OPERATOR'S MANUAL
MX 130P
Manure Spreader
Rev Apr-2021
Document Number: Z97104_En

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX130P and is the answer not in the manual?

Questions and answers

Related Manuals for Wallenstein MX130P

Summary of Contents for Wallenstein MX130P

  • Page 1 OPERATOR'S MANUAL MX 130P Manure Spreader Rev Apr-2021 Document Number: Z97104_En...

  • Page 2: Foreword

    Keep this manual handy for frequent reference and to provide Always keep this manual with the machine. to new operators or owners. Call your Wallenstein dealer or the W034 Distributor if you need assistance, information, or additional copies of the manual.

  • Page 3: Table Of Contents

    MX130P Foreword Manure Spreader Table of Contents 1. Foreword ..............2 10.  Specifications ............36 1.1 Introduction ............2 10.1 Machine Specifications ........36 1.2 Delivery Inspection Report ........4 10.2 Common Bolt Torque Values ......37 1.3 Serial Number Location ........5 10.3 Wheel Lug Nut Torque ........38 1.4 Types of Decals on the Machine ......6...

  • Page 4: Delivery Inspection Report

    Foreword Manure Spreader 1.2 Delivery Inspection Report Wallenstein MX130P Manure Spreader www.wallensteinequipment.com To activate the warranty, register your product at: This form must be filled out by the dealer at the time of delivery, and then signed by the dealer and customer.

  • Page 5: Serial Number Location

    MX130P Foreword Manure Spreader 1.3 Serial Number Location Always provide the model and serial number of your Wallenstein product when ordering parts, or requesting service or other information. The product information plate location is shown in the following illustration. Record the serial number of your equipment in the spaces provided below for future reference.

  • Page 6: Types Of Decals On The Machine

    The following example decal informs operators what personal protective equipment (PPE) is required for safe operation. For a complete illustration of the decals and decal locations, download the parts manual for the MX130P manure spreader at www.wallensteinequipment.com.

  • Page 7: Safety

    YOU are responsible for the SAFE operation and maintenance DANGER – of your Wallenstein product. YOU must make sure that anyone who is going to use, maintain, or work around the machine is Indicates an imminently hazardous situation that, if not avoided, familiar with the operating and maintenance procedures and will result in death or serious injury.

  • Page 8: Safety Rules

    MX130P Safety Manure Spreader 2.4 Safety Rules • Keep a first-aid kit available for use, should the need arise, and know how to use it. CAUTION! • Keep a fire extinguisher available for use, should Hearing loss hazard. Prolonged the need arise, and know how to use it.

  • Page 9: Safe Condition

    6. Chock the wheels to prevent movement. 2.7 Safety Training Safety is a primary concern in the design and manufacture of Wallenstein products. Unfortunately, efforts to provide safe equipment can be wiped out by a single careless act. • It is the operator's responsibility to read, understand, and follow ALL safety and operating instructions in this manual.

  • Page 10: Sign-Off Form

    MX130P Safety Manure Spreader 2.8 Sign-Off Form The design and manufacture of this product conforms to the applicable provisions in the following standards: Everyone who uses this machine must read and thoroughly • ASABE S318 Safety for Agricultural Field Equipment understand all safety, operation, and maintenance information in this manual.

  • Page 11: Safety Sign Explanations

    MX130P Safety Manure Spreader 2.9 Safety Sign Explanations Practicing good safety means becoming familiar with safety The top panel (or left-hand panel for horizontal signs) shows the signs (decals) and warnings, and being aware of situations that safety alert (potential hazard), and the bottom (or right-hand) require alertness.
  • Page 12 MX130P Safety Manure Spreader 01452 Fig. 3 – Safety-sign Locations (left-hand side view) 1. WARNING! 2. WARNING! Risk of entanglement in beater-bar Risk of injury from flying debris. paddles. Stay clear of manure discharge. The beater Keep hands, loose clothing, and long hair...
  • Page 13 MX130P Safety Manure Spreader 3. WARNING! 6. WARNING! Risk of being caught in rotating parts Risk of entanglement in rotating drive resulting in serious injury. line. Do not attempt to reach in with the shields Stay clear of the PTO shaft when the removed while the machine is operating.

