Record the model, product and serial numbers on the oven compartment. back cover of this instruction book from the rating plate. -
Page 9: General Notes On Using Your Appliance
In the case of the main oven the cooling fan may not GENERAL NOTES ON USING YOUR switch on except when used for a longer period of APPLIANCE time. The cooling fan may run on, and turn on and off after the control knobs have been switched off, We suggest that you run the oven elements for 10 –... -
Page 10: Getting To Know Your Appliance
GETTING TO KNOW YOUR APPLIANCE THE CONTROL PANEL FEATURES - Fan Oven Temperature Control - Fan Oven Indicator Neon - Top Oven/Grill Control - Top Oven Indicator Neon Hotplate Controls... -
Page 11: The Electronic Minute Minder
ELECTRONIC MINUTE MINDER DECREASE CONTROL & MINUTE MINDER INCREASE CONTROL COOKPOT SYMBOL CLOCK SETTING SYMBOL MINUTE MINDER SYMBOL Fig.1 The electronic minute minder can indicate the time of day, operate as a minute minder and it can be used to time and switch off the main oven. 1. - Page 12 2. THE MINUTE MINDER Fig.6 IMPORTANT The minute minder can be used to time a set cooking period. At the end of the cook time the minute minder will automatically switch off the main oven if in use. The minute minder gives an audible reminder at the end of any period of cooking up to 23 hours and 50 Fig.7 minutes.
-
Page 13: The Sealed Hotplates
THE SEALED HOTPLATES BEFORE USING THE HOTPLATES FOR THE FIRST TIME Turn the control knob to a medium/high setting and allow the hotplate to heat, uncovered by a saucepan for 3-5 minutes. This hardens the protective coating on the hotplates, and makes it more resistant to normal use. A harmless smoke will be given off from the hotplates. -
Page 14: Deep Fat Frying
6. Frying temperatures DEEP FAT FRYING Celsius Fahrenheit Scale (°C) Scale (°F) SPECIAL FRYING NOTE: For safety purposes when deep fat frying, fill the pan one third full of oil, DO NOT cover the pan with a lid First frying of potatoes and DO NOT leave the pan unattended. -
Page 15: The Grill
THE GRILL CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. CHLDREN SHOULD BE KEPT AWAY. SELECTING THE GRILL • The grill pan is supplied with a removable handle. To operate the grill, open the grill door and turn the top oven/grill control clockwise so that ‘0’... -
Page 16: Hints And Tips
• Accompaniments such tomatoes To correctly locate the grill pan on the shelf, ensure mushrooms may be placed underneath the grid that the cut out on the underside of the handle when grilling meats. bracket locates over the front bar of the shelf. •... -
Page 17: The Top Oven
THE TOP OVEN USES OF THE TOP OVEN The top oven is the smaller of the two ovens. It is heated by elements in the top oven and bottom of the oven. It is designed for cooking on one level and for smaller quantities of food. It gives especially good results if used to cook fruit cakes, sweet or savoury flans or quiche. -
Page 18: Hints And Tips
• HINTS AND TIPS The material and finish of the baking trays and • dishes will affect the degree of base browning of All cooking should be carried out using an oven the food. Enamelware, dark, heavy or non-stick shelf positioned in one of the shelf runners. utensils increase base... -
Page 19: The Main Fan Oven
THE MAIN FAN OVEN USES OF THE FAN OVEN PREHEATING The fan oven quickly reaches its temperature, so it is not usually necessary to preheat the oven. Without preheating however, you may find you need to add an extra 5 – 10 minutes on the recommended cooking times. For recipes needing high temperatures, e.g. -
Page 20: Hints And Tips
DO NOT place baking trays directly on the oven floor HINTS AND TIPS as it interferes with the oven air circulation and can • Arrange the shelves in the required positions lead to base burning; use the lower shelf position. before switching the oven ON. -
Page 21: Oven Cooking Chart
