US7116 LMAUTO
UPHOLSTERY STAPLED
OPERATION and MAINTENANCE MANUAL
BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY THIS
MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND
INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE
REFERENCE.
IF
YOU
HAVE
ANY
QUESTIONS,
CONTACT
YOUR
REPRESENTATIVE OR DISTRIBUTOR.
Advertisement
Related Manuals for B&C Eagle US7116 Lmauto
Summary of Contents for B&C Eagle US7116 Lmauto
- Page 1 US7116 LMAUTO UPHOLSTERY STAPLED OPERATION and MAINTENANCE MANUAL BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY THIS MANUAL TO UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THESE INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE. HAVE QUESTIONS, CONTACT YOUR...
-
Page 2: Table Of Contents
INDEX Safety Instructions ..........3, 4 Air Supply: Fittings, Hoses, Filters, Air Consumption, Regulators, Operation Pressure, Setting Correct Pressure . -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS EYE PROTECTION which conforms to ANSI specifications and provides protection against flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and others in the work area when connecting to air supply, loading, operating or servicing this tool. -
Page 4: Loading The Tool
AIR SUPPLY AND CONNECTION Do not use oxygen, combustible gases, or bottled gases as a power source for this tool as tool may explode, possibly causing injury or death. Do not use supply sources which can potentially exceed 200 P.S.I.G. as tool may burst, possibly causing injury. -
Page 5: Air Supply And Connections
AIR SUPPLY AND CONNECTIONS Do not use oxygen, combustible gases, or bottled gases as a power source for this tool as tool may explode, possibly causing injury. Keep the tool pointed away from yourself and others when connecting air source. FITTINGS: Install a male plug on the tool which is free flowing and which will release air pressure from the tool when disconnected from the supply source. - Page 6 PRODUCT SPECIFICATIONS DRIVING POWER .............. . 58 in.lbs FASTENER TYPE .
- Page 7 LOADING TO PREVENT ACCIDENTAL INJURIES: • Never place a hand or any other part of the body in nail discharge area of tool while the air supply is connected. • Never point the tool at anyone else. • Never engage in horseplay. •...
-
Page 8: Tool Operation
TOOL OPERATION EYE PROTECTION which conforms to ANSI specifications and provides protection against flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and others in the work area when connecting to air supply, loading, operating or servicing this tool. - Page 9 IN ADDITION TO THE OTHER WARNINGS CONTAINED IN THIS MANUAL OBSERVE THE FOLLOWING FOR SAFE OPERATION • Use the B&C Eagle pneumatic tool only for the purpose for which it was designed. • Never use this tool in a manner that could cause a fastener to be directed toward the user or others in the work area.
-
Page 10: Maintaining The Pneumatic Tool
MAINTAINING THE PNEUMATIC TOOL When working on air tools, note the warnings in this manual and use extra care evaluating problem tools. CAUTION: Pusher spring (constant force spring). Caution must be used when working with the spring assembly. The spring is wrapped around, but not attached to, a roller. If the spring is extended beyond its length, the end will come off the roller and the spring will roll up with a snap, with a chance of pinching your hand. -
Page 11: Troubleshooting
TROUBLE SHOOTING PROBLEM CAUSE CORRECTION Frame/nose leaks air Loose nose screws ....Tighten and recheck O-ring or Gasket is cut or cracked . . .Replace O-ring or gasket Bumper cracked/worn .
