- Page 1 Quad DVR 32 Gig SD Card REC02C Please read this manual completely before operating the SYSTEM A division of Component Solution Services, LLC. 56600 Twin Branch Drive Mishawaka, IN 46545 2018 Verity Rear Vision Systems / All rights reserved / Subject to Change...
- Page 2 Read our manual before operating Think Safety or installing. First Most likely, your system came preinstalled so the installation section would be for reference. Thank you for your purchase of our Verity Rear Vision Systems®. When installed and used properly, your REC02C is designed to deliver you years of trouble-free operation.
- Page 3 WARNING Do not place heavy objects on cables or cover them with carpet or mats. Do not place cables where they can be crushed in any manner. Our systems are designed as a driving aid. Watching videos, broadcasts, DVDs and/or any images other than intended driving assistance cameras is prohibited.
-
Page 4: Remote Instructions
KEY STROKE INSTRUCTIONS REMOTE INSTRUCTIONS... - Page 5 KEYSTROKE INSTRUCTIONS Press Menu: Press the (+) key to advance to the next menu screens. Menu Screens are PICTURE, VOLUME, OPTION, SYSTEM. Screen 1: Depress menu repeatly to scroll down options. Use the (-) and (+) buttons on monitor to increase or decrease values.
- Page 6 3 PICTURE: Picture refers to picture delay. This determines how long a camera stays on past the trigger wire being deactivated (powered). This allows for using the turn signal flasher wire as a trigger. PICTURE PICTURE CAMERA1 CAMERA2 CAMERA3 4 SYSTEM: LANGAUGE The default language is English.
- Page 7 DVR OPERATIONS REMOTE...
-
Page 11: System Components
SYSTEM COMPONENTS This monitor can be mounted on the dash and can be mounted on both horizontal and vertical surfaces. Make sure the view is suitable to the driver to observe the images. Take care not to block any necessary viewing area when mounting. -
Page 12: Connection Operations
CONNECTION OPERATIONS... - Page 15 Verity Rear Vision Systems A division of COMPONENT SOLUTION SERVICES (CSS) LIMITED ONE (1) YEAR WARRANTY 1. CSS products’ warranties are not transferable. The warranties apply to the retail consumer for one (1) year and covers against defects in material and workmanship.
- Page 16 Note: if you are a fire/rescue customer in need of tech support after hours or on weekends, leave a message and a technician will return your call as soon as one becomes available. a division of Component Solution Services 56600 Twin Branch Drive Mishawaka, IN 46545 574-807-6002 Toll Free 844-875-4799 We at Verity Rear Vision Systems would like to personally thank you for purchasing our product.
