- Page 1 SWIMMING POOL PUMP MODEL NO: SPP10A PART NO: 7175031 OPERATION & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS LS0520 - ISS 1...
- Page 2 The pump inlet is higher than the impeller inlet so that it can start operating when only the pump body is filled with water. Upon receipt, any damage or deficiency should be reported to your CLARKE dealer immediately. CONTENTS...
-
Page 3: General Safety Precautions
This will ensure the safety of the pump is maintained. The use of non standard parts could be hazardous. 13. Your CLARKE water pump has been designed to give long and trouble free service. If, however, having followed the instructions in this booklet carefully, you encounter problems, take the unit to your local CLARKE dealer. -
Page 4: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. If the plug has to be changed because it is not suitable for your socket, or because of damage, it must be removed and a replacement fitted, following the wiring instructions shown below. -
Page 5: Installation
Because of the variety of possible installations, no plumbing accessories are supplied with your pump, however accessories are available from your nearest CLARKE dealer. Contact your CLARKE dealer for further information, or CLARKE International Sales Department on 01992 565333. NOTE: It is recommended that the end user should consult a qualified installer if there are any doubts as to the suitability of this product for a particular installation. -
Page 6: Electrical Connection
ELECTRICAL CONNECTION The pump should be located at a safe distance, (usually 2 metres), away from the pool, and the power supply should be at least 3.5 metres from the pool. If in doubt, please contact your electrical specialist and refer to the International Electrical Commission (IEC) standard, (Electrical Installations for Buildings-part 7), referring to ‘swimming pools and other basins’. -
Page 7: Operation
If a leak is noticed at this point, it may indicate that the seal is worn and therefore in need of replacement. Contact your CLARKE dealer, or the CLARKE International Service Department for advice. 2. In the event of a blockage, where debris has entered the suction chamber, the sieve and chamber can be cleaned out as described under MAINTENANCE. -
Page 8: Maintenance
Remember to re-prime the pump when returning to service. In the event that dismantling and overhaul of the pump is necessary, contact your CLARKE International Service Department on 020-8988-7400 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 9: Environmental Recycling Policy
78 dB LwA Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 10: Troubleshooting
Release drain plug in impeller housing to release air. Damaged impeller Return to your CLARKE dealer for repair. If this does not solve your problem, please contact the CLARKE service department. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 11 PERFORMANCE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 12: Parts Diagram
PARTS DIAGRAM To order and spare parts shown above, quote the following: ZGSPP10A + the number of the part Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 13: Parts List
PARTS LIST Wrench Capacitor Pump cover nut 5x2.65 O-Ring Pump cover Retardant block Sieve/Basket Clamp wire cap 135x4.5 O-Ring M4x10 bolt Pump body Terminal box 66x4.7 O-Ring Gasket Water outlet connector Motor stator Locking washer Drain plug Spring washer 16x3.55 O-Ring M4x6 bolt Even washer Cord clip... -
Page 14: Declaration Of Conformity
DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 15 DECLARATION OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
