- Page 1 USB-to-Serial Console Adapter USER MANUAL UC232B...
-
Page 2: Emc Information
EMC Information Federal Communication Commission Interference Statement: This equipment has been tested and found to comply with the limits for a Class B digital service, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Any changes or modifications made to this equipment may void the user’s authority to operate this equipment. - Page 3 Telephone Support International 886-2-8692-6959 China 86-400-810-0-810 Japan 81-3-5615-5811 Korea 82-2-467-6789 North America 1-888-999-ATEN ext 4988 1-949-428-1111 Technical Support For international online technical support – including troubleshooting, documentation, and software updates: http://eservice.aten.com For North American technical support: Email Support support@aten-usa.com...
-
Page 4: Package Contents
® Copyright © 2007-2020 ATEN International Co., Ltd. Printing Date: 2020-10-13 ATEN and the ATEN logo are trademarks of ATEN International Co., Ltd. All rights reserved. All other trademarks are the property of their respective owners. - 4 -... - Page 5 Overview The ATEN UC232B is a one port USB-to-Serial console adapter. This high quality industrial adapter cable is designed to instantly add single RS-232 console port connectivity for networking appliances via a USB port. The adapter is powered via the USB connection.
-
Page 6: System Requirements
Features USB 2.0 compliant Converts a USB port to RJ-45 (RS-232) Up to 921.6 Kbps data transfer rate with fast COM port transmission Connects your computer or table to a router, modem, or network switch for network connection. ... -
Page 7: How To Install
How to Install 1. Connect the USB plug for the UC232B to your computer’s USB port and wait for the drivers to automatically install the device.* Note: If you are using an older computer, you may need to visit our website to download the UC232B drivers and install them before setting up the hardware. -
Page 8: Specifications
Specifications Function Specification Connectors Type A Plug Male (White) Serial DB-9 Male (Silver) LEDs Power Status (Orange) Data Transfer Rate Up to 921.6 Kbps Cable Length 1.2 m Power Consumption DC5V, 0.202 W Power Mode Bus Powered USB Specification 2.0 Compliant Environment Operating Temp. - Page 9 Console/Aux Cable Mode UC232B RJ-45 Port Console/Aux Port (DTE) Signal Straight RJ-45 Pin Signal Type 1 Signal Type 2 Cable Pin Aten RS-232 Cable Mode UC232B RJ-45 Port Third Party RJ-45 to RS-232 Adapter Signal Rolled Cable RJ-45 Pin Signal DB-9 Out...
- Page 10 Thank you for purchasing this ATEN product! It is recommended that you register the product right away at our website: http://eservice.aten.com. This will give you access to useful add-on features, as follows: View details of all your registered ATEN products in one place ...
-
Page 11: Limited Warranty
What is covered by the Limited Hardware Warranty ATEN will provide a repair service, without charge, during the Warranty Period. If a product is detective, ATEN will, at its discretion, have the option to (1) repair said product with new or...
