Eclipse CLD2 User Manual

Cld mp3 player
Hide thumbs
Table of Contents

Advertisement

Quick Links

ECLIPSE
POBTABLE MEDIA PLAYER
CLD MP3 Player
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for Eclipse CLD2

Summary of Contents for Eclipse CLD2

  • Page 1 ECLIPSE POBTABLE MEDIA PLAYER CLD MP3 Player User’s Manual...
  • Page 2 CLD MP3 Player User’s Manual Thank you for your purchase of this CLD MP3 player. To better learn how to use this product to its maximum potential, it is recommended that you read the entire user’s manual.

  • Page 3: Technical Specifications

    Technical Specifications Compatible Formats -Audio formats: MP3, WMA (non encrypted) Battery Information -Charging Time: One hour and 30 minutes -Playback Time: Six hours (depending on function in use and power settings).

  • Page 4: Table Of Contents

    Contents Page 4: Foreward Page 6: Safety Precautions Page 5: Unit and Button Description Page 9: Basic Operation Page 12: Uploading Files Page 18: Music Mode Page 19: Menu Mode Page 20: Menu Settings Page 22: Contact Us...

  • Page 5: Foreward

    Foreward Please take note:  Mach Speed Technologies is not responsible for loss of personal data or damage to property due to malfunction in hardware or firmware, improper handling of the unit, or improper storage of the unit.  Information contained within this manual is subject to change without prior notice.
  • Page 6 Foreward This equipment has been tested and found to comply with the limits for Class B Digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generate, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio or telephone reception, which can be determined by turning the...

  • Page 7: Safety Precautions

    Safety Precautions  Avoid using in extreme temperature conditions (-20ºC / -4ºF or below; +45ºC / +114ºF or above).  Avoid dropping.  Do not immerse or expose to water  Do not disassemble or flash 3rd party firmware. The playback times listed refer to the maximum playback times possible, using the best power savings.

  • Page 8: Unit And Button Description

    Unit and Button Description...
  • Page 9 Unit and Button Description 1. LCD screen 2. Power switch On / Off 3. Play / Pause 4. Menu / Select 5. Volume 6. Next track 7. Previous track 8. Earphone jack 9. USB port...

  • Page 10: Basic Operation

    Basic Operation Powering On and Off -To power the player on, slide the power switch to the on position. Alternatively, press and hold the play / pause button for 5 seconds if the unit is powered off but the power switch is in the on position. -To power the unit off, slide the power switch to the off position.
  • Page 11 Basic Operation Recharging the Battery -The player can be charged by connecting the supplied charger cable between the player’s charging jack and a wall outlet, or by connecting the player to a computer using the supplied USB cable. -The player will charge while either turned on or turned on off. Note: If using 3rd party wall adapters, make sure the voltage is compatible with AC input 120V and 5V DC, 300mA.
  • Page 12 Basic Operation Menu Browsing -Press the menu / select button to access the menu while in play mode. -Press the next track button or the previous track button to navigate menu options. -Press the menu / select button to select a menu option. -Press the play / pause button to return to a previous menu.

  • Page 13: Uploading Files

    -This player can have files uploaded via drag and drop / copy and paste, or by using Window’s Media Player. Window’s Media Player Method -Open Windows Media Player and connect the player to a working USB port. Windows Media player will display a setup screen asking for a name for the MP3 player.
  • Page 14 Uploading Files to the Player Window’s Media Player Method -Once the MP3 player has been named, select Finish, and Windows Media Player will open to the Sync tab.
  • Page 15 Uploading Files to the Player Window’s Media Player Method -Drag music to the sync list (on the right of the screen) from the list on the left. Once all desired music you has been added to the player, press Sync, and Window Media Player will load the songs to the player.
  • Page 16 Uploading Files to the Player Window’s Media Player Method -Once all the songs added are synced to the unit, and Windows Media Player says that is safe to disconnect the player, disconnect the device. Note: 1. To use this feature, Windows Media Player 10 or later must be used. 2.
  • Page 17 Uploading Files to the Player Drag and Drop / Copy and Paste Method -Go to “My computer”, and a new removable disk drive with a letter in parenthesis will appear. Disk drive names vary from computer to computer.
  • Page 18 Uploading Files to the Player Drag and Drop / Copy and Paste Method -Double click, or right click then select open to access the player’s internal memory. -Without closing the removable drive already selected, locate and open where music is stored on the computer (often located in My Music). -If music can not be easily located, click “Start”, select “Search”, select “Pictures, music or video”, then search for *.MP3, *.WMA.

  • Page 19: Music Mode

    Operation Music Mode -By default, when the player is turned on, it will start in music mode -When audio files are playing, these options are available; volume control, next / previous track, next / previous 10 tracks, fast forward / rewind, play / pause.

  • Page 20: Menu Mode

    Operation Menu Mode -Use the menu to adjust settings and find information about the player. -Press the menu / select key while in music mode to access the menu. -When the menu is selected, these options are available; Music, About, Folder, Settings.

  • Page 21: Menu Settings

    Operation Menu Settings -When settings is selected, these options are available; EQ Set, Play Mode, LCD Set Language, Auto off. -Select auto off to choose how long the player remains on before shutting automatically off -Select language to choose different languages available for the player. Menu Settings - LCD Set -Select LCD set to choose power saving options -When LCD set is selected, these options are available: Backlight,...
  • Page 22 Operation Menu Settings - Play Mode -Select play mode to select different playback options while in music mode. -When play mode is selected, these options are available: Normal, Repeat One, Repeat All, Random, Repeat Folder -Select normal to have all audio files located within one folder or all song located outside folders play, after which the player will switch to stop mode and playback will cease until the play / pause button is pressed.

  • Page 23: Contact Us

    Contact Us If you notice any mistakes or omissions that you would like to tell us about, please feel free to contact our technical support department at mssupport@machspeed.com.
