- Page 1 Kleurentelevisie Colour television Télévision en couleur FL4322SMART De handleiding Owner’s manual Manuel d'utilisateur...
- Page 2 www.elmarc.eu 50367172...
-
Page 3: Table Of Contents
Contents Safety Information Safety Information ..........29 Markings on the Product........30 CAUTION Environmental Information........31 RISK OF ELECTRIC SHOCK Features ...............31 DO NOT OPEN Accessories Included..........31 CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO Standby Notifications ..........31 NOT REMOVE COVER (OR BACK). TV Control Switch &... -
Page 4: Markings On The Product
• Do not place any heat sources such as electric heaters, radiators, etc. near the TV set. WARNING • Do not place the TV on the floor and inclined Do not ingest the battery, Chemical Burn Hazard surfaces. This product or the accessories supplied with the •... -
Page 5: Environmental Information
Note: Screen Off option is not available if the Mode is set to Game. When the TV is not in use, please switch off or WALL MOUNTING WARNINGS disconnect the TV from the mains plug. This will also reduce energy consumption. •... -
Page 6: Tv Control Switch & Operation
mode automatically because there was no signal Input Selection for a long time.” Press OK to continue. Once you have connected external systems to your TV, you can switch to different input sources. Press the If the TV is on and it isn’t being operated for a while Source button on your remote control consecutively it will go into standby. -
Page 7: Notification
Notification Specification TRADEMARK ACKNOWLEDGMENT PAL BG/DK/II’ The terms HDMI and High-Definition Multimedia TV Broadcasting SECAM BG/DK Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing LLC in the VHF (BAND I/III) - UHF Receiving Channels United States and other countries. (BAND U) - HYPERBAND Fully integrated digital Digital Reception... -
Page 8: Remote Control
Remote Control Source: Shows all available broadcast and content sources Netflix: Launches the Netflix application. YouTube: Launches the YouTube application. Play: Starts to play selected media Record: Records programmes Rapid reverse: Moves frames backwards in media such as movies Language: Switches between sound modes (analogue TV), displays and changes audio/subtitle language (digital TV, where available) Red button... -
Page 9: Connections
Connections NOTE: When connecting a device via the YPbPr or Side Connector Type Cables Device AV input, you must use the Scart connection cables to enable Connection connection. See the illustrations (back) on the left side. | You can use YPbPr to VGA cable to enable YPbPr signal via VGA input. -
Page 10: Switching On/Off
channels of it will be listed on the top of the Channel Switching On/Off List. When finished, press OK to continue. To Switch the TV On You can activate Store Mode option at this point. Connect the power cord to a power source such as a This option will configure your TV’s settings for store wall socket (220-240V AC, 50 Hz). -
Page 11: Recording A Programme
Wait a little while before each plugging and unplugging Record, Play, Pause, Display (for PlayListDialog) keys as the player may still be reading files. Failure to do can not be used when teletext is on. If a recording starts so may cause physical damage to the USB player from timer when teletext is on, teletext is automatically and the USB device itself. -
Page 12: Media Browser Menu
The TV remote is automatically able to perform the selection) during the First Time Installation use the PIN that you have defined. main functions after the connected HDMI source has been selected. IMPORTANT: Formatting your USB drive will erase ALL the data on it and it’s file system will be converted To terminate this operation and control the TV via to FAT32. - Page 13 TV Menu Contents System - Picture Menu Contents You can change the picture mode to suit your preference or requirements. Picture mode can Mode be set to one of these options: Cinema, Game(optional), Sports, Dynamic and Natural. Contrast Adjusts the light and dark values on the screen. Brightness Adjusts the brightness values on the screen.
- Page 14 System - Sound Menu Contents Volume Adjusts the volume level. Equalizer Selects the equalizer mode. Custom settings can be made only when in User mode. Balance Adjusts whether the sound comes from the left or right speaker. Sets headphone volume. Headphone Please ensure before using headphones that the headphone volume is set to a low level, to prevent damage to your hearing.
- Page 15 Menu Timeout Changes timeout duration for menu screens. Software Ensures that your TV has the latest firmware. Press OK to see the menu options. Upgrade Application Displays current software version. Version This option is used to select which subtitle mode will be on the screen (DVB subtitle / Subtitle Mode Teletext subtitle) if both is available.
