SN2290
ROUND HEAD FRAMING NAILER
OPERATION and MAINTENANCE MANUAL
BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY THIS
MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND
INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE
REFERENCE.
IF
YOU
HAVE
ANY
QUESTIONS,
CONTACT
YOUR
REPRESENTATIVE OR DISTRIBUTOR.

Advertisement

loading

Related Manuals for B&C Eagle SN2290

Summary of Contents for B&C Eagle SN2290

  • Page 1 SN2290 ROUND HEAD FRAMING NAILER OPERATION and MAINTENANCE MANUAL BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE. HAVE QUESTIONS, CONTACT YOUR REPRESENTATIVE OR DISTRIBUTOR.

  • Page 2: Table Of Contents

    INDEX Safety Instructions ..........3, 4 Air Supply: Fittings, Hoses, Filters, Air Consumption, Regulators, Operation Pressure, Setting Correct Pressure .

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS EYE PROTECTION which conforms to ANSI specifications and provides protection against flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and others in the work area when connecting to air supply, loading, operating or servicing this tool.
  • Page 4 AIR SUPPLY AND CONNECTION Do not use oxygen, combustible gases, or bottled gases as a power source for this tool as tool may explode, possibly causing injury or death. Do not use supply sources which can potentially exceed 200 P.S.I.G. as tool may burst, possibly causing injury.

  • Page 5: Air Supply: Fittings, Hoses, Filters, Air Consumption, Regulators, Operation Pressure, Setting Correct Pressure

    AIR SUPPLY AND CONNECTIONS Do not use oxygen, combustible gases, or bottled gases as a power source for this tool as tool may explode, possibly causing injury. Keep the tool pointed away from yourself and others when connecting air source. FITTINGS: Install a male plug on the tool which is free flowing and which will release air pressure from the tool when disconnected from the supply source.

  • Page 6: Production Specifications

    PRODUCT SPECIFICATIONS DRIVING POWER ..............1002 in.lbs FASTENER TYPE .

  • Page 7: Depth Adjustment

    DEPTH ADJUSTMENT Always disconnect air supply: 1. Before making adjustments; 2. When servicing the tool; 3. When clearing a jam; 4. When tool is not in use; 5. When moving to a different work area, as accidental actuation may occur, possibly causing injury. The depth adjustment feature provides close control of the fastener drive depth;...

  • Page 8: Loading The Tool

    LOADING TO PREVENT ACCIDENTAL INJURIES: • Never place a hand or any other part of the body in nail discharge area of tool while the air supply is connected. • Never point the tool at anyone else. • Never engage in horseplay. •...

  • Page 9: Tool Operation

    TOOL OPERATION EYE PROTECTION which conforms to ANSI specifications and provides protection against flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and others in the work area when connecting to air supply, loading, operating or servicing this tool.
  • Page 10 TOOL OPERATION CHECK Keep the tool away from yourself and others when connecting air source. CAUTION: Remove all fasteners from tool before performing tool operation check. To reduce the risk of injury to yourself and others, check the tool before beginning work each day or if the tool is dropped, received a sharp blow, been run over, etc.

  • Page 11: Maintaining The Pneumatic Tool

    MAINTAINING THE PNEUMATIC TOOL When working on air tools, note the warnings in this manual and use extra care evaluating problem tools. CAUTION: Pusher spring (constant force spring). Caution must be used when working with the spring assembly. The spring is wrapped around, but not attached to, a roller. If the spring is extended beyond its length, the end will come off the roller and the spring will roll up with a snap, with a chance of pinching your hand.

  • Page 12: Troubleshooting

    TROUBLE SHOOTING PROBLEM CAUSE CORRECTION Frame/nose leaks air Loose nose screws ....Tighten and recheck O-ring or Gasket is cut or cracked . . .Replace O-ring or gasket Bumper cracked/worn .
