Digital Spectrum MemoryFrame MF-1040 Plus Quick Start Manual page 2

What's in the box?
Before setting up your Before setting up your
frame check the contents of the box frame check the contents of the box
Software CD MemoryFrame Power Supply USB card reader
USB Cable Stand Remote
dsicentral.com
2007 Digital Spectrum Solutions, Inc. All rights reserved. Specifications and items shown subject to change
without notice. MemoryFrame is a registered trademark, and the Digital Spectrum logo, and Digital Spectrum
TM
are trademarks of Digital Spectrum, Inc. Microsoft , Windows Vista and the Windows Vista logo are registered
trademarks of the Microsoft Corporation. All other trademarks are the property of their respective owners.
* Protected by United States Patent No: 6,826,863 B1
Playing a slide show
MemoryFrame automatically plays your
1
previous slideshow. If you insert a new
MENU
media device, MemoryFrame will
automatically play from that device if
Video
Music
pictures are present.
Setting
To specify a different s urce for your pictures o
2
- Press MENU
- Select Picture and pr ss ENTER e .
- Se ect Play Slides l ho w and press ENTE R
Pictures
- Specify source l cation of picture fi es o l
Play slideshow
and p ess ENTER r
Copy picture(s)
- Select Play all pict es and press ENTER ur
Delete picture(s)
Note: For Compact Flash, SD/MMC
3
insert the memory card into the
slot as shown in the diagram. For
USB storage insert the USB card
SD/MMC
reader or thumb drive into the
Back panel connectors
"USB device" slot. Press "ENTER"
To confirm selection.
Up
CF Slot
Right
Down
Left
Use the / buttons to navigate
the menu bar press the "ENTER" button
Remote
once you have made your selection
Enter
Getting to know your memoryFrame
Removable frame
Built-in Stereo Speaker
Frame Lock
Power switch
SD/MMC
1
Assembled in China. Ilustration for information only.
Actual product and frame may vary slightly
Playing a slide show with music
MemoryFrame allows you to easily play
4
background music with your slideshow.
To play background music,
- Press MENU
- Select Music and press ENTER
- Select Play music and press Enter
5
- Select Previous or New song list and
press ENTER
-If Previous song list selected, music
playback will begin.
- If New song list selected, specify source
location and press ENTER
While music is playing, you can restart
6
your previous picture slideshow by
pressing PLAY on the remote.
Use the Mute/Vol+/Vol- buttons on the
remote to adjust music volume.
Refer to the User Guide to disable
background music.
USB USB Power
client host supply
Left
4
Enter
Play/Pause/Enter
Right
Left
Built-in Wireless Antenna
Down
Up
Menu
Mounting Holes
Built-in Stereo Speaker
Security Lock
(not included)
Adjustable Stand
(Landscape/Portrait)
Back panel connectors
Remote
CF Slot Power
USB USB
to PC device supply
Up
Right
Use the / buttons to navigate
Down
the menu bar press the "PLAY" button
once you have made your selection
Remote
Connecting the frame
Plug in the power cable to the back
1
of the unit
2 Plug the power adapter into a power
outlet
3 Turn on the power switch
After a few moments the unit will
automatically begin playing a photo
slideshow.
2
Configuring wireless photo sharing
Network requirement: To enable wireless network connectivity, an 802.11b/g
wireless router/access point must be available and accessible. Please refer to
the manufacturer's information on the router/ access point to ensure that a
connection is permissible and that the wireless settings match those of your
MemoryFrame. For Internet access, make sure your access point is online.
To access an Internet photo sharing site or a Windows PC*
1- Follow the previous steps to play picture slideshow.
2- When prompted to specify a source location, select
Photosharing or Windows.
3- MemoryFrame will display all the available wireless
networks. Select the preferred network.**
*Photo sharing with Windows requires Media Player 11 with
media sharing enabled.
**Once a network connection has been made, MemoryFrame
will remember the connection preference.
If the access point is configured
for encryption, MemoryFrame will
display an onscreen keyboard so
Security Key
you can enter the security key. Use
Type security access key for: MYSERVEREXAMPLE
the remote to navigate the
characters, and press the "ENTER" 1234xvsaaexample
button to select the character.
1 2
Select "BS" key to backspace a
Q w
character.
A s
Z x
Remote
Some routers allow users to enter a "passphrase" to generate
a security key. MemoryFrame requires the actual security key
rather than the passphrase. Please refer to your router
5
User manual to determine the required security key.
3
3 4 5 6 7 8 9 0 - BS
e r t y u i o p Space
d f g h j k l Enter
c v b n m . Shift
6