OVEN COOKING CHART The oven temperatures are intended as a guide only. It may be necessary to increase or decrease the temperature by 10°C to suit individual preferences and requirements Shelf positions are counted from the bottom of the oven. FAN OVEN TOP OVEN FOOD... -
Page 22: Roasting Chart
ROASTING CHART ROASTING CHART INTERNAL TEMPERATURES – Rare : 50-60°C; Medium : 60-70°C; Well done : 70-80°C SECOND/FAN MEAT COOKING TIME OVEN 20-35 minutes per ½kg (1lb) Beef 160-180°C and 20-35 minutes over Beef, boned 160-180°C 25-35 minutes per ½kg (1lb) and 25-35 minutes over Mutton and Lamb 160-180°C... -
Page 23: Defrost Feature
DEFROST FEATURE Small or thin fish fillets, frozen peeled prawns, cubed USES OF DEFROST FEATURE or minced meat, liver, thin chops, steaks etc., can be thawed in 1 – 2 hours. This fan oven function defrosts most foods faster than more conventional methods. It is particularly suitable for delicate frozen foods which are to be served cold e.g. -
Page 24: Care And Cleaning
CARE AND CLEANING ALWAYS SWITCH OFF THE CLEANING THE VITREOUS ENAMEL ELECTRICITY SUPPLY AT THE MAIN Use a clean damp cloth or scourer made for non- WALL SWITCH AND ALLOW THE stick saucepans with ‘Cif’ cream cleaner. APPLIANCE TO COOL BEFORE AFTER CLEANING CLEANING. -
Page 25: Cleaning The Grill Pan, Grid And Oven Shelves
CLEANING THE GRILL PAN, GRILL PAN HINTS AND TIPS • GRID AND OVEN SHELVES Manual cleaning of the Stayclean surfaces IS NOT recommended. Damage will occur if All removable parts, except the grill pan handle can abrasives or aerosol sprays of any kind are used. be washed in the dishwasher. -
Page 26: Cleaning Between The Fan Oven Outer And Inner Door Glass
CLEANING THE DOOR GLASS TO REPLACE THE OUTER GLASS 1. Holding the oven glass with both hands, gently place the locators into the holes of the brackets To prevent damaging or weakening of the at the bottom of the oven door. door glass panels avoid the use of the following: 2. -
Page 27: Something Not Working
SOMETHING NOT WORKING? We strongly recommend that you carry out the following checks on your appliance before calling a Service Engineer. It may be that the problem is a simple one which you can solve yourself without the expense of a Service call. If our Service Engineer finds that the problem is listed below you will be charged for the call whether or not the appliance is under guarantee. -
Page 28: Service And Spare Parts
Dublin 12 Telephone: 01 4090752 CUSTOMER CARE DEPARTMENT For general enquiries concerning your Tricity Bendix appliance, or further information on Tricity Bendix products, you are invited to contact our Customer Care Department by letter or telephone as follows: Customer Care Department Tricity Bendix 55 –... -
Page 29: Customer Service Centres
08705 929 929 To contact your local Service Force Centre telephone ISLE OF LEWIS ND Macleod NORTH EAST CHANNEL ISLANDS 16 James Street Stornoway GATESHEAD Unit 356a GUERNSEY Guernsey Electricity Isle of Lewis PA87 2QW Dukesway Court PO Box 4 Dukesway Vale, Guernsey Gateshead... - Page 30 08705 929 929 To contact your local Service Force Centre telephone MIDLANDS BECKENHAM 11a Gardner Ind. Estate SOUTH EAST Kent House Lane Beckenham BIRMINGHAM 66 Birch Road East ASHFORD Unit 2 Kent BR3 1QZ Wyrley Trading Estate Bridge Road Business Witton Centre CHELMSFORD...
-
Page 31: Guarantee Conditions
Standard guarantee conditions We, Tricity Bendix, undertake that if within 12 months of the date of the purchase this Tricity Bendix appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: •... - Page 32 In line with our continuing policy of research and development, we reserve the right to alter models and specifications without prior notice. This instruction booklet is accurate at the date of printing, but will be superseded if specifications or appearance are changed. TRICITY BENDIX, 55 – 77 HIGH STREET, SLOUGH, BERKSHIRE, SL1 1DZ.