-
Page 16: General Tv Operation
Child Lock: If this option is set to ON, the TV can only General TV Operation be controlled by the remote control. In this case the Using the Channel List control buttons on the TV will not work. The TV sorts all stored stations in the Channel List. Internet Lock: If this option is set to ON, the open You can edit this channel list, set favourites or set browser application in the portal will be disabled. -
Page 17: Teletext Services
Next/Prev Day (Programme +/- buttons): Displays Teletext Services the events of previous or next day. Press the Text button to enter. Press again to activate Event Details (Info button): Displays detailed mix mode, which allows you to see the teletext page and information about selected events. -
Page 18: Pc Input Typical Display Modes
• The picture quality may degrade when two devices PC Input Typical Display Modes are connected to the TV at the same time. In such The following table is an illustration of some of the a case, disconnect one of the devices. typical video display modes. -
Page 19: Av And Hdmi Signal Compatibility
AV and HDMI Signal Compatibility Source Supported Signals Available SECAM NTSC4.43 (SCART) NTSC3.58 RGB 50/60 SECAM Side AV NTSC4.43 NTSC3.58 480i, 480p 60Hz 576i, 576p 50Hz YPbPr 720p 50Hz,60Hz 1080i 50Hz,60Hz 480i, 480p 60Hz 576i, 576p 50Hz 720p 50Hz,60Hz 1080i 50Hz,60Hz HDMI 24Hz,... -
Page 20: Supported Video File Formats For Usb Mode
Supported Video File Formats for USB Mode Extension Video Codec SPEC (Resolution) & Bit Rate .dat, vob MPEG1/2 1080P@30fps - 40 Mbps MPEG1/2, .mpg, .mpeg MPEG4 MPEG1/2, H.264, H.264: 1080Px2@30fps - 62.5 Mbps, 1080P@60fps - 62.5 Mbps MVC: .ts, .trp, .tp AVS, MVC 1080P@30fps - 62.5 Mbps Other: 1080P@30fps - 40Mbps .mp4, .mov,... -
Page 21: Supported Audio File Formats For Usb Mode
Supported Audio File Formats for USB Mode Extension Audio Codec Bit Rate Sample rate MPEG1/2 Layer1 32Kbps ~ 448Kbps .mp3, MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3 8Kbps ~ 320Kbps MPEG1/2 Layer1 32Kbps ~ 448Kbps MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3... -
Page 22: Supported Subtitle File Formats For Usb Mode
Extension Audio Codec Bit Rate Sample rate MPEG1/2 Layer1 32Kbps ~ 448Kbps MPEG1/2 Layer2 8Kbps ~ 384Kbps 16KHz ~ 48KHz MPEG1/2 Layer3 8Kbps ~ 320Kbps .wav LPCM 64Kbps ~ 1.5Mbps 8KHz ~ 48KHz IMA-ADPCM, 384Kbps 8KHz ~ 48KHz MS-ADPCM G711 A/mu-law 64Kbps ~ 128Kbps 8KHz MPEG1/2 Layer3... -
Page 23: Supported Dvi Resolutions
Supported DVI Resolutions When connecting devices to your TV’s connectors by using DVI converter cable(DVI to HDMI cable - not supplied), you can refer to the following resolution information. 56Hz 60Hz 66Hz 70Hz 72Hz 75Hz 640x400 þ 640x480 þ þ þ... - Page 24 and display the result when complete. Connectivity Advanced Settings Highlight Advanced Settings and press the OK Wired Connectivity button. On the next screen you can change the IP To Connect to a Wired Network and DNS settings of the TV. Highlight the desired one •...
- Page 25 • The location where the transmission is most effective • If the connection is established correctly, you will be differs depending on the usage environment. able to access the shared files from your mobile device via the Media Browser of your TV. •...
- Page 26 Connection is Slow information about the installation, please refer to the “Nero Media Home Installation” section. See the instruction book of your wireless modem to 2. Connect to a Wired or Wireless Network get information on the internal service area, connection speed, signal quality and other settings.
-
Page 27: Internet Browser
Internet Portal Nero MediaHome Installation HINT: A broadband internet connection is required To install Nero MediaHome, please proceed as for high quality viewing. You must set the country follows: option accordingly in the First Time Installation Note: The Audio Video Sharing feature cannot be used if for proper operation of the internet portal. -
Page 28: Smart Center
To add a desired website to the Speed Dial list for ports if your TV doesn’t have internal wifi feature. To quick access, move the cursor to the top of the page be able to use internet based features, your modem/ or press the Back/Return button. - Page 29 Media Share Page Auto-lock (Only in IOS): The screen of the device automatically turns off after a certain amount of To access the Media Share widget tap on the Up- time. Default is off, which means the screen will arrow on the bottom left side of the screen. always stay on.
