Channel Vision 6126 Instructions

* Specifications :
Image Sensor: 1/3" Hi-Res CCD
Picture Elements: NTSC: 768x494
Resolution: 540 lines
S/N Ratio: More than 48 dB
Min Illumination: 0.03 LUX @ F2.0(Day), 0 LUX @ F2.0(Night)
Electronic Shutter: 1/60s - 1/100,000s
Flickerless Mode: ON/OFF switchable
Gain Control: High/Low switchable
Auto White Balance: Automatic
Back Light Comp.: ON/OFF switchable
Gamma Characteristic: 0.45
Camera Lens: 3.6mm Fixed Lens
Sync. System: Internal, Negative sync.
Power Requirements: 12VDC
Power Consumption: 80mA (IR off), 360mA (IR on - max)
Infrared Illumination: 24 IR LEDs
LED Wavelength: 850nm
Illumination Distance: 60 feet
Video Output: 1 Vp-p @ 75 ohms
Dimensions: Dia. 4.39", Height 3.27"
Operating Temp: -10°C to 50°C (14°F to 122°F)
1
Channel Vision Technology will repair or replace any defect in material or workmanship which
occurs during normal use of this product with new or rebuilt parts, free of charge in the USA, for
one year from the date of original purchase. This is a no hassle warranty with no mail in
warranty card needed. This warranty does not cover damages in shipment, failures caused by
other products not supplied by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only to the original purchaser,
and a purchase receipt, invoice, or other proof of original purchase date will be required before
warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling (800) 840-0288 toll free.
A Return Authorization number must be obtained in advance and can be marked on the outside
of the shipping carton.
This warranty gives you specific legal rights and you may have other rights (which vary from
state to state). If a problem with this product develops during or after the warranty period,
please contact Channel Vision Technology, your dealer or any factory-authorized service
center.
Channel Vision products are not intended for use in medical, lifesaving, life sustaining or
critical environment applications. Channel Vision customers using or selling Channel Vision
products for use in such applications do so at their own risk and agree to fully indemnify
Channel Vision for any damages resulting from such improper use or sale.
w w w . c h a n n e l v i s i o n . c o m
234 Fischer Avenue, Costa Mesa, California 92626 USA
(714)424-6500 (800)840-0288
email: techsupport@channelvision.com
*Specifications subject to change without notice.
(714)424-6510 fax
500-267 Rev C
6126
IR Illuminated Color Dome Camera
