- Page 1 LED TV RTDVD2005 This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device might not cause harmful interference, and (2) this device must accept any interference received, including interference that might cause undesired operation...
-
Page 2: Table Of Contents
Table of Contents Caution Important Safety Precautions Wall Mount Installation TV Bracket assembly Top/Side panel diagram Remote Controller Battery Installation Using the Remote Control Install TV Set your TV Connect Antenna and power Turn On TV Systems Connection Setup Wizard 12-13 Select Input Source 15-18... -
Page 3: Caution
Caution The lightening flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of un-insulated "dangerous voltage" within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to the persons. The exclamation point within an equilateral triangle is intend to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance. -
Page 5: Wall Mount Installation
Wall Mount Installation 3.95” x 3.95” 3.95” 3.95”... -
Page 6: Tv Bracket Assembly
TV Bracket assembly 1.Match the TV unit into the stand, then hold the TV stand, revolve and lock the tv unit tightly as the arrowhead point. 2.Fix the screws into the TV stand after installing the tv unit and tv stand. screws... - Page 7 Top panel diagram (IR) Infrared Receiver: Receives IR signals from the remote control. (Power on/Standby) LED Indicator: Press to turn on and off Indicator on(Red) Standby mode Indicator on(Green) Power on mode The functions of the buttons on the are as follows: SOURCE :DVD Eject.
-
Page 8: Top/Side Panel Diagram
Side Panel Diagram INPUT VIDEO COAXIAL (Left Side) INPUT AC 12 0V ~ 60 Hz service port service port HDMI1 HDMI2 HDMI3 COAXIAL DC 12V HDMI (Back Side) Name Function Description Digital Audio Output COAXIAL AV INPUT Service Port For Upgrade Use Connect to HDMI of DVD or other equipment HDMI IN VGA IN... -
Page 9: Remote Controller
Remote Controller SLEEP: Select amount of time before TV turn off automatically. Press "-" to enter a program number for multiple program channel, such as 2-1 etc. S.MODE: Press to cycle through the different sound settings P.MODE S.MODE SLEEP P.MODE: Press to cycle through the different picture settings MENU SOURCE ENTER... -
Page 10: Install Tv
10cm 10cm 10cm side LED TV indicator... - Page 11 INPUT VIDEO COAXIAL Component INPUT service port DC 12V HDMI INPUT VIDEO COAXIAL...
- Page 12 INPUT service port DC 12V HDMI INPUT service port DC 12V HDMI...
-
Page 13: Setup Wizard
Setup Wizard Connect an RF cable from the TV’s input called “RF-In” and to your TV Aerial socket. Select TV Configuration TV Configuration Select Time Press ▼ / ▲ button to select the time zone, daylight saving time and time format you want to. Press </ >... - Page 14 Setup Wizard Auto Scan Press </ > button to select the antenna type. Press ▼ / ▲ button to select go to next step and press ENTER/> button to start auto scan.
-
Page 15: Select Input Source
Select Input Source Source Select Press INPUT button to display the input source list, Press ▼ / ▲ or Component INPUT button to select the input source you want to, HDMI Press ENTER button to enter the input source, Press EXIT button to quit. Main Menu Press MENU to display the main menu or return to the previous menu or close the main menu. -
Page 16: Main Menu Operation
Main Menu Operation Picture Menu Press M ENU to enter the main menu, Press </ > button to select. ENTER / ▼ Press to enter. Press M ENU again to exit or back to parent menu. Press ▼ / ▲ button to select among Picture Mode /Brightness/ Contra st / Color / Tint / Sharpness / Color Temperature/ Advanced Settings. -
Page 17: Time Menu
Press ▼ / ▲ button to select among /Sound Mode / Bass / Treble / Balance /MTS/ Audio Language /Digital Audio Output/Surro und Sound/ AVL . ENTER / ▼ Press to enter. Press </ > button to adjust. Press M ENU again or back to parent menu. - Page 18 Move Next Return Press ▼ / ▲ button to select among Menu Language / Transparent / OSD Timeout / Closed Caption /Over Scan/ Input Label / Other settings / Restore Default / Setup Wizard/Voice Guidance/Video Description. ENTER / ▼ Press to enter.
-
Page 19: Lock Menu
Lock Menu Press M ENU to enter the main menu Press </ > button to select Press ENTER / ▼ to enter Press M ENU again to exit or back to parent menu / ▲ Press ▼ buttontoselectamong Change Password / System Lock / Input Block / US Rating / Canada Rating /RRT Setting / Reset RRT ENTER / ▼... -
Page 20: Channel Menu
Channel Menu Press M ENU to enter the main menu, Press </ > button to select. ENTER / ▼ Press to enter. Press M ENU again to exit or back to parent menu. Press ▼ / ▲ button to select among Air/C able / Auto Scan / Favorite / channe list / Show/Hide / Channel Number / Channel Label . -
Page 21: Pc Menu
PC Menu Press INPUT to select PC source. Press ENU to enter the main menu, Press </ > button to select Setup menu. ▼ Press to select PC Settings. Move Select Return ▼ / ▲ Press buttontoselectamong H-Pos / V-Pos / Clock / Phase / Auto. Press ENTER / ▼... -
Page 22: Dvd Setup
DVD Setup Press the “D.Setup” button to enter the DVD settings menu,use the “ ” buttons to select the desired menu page (General / Audio / Video / Preferences),and use “ ” buttons to select the items in each menu,then use “ ”... - Page 23 DVD Setup 3.Video Setup Page Sharpness:adjust the sharpness of the image. Brightness:adjust the brightness of the image. contrast:adjust the contrast of the image. 4.Preference Page (Note:This menu page will pop up before put the disc into DVD.) TV Type: Select the local TV system (PAL TV/Multi/NTSC TV) Audio: Disc audio language selection (disc dependent) Subtitle: Disc subtitle language selection (disc dependent) Disc Menu: Disc Menu language selection (disc dependent)
-
Page 24: Help
Help... -
Page 25: Specifications
Specifications Resolution 640x480 800X600 1024x768 1360x768 60HZ 60HZ 60HZ 60HZ Vertical frequency hz HDMI 576 i/P 720 P 1080 i Format 480 i/P 50HZ/60HZ Vertical frequency hz 50HZ 50HZ/60HZ 60HZ Parameter specification Screen Size 20” NTSC / ATSC PAL, NTSC IN:TV, AV, YPbPr, PC AUDIO,VGA, HDMI, DC.
