Summary of Contents for Finlux FL5526UHD
- Page 1 Kleurentelevisie Colour television Télévision en couleur Farbfernseher FL5526UHD Handleiding Owner’s manual Manuel d'utilisateur Bedienungsanleitung...
- Page 2 Quick Start Guide Insert the batteries into the Remote Control Insert two AAA/R3 or equivalent type batteries inside. Observe the correct polarity (+/-) when inserting batteries and replace the battery cover. REAR SIDE OF THE TV Connect the antenna to your TV Aerial Cable Connect the TV to the mains socket...
- Page 3 HDMI input PLEASE ENSURE BOTH UNITS ARE SWITCHED OFF BEFORE CONNECTING. Use a HDMI to HDMI cable to connect the two units together. To select the HDMI input, To HDMI connection SOURCE SOURCE on the device press the Source button on the remote control. Each time it is pressed the on-screen menu confirms your selection.
- Page 4 Connect your TV to the Internet Connectivity feature allows you to connect your TV to the home network wired or wirelessly. You can use this networking system to connect to the Portal or to access photo, video and audio files that are stored on a Media server connected to the network and play/display them on the TV.
-
Page 5: Table Of Contents
Contents Contents ...............32 Safety Information ..........33 Markings on the Product........33 Environmental Information........34 Features ...............35 Accessories Included..........35 Standby Notifications ..........35 TV Control & Operation ........36 Inserting the Batteries into the Remote ....36 Connect Power ............36 Antenna Connection ..........36 License Notification ..........36 Specification ............37 Remote Control ............39 Connections............40... -
Page 6: Safety Information
• Do not place any heat sources such as electric Safety Information heaters, radiators, etc. near the TV set. • Do not place the TV on the floor and inclined CAUTION surfaces. • To avoid danger of suffocation, keep plastic bags RISK OF ELECTRIC SHOCK DO NOT OPEN out of the reach of the babies, children and domestic... -
Page 7: Environmental Information
WARNING WALL MOUNTING WARNINGS Do not ingest the battery, Chemical Burn Hazard This product or the accessories supplied with the • Read the instructions before mounting your TV product may contain a coin/button cell battery. If the on the wall. coin/button cell battery is swallowed, it can cause •... -
Page 8: Features
Note: Screen Off option is not available if the Mode is set Standby Notifications to Game. If the TV does not receive any input signal (e.g. from When the TV is not in use, please switch off or aerial or HDMI source) for 3 minutes, it will go disconnect the TV from the mains plug. -
Page 9: Tv Control & Operation
TV Control & Operation Inserting the Batteries into the Remote Remove the back cover to reveal the battery compartment. Insert two size AAA batteries. Make sure the (+) and (-) signs match (observe correct polarity). Do not mix old and new batteries. Replace only with same or equivalent type. -
Page 10: Specification
If the device fails to properly enforce restrictions on Specification content usage, content owners may require Microsoft to revoke the device’s ability to consume PlayReady- protected content. Revocation should not affect unprotected content or content protected by other content access technologies. Content owners may require you to upgrade PlayReady to access their content. - Page 11 Country Restriction PAL BG/I/DK/LL’ TV Broadcasting Radio transmission is prohibited for the SECAM BG/DK Norway geographical area within a radius of 20 km VHF (BAND I/III) - UHF from the centre of Ny-Ålesund Receiving Channels (BAND U) - HYPERBAND R u s s i a n In-door use only Fully integrated digital Federation...
-
Page 12: Remote Control
Remote Control Source: Shows all available broadcast and content sources Netflix: Launches the Netflix application, if this feature is supported by your TV YouTube: Launches the YouTube application Play: Starts to play selected media Record: Records programmes Rapid reverse: Moves frames backwards in media such as movies Language: Switches between sound modes (analogue TV), displays and changes audio/subtitle... -
Page 13: Connections
Connections Connector Type Cables Device NOTE: When connecting a device via the YPbPr or Back Scart AV input, you must use the Connection connection cables to enable (back) connection. See the illustrations on the left side. | To enable YPBPR PC/YPbPr audio, you will need YPbPr Video to use the Back Audio inputs... -
Page 14: Switching On/Off
channels of it will be listed on the top of the Channel Switching On/Off List. When finished, press OK to continue. To Switch the TV On You can activate Store Mode option at this point. Connect the power cord to a power source such as a This option will configure your TV’s settings for store wall socket (220-240V AC, 50 Hz). -
Page 15: Recording A Programme
Wait a little while before each plugging and unplugging Some stream packets may not be recorded because as the player may still be reading files. Failure to do of signal problems, as a result sometimes videos may so may cause physical damage to the USB player freeze during playback. -
Page 16: Timeshift Recording
If “USB disk writing speed too slow to record” Timeshift Recording message is displayed on the screen while starting a Press Pause button while watching a broadcast to recording, try restarting the recording. If you still get activate timeshifting mode. In timeshifting mode, the the same error, it is possible that your USB disk does programme is paused and simultaneously recorded not meet the speed requirements. -
Page 17: E-Manual (If Available)
set as Off by pressing Left or Right button. This feature can also be enabled or disabled under the System>Settings>More menu. The TV supports also ARC(Audio Return Channel) feature. This feature is an audio link meant to replace other cables between the TV and the audio system (A/V receiver or speaker system). -
Page 18: Tv Menu Contents
TV Menu Contents System - Picture Menu Contents You can change the picture mode to suit your preference or requirements. Picture mode can Mode be set to one of these options: Cinema, Game(optional), Sports, Dynamic and Natural. Contrast Adjusts the light and dark values on the screen. Brightness Adjusts the brightness values on the screen. - Page 19 System - Sound Menu Contents Volume Adjusts the volume level. Equalizer Selects the equalizer mode. Custom settings can be made only when in User mode. Balance Adjusts whether the sound comes from the left or right speaker. Sets headphone volume. Headphone Please ensure before using headphones that the headphone volume is set to a low level, to prevent damage to your hearing.
