USER GUIDE
Airflow & Product Loading
AIRFLOW
External
• Do not block the front grille - no additional clearance
around sides, top or rear of unit is needed for
ventilation
• Do not install behind a closed door
Internal
• When loading, leave space between internal fans,
vents, and side walls to allow air to circulate freely

PRODUCT LOADING

Bottles and cans come in all shapes and sizes. When
determining capacities U-Line uses the following sizes.
Combinations of red and white bottles are used in Wine
®
Captain Models and Beverage Centers.
11
¾"
(298 mm)
11
¼"
(184 mm)
Typical White
Wine Bottle
(750 mL)
3
¼"
(82 mm)
Airflow & Product Loading
11
29⁄32"
(302 mm)
8
¾"
(222 mm)
Typical Red
Wine Bottle
(750 mL)
3"
(76 mm)
NOTICE
Restricting airflow may result in poor product
performance, product failure, and uneven
internal temperatures and may freeze contents.
4 27⁄32"
Typical Can
(123 mm)
(12 oz)
2 19⁄32"
(66 mm)
11
¾"
(299 mm)
7
11⁄16"
(195 mm)
Typical
Champagne Bottle
(750 mL)
3
11⁄16"
(94 mm)
18
u-line.com
9"
(229 mm)
Typical Bottle
(12 oz)
5
5⁄16"
(135 mm)
2
7⁄16"
(64mm)
13
1⁄8"
(334 mm)
Magnum Bottle
10
11⁄32"
(1.5 L)
(263 mm)
3
27⁄32"
(98 mm)