  • Page 14: Replacing Damaged Safety Signs

    Replacement safety signs are available from your authorized distributor, dealer parts department, or Wallenstein Equipment. • Keep the safety signs clean and legible at all times. • Parts replaced that had a safety sign (decal) on them must also have the safety sign replaced.

  • Page 15: Familiarization

    IMPORTANT! The directions for left-hand side, right-hand manure. side, backward, and forward mentioned throughout this The MX130P model uses power from the tractor that is manual are determined when sitting in the driver's seat, transmitted through a PTO drive shaft. Power is transmitted facing the direction of forward travel.

  • Page 16: Machine Components

    The heavy-duty beater bar includes ten replaceable The Wallenstein MX130P has a 130 bushel main box with a paddles. sliding apron that is powered by a PTO driven multi-speed gear assembly (540 rpm maximum).

  • Page 17: Attaching To A Tractor

    MX130P Attaching to a Tractor Manure Spreader 4. Attaching to a Tractor 1. Keep bystanders clear of the area. WARNING! 2. Make sure that there is enough space and clearance to Never let anyone stand between the tractor and safely back up to the tractor.

  • Page 18: Pto Shaft

    MX130P PTO Shaft Manure Spreader 5. PTO Shaft Before installing the PTO shaft, make sure that it is the correct 5. Subtract B from the uncut PTO shaft measurement A. size. (A – B) The result is the length that BOTH halves of the PTO shaft should be shortened.

  • Page 19: Installing A Pto Shaft

    MX130P PTO Shaft Manure Spreader 5.2 Installing a PTO Shaft Make sure that the equipment is in the following state: • The tractor is turned off and the parking brake is applied. • The PTO shaft shielding is in good condition and able to turn freely, independent of the PTO shaft.

  • Page 20: Controls

    MX130P Controls Manure Spreader 6. Controls The five-position speed-control indicator is located on the front WARNING! of the main box, near the PTO connection. Do not operate the machine until you are thoroughly familiar with the position and function of the various controls. Read the operator’s manual thoroughly.

  • Page 21: Operating Instructions

    MX130P Operating Instructions Manure Spreader 7. Operating Instructions The operator is responsible for being familiar with and • Do not allow anyone within 20 ft (6 m) of the manure following all operating and safety procedures. spreader during operation. Objects thrown from the rear of the manure spreader could cause injury.

  • Page 22: Stopping

    MX130P Operating Instructions Manure Spreader 7.2 Stopping 7.5 Machine Break-In 1. Slow the tractor engine to low idle. Although there are no operational restrictions on the manure spreader when it is used for the first time, it is recommended 2. Stop forward movement.

  • Page 23: Loading

    MX130P Operating Instructions Manure Spreader 7.6 Loading • Do not overload the manure spreader. • Break up any large chunks of manure. The manure spreader load height is 42 inches • Be cautious of foreign objects in the manure that could (107 cm).

  • Page 24: Spreading

    For more information about accessories for your manure spreader, contact your Wallenstein dealer or go to 1. Stop the tractor, apply the parking brake, and then turn off www.wallensteinequipment.com.

  • Page 25: Transporting

    MX130P Operating Instructions Manure Spreader 7.10 Transporting 5. Start the tractor and leave it at a low idle. 6. Slowly engage the PTO. IMPORTANT! Equipment that is transported on a public 7. Do one of the following: roadway must comply with the local laws that govern the - If the beater bar turns freely, continue spreading.

  • Page 26: Storage

    MX130P Operating Instructions Manure Spreader 7.11 Storage IMPORTANT! During cold weather months, never store manure in the manure spreader between unloading times. A frozen load can cause equipment damage. After use for one season or when the manure spreader is not going to be used for a period of time, completely inspect all of the major systems.

  • Page 27: Service And Maintenance

    • Always wear the appropriate PPE. Check the apron-chain lubrication. See page 30 • When replacement parts are required, only use genuine original equipment manufacturer (OEM) parts. Wallenstein Check the drive-chain lubrication and See page 30 Equipment cannot be held responsible for damage or tension, and the sprocket condition.
  • Page 28 MX130P Service and Maintenance Manure Spreader 8.3.1 Grease Points IMPORTANT! Use a hand-held grease gun for all greasing. Pump one shot of grease per fitting. • Wipe the grease fitting with a clean cloth before applying the grease to avoid injecting dirt and grit.
  • Page 29 MX130P Service and Maintenance Manure Spreader 01459 Fig. 16 – 50-hour Grease Points...