- Page 20 System - Settings Menu Contents Conditional Access Controls conditional access modules when available. Language You may set a different language depending on the broadcaster and the country. Enter correct password to change parental settings. You can easily adjust Menu Lock, Maturity Lock, Child Lock or Guidance in this menu. You can also set a new PIN or change the Default CICAM PIN using the related options.
- Page 21 This setting configures the power up mode preference. Last State and Standby Power Up Mode options are available. Virtual Remote Enable or disable the virtual remote feature. With this setting you can enable and disable CEC functionality completely. Press Left or Right button to enable or disable the feature.
-
Page 22: General Tv Operation
Internet Lock: If this option is set to ON, the open General TV Operation browser application in the portal will be disabled. Set Using the Channel List to OFF to release the application again. The TV sorts all stored stations in the Channel List. Set PIN: Defines a new PIN number. -
Page 23: Teletext Services
Event Details (Info button): Displays detailed Teletext Services information about selected programmes. Press the Text button to enter. Press again to activate Filter (Text button): Views filtering options. mix mode, which allows you to see the teletext page and Next Time Slice (Green button): Displays the the TV broadcast at the same time. -
Page 24: Pc Input Typical Display Modes
• Are suitable plugs used to connect the antenna? PC Input Typical Display Modes • If you are in doubt, consult your dealer. The following table is an illustration of some of the typical video display modes. Your TV may not support No sound all resolutions. -
Page 25: Av And Hdmi Signal Compatibility
AV and HDMI Signal Compatibility Source Supported Signals Available SECAM NTSC4.43 (SCART) NTSC3.58 RGB 50/60 SECAM Back AV NTSC4.43 NTSC3.58 480i, 480p 60Hz 576i, 576p 50Hz YPbPr 720p 50Hz,60Hz 1080i 50Hz,60Hz 480i 60Hz 480p 60Hz 576i, 576p 50Hz 720p 50Hz,60Hz 1080i 50Hz,60Hz 24Hz,... -
Page 26: Supported Video File Formats For Usb Mode
Supported Video File Formats for USB Mode Video Codec Resolution Bit Rate Container MPEG program stream (.DAT, .VOB, .MPG, .MPEG), MPEG MPEG1/2 transport stream (.ts, .trp, .tp), MP4 (.mp4, .mov), 3GPP (.3gpp, .3gp), AVI (.avi), MKV (.mkv), ASF (.asf) MPEG program stream (.MPG, .MPEG), MP4 (.mp4, .mov), 1080Px2@30fps, MPEG4 40Mbps... -
Page 27: Supported Audio File Formats For Usb Mode
Supported Audio File Formats for USB Mode Audio Codec Sample rate Bit Rate Container MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka), 32Kbps ~ MPEG1/2 Layer1 16KHz ~ 48KHz MPEG transport stream (.ts, .trp, .tp), MPEG program stream 448Kbps (.DAT, .VOB, .MPG, .MPEG), WAV (.wav) MP3 (.mp3), AVI (.avi), ASF (.asf), Matroska (.mkv, .mka), 8Kbps ~... -
Page 28: Supported Dvi Resolutions
Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not supplied), you can refer to the following resolution information. 72Hz 75Hz 56Hz 60Hz 66Hz 70Hz 640x480 þ þ 800x600 þ þ... - Page 29 Configuring Wired Device Settings Connectivity Network Type Wired Connectivity The Network Type can be selected as Wired Device, Wireless Device or Disabled, in accordance with the To Connect to a Wired Network active connection to the TV set. Select this as Wired •...
- Page 30 Connecting to your mobile device via WiFi • The transmission speed differs depending on the distance and number of obstructions between the • If your mobile device has WiFi feature, you can connect transmission products, the configuration of these it to your TV via a router, in order to access the content products, the radio wave conditions, the line traffic in your device.
- Page 31 the domain is invalid, this might cause problems while Connectivity Troubleshooting browsing files in Audio Video Sharing mode. Wireless Network Not Available Using Audio Video Sharing Network Service • Ensure that any firewalls of your network allow the Audio Video Sharing feature uses a standard that eases TV wireless connection.
-
Page 32: Internet Portal
Internet Portal HINT: A broadband internet connection is required for high quality viewing. You must set the country option accordingly in the First Time Installation for proper operation of the internet portal. Portal feature adds your TV a feature that allows you to connect a server on the Internet and view the content provided by this server over your Internet connection. - Page 33 All sites on the internet might not be supportted. Internet Browser According to the site; content problems may occur. To use the internet browser, enter the portal first. Then In some circumstances video contents might not be launch the Internet application on the portal. able to be played.