  • Page 30: Drive Chain

    MX130P Service and Maintenance Manure Spreader 8.4 Drive Chain 8.5 Apron Chain The drive chain and sprocket provide power to the apron-chain Lubricate the apron chain every 50 hours or monthly. Use a drive shaft. It must be oiled frequently and kept at the correct good quality chain lubricant for the best performance.

  • Page 31: Main Box Sealing Flap

    MX130P Service and Maintenance Manure Spreader 8.6 Main Box Sealing Flap On each side of the manure spreader: 1. Loosen the two idler-mount bolts (1). Periodically check the condition of the front main-box sealing flap. Replace the sealing flap if the sides or bottom of the main 2.

  • Page 32: Gearbox

    MX130P Service and Maintenance Manure Spreader 8.7 Gearbox 8.7.1 Check the Gearbox Oil Level Check the gearbox oil level every 50 hours. Use a good quality SAE 90 EP (ISO VG 320) gear oil in the gearbox. 1. Set the machine to a safe condition. For instructions, see Safe Condition on page 9.

  • Page 33: Drive Belt

    MX130P Service and Maintenance Manure Spreader 8.7.3 Adjust the Shift Cable 8.8 Drive Belt If the gearbox is not shifting gears correctly, the shift cable may require adjustment. WARNING! Machine shown with shields removed for illustrative purposes only. Never operate machine with shields removed.

  • Page 34: Beater-Bar Paddles

    For optimal performance, inspect the beater-bar paddles on a Recheck the drive belt tension after 10 hours of use. regular basis and replace paddles that are worn or damaged. Contact your Wallenstein dealer to purchase replacement paddles. 01462 Fig. 24 – Tensioning a Drive Belt 01467 1.

  • Page 35: Troubleshooting

    Wallenstein. Before you call, have The following table provides possible causes and solutions for the serial number for your manure spreader handy. For more some of the common problems you may encounter.

  • Page 36: Specifications

    MX130P Specifications Manure Spreader 10. Specifications 10.1 Machine Specifications Model MX130P 45–75 hp Recommended Tractor Size 34–56 kW Drive Type Beater Drive Belt drive / gearbox Apron Drive Chain and sprocket 130 bushels Capacity (Heaped) 162-1/2 ft³ 4.6 m³ 130" x 48" x 23"...

  • Page 37: Common Bolt Torque Values

    MX130P Specifications Manure Spreader 10.2 Common Bolt Torque Values Imperial Bolt Torque Specifi   cations Checking Bolt Torque Torque Value Bolt SAE Gr. 2 SAE Gr. 5 SAE Gr. 8 Unless otherwise indicated, tighten all bolts to the torque Diameter values that are specified in the following tables. Check the lbf•ft...

  • Page 38: Wheel Lug Nut Torque

    MX130P Specifications Manure Spreader 10.3 Wheel Lug Nut Torque Wheel Lug Nut Torque It is extremely important safety procedure to apply Wheel Units 1st Stage 2nd Stage 3rd Stage and maintain proper wheel mounting torque on your Size trailer axle. Torque wrenches are the best method to lbf•ft...

  • Page 39: Product Warranty

    Product Warranty Manure Spreader 11. Product Warranty LIMITED WARRANTY Wallenstein products are warranted to be free of defects in materials and workmanship under normal use and service, for a period of Five Years for Consumer Use Two Years for Commercial/Rental Use from the date of purchase, when operated and maintained in accordance with the opera�ng...

  • Page 40: Alphabetical Index

    MX130P Alphabetical Index Manure Spreader 12. Alphabetical Index Apron chain Gearbox Lubricate ................ 30 Maintenance ............27, 32 Maintenance ............27, 30 Oil change..............32 Shorten ................31 Oil level ................32 Tension ................30 Shift cable, adjustment ..........33 Apron drive Grease Points ..............
  • Page 41 MX130P Alphabetical Index Manure Spreader Optional equipment ............. 36 Spreading Instructions ..............24 Troubleshooting ............. 35 Standards ................10 PPE .................6, 13 Stopping ................22 Pre-operation checklist............22 Stopping in an Emergency ..........22 PTO ..................13 Storage................26 Controls ................. 20 Machine clean out............
  • Page 44 www.wallensteinequipment.com...
