User Manual
Home Automation CDP 1020ID
Thank you for purchasing COMMAX products.
• Thank you for purchasing COMMAX products.
Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
• Please carefully read this User's Guide (in particular, precautions for safety) before using a product and follow
instructions to use a product exactly.
instructions to use a product exactly.
The company is not responsible for any safety accidents caused by abnormal operation of the product.
• The company is not responsible for any safety accidents caused by abnormal operation of the product.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Commax CDP-1020ID
Summary of Contents for Commax CDP-1020ID
- Page 1 Home Automation CDP 1020ID Thank you for purchasing COMMAX products. • Thank you for purchasing COMMAX products. Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow • Please carefully read this User’s Guide (in particular, precautions for safety) before using a product and follow instructions to use a product exactly.
-
Page 2: Table Of Contents
19. Attention when in use ..................24 20. Miscellaneous....................24 21. Specifications ....................25 1. Greeting Thank you for purchasing a COMMAX product ● Please, use the product after carefully reading this Manual ● This type of videophone can be used in apartments, villas and other buildings as a ●... -
Page 3: Warnings And Caution
2. Warnings and caution Please follow the things described below in order to prevent any danger or property damage. Prohibition. Warning No disassembly It may cause a serious damage or injury if violated. No touch Caution Must follow strictly. Shows plugging out the power cord It may cause a minor damage or injury if violated. - Page 4 Warning If an abnormal sound, burning Please don’t disassemble, Please don’t insert any Please use only the designated smell or smoke is coming out metallic or burnable materials batteries for the products of repair or rebuild this product of the product, please plug out arbitrarily (please contact the into the ventilation hole.
-
Page 5: Parts And Functions
3. Parts and functions CDP-1020ID Part Part LCD & TOUCH SCREEN Guard button Speaker Door release button Talk button POWER LED Power switch Emergency button Wiring connector Monitoring button The product has hands-free conversation function : Please, press conversation button to initiate or end a call (Remark : When in stand by mode, only power button is on.) -
Page 6: Compositions
4. Compositions Monitor (CDP-1020ID) Wall bracket User manual GH1T 4X18 ZNW PHM 3 X 6 ZnY 3P(1EA) 4P(1EA) 2P(3EA) Screws for mounting Screws for main body Connectors Connectors Connectors 6P(2EA) 8P(1EA) 12P(1EA) Connectors Connectors Connectors Adaptor(DC14V) Power cord... -
Page 7: Main Menu
5. Main menu ① Door : Door camera monitoring and talk ② Guard : Guard station call and talk ③ Telephone : Telephone and extension/neighbor talk ④ EMS(Energy Management System) : Remote control(Secumax - remote metering and control) Device control(Lighting / Gas valve / Boiler) ⑤... -
Page 8: Household Setting (Household No./ Pin / Extension)
6. Household setting (household No./ PIN / extension) ※ It shows the following screen after pressing 「Setting 」 icon and 「Household」 in order. 1. Household No. setting It shows setting menu of building and room No. after pressing 「 House Num 」 icon ①... -
Page 9: Away Mode Setting
7. Away mode setting ※ It shows the following screen after pressing 「 Setting 」 icon and 「 Setting away mode 」 in order. ① You can activate each icon to be operating in away mode. (Devices and sensors should be installed before activating) - Security1(Burglar1) : Activating security 1 sensor in away mode - Security2(Burglar2): Activating security 2 sensor in away mode - All lights off : Activating all lights Off in away mode... -
Page 10: Individual Door Talk
8. Individual door talk ● How to use door monitoring/talk and basic function 1. Individual door monitoring and talk ① When you press 「 Door 」 icon, it shows door monitoring ② When you press 「 Talk 」 icon, it enables to talk ③... - Page 11 ● Display setting It shows Color, Contrast and Brightness after pressing 「 Display 」 icon while talking/monitoring. (You can make factory default(medium value) by pressing 「 Initial 」 ) ● Screen scrolling and zoom in & out 1. You can make screen zoom in & out by pressing while talking and monitoring 2.
-
Page 12: Guard Station Talk
9. Guard station talk ● How to use guard call and talk 1. Guard call ① When you press 「 Guard 」 icon, it executes calling and talking ② When you press 「 Talk end 」 icon, it ends talking 2. -
Page 13: Emergency Function
10. Emergency function ● How to activate emergency function It generates emergency when you press 'Emergency button more than 1 sec on the right upper side. (With emergency sound generating, guard station gets emergency signal from household ● How to release emergency function 「Release」icon shows up in case of pressing 「Guard」Button and 「Door release」... -
Page 14: Telephone Function(Telephone/Extension/Neighbor Talk)
11. Telephone function (Telephone/Extension/Neighbor talk) ※ It shows the following screen once you press 「 Telephone 」 icon ● How to register numbers and make a telephone call ① Calling : Press 「 Telephone 」 icon and conafter entering the numbers you want to call Press 「... -
Page 15: Volume Control(Receiving / Calling / Button Tone)
12. Volume control(Receiving / calling / button tone) ※ It shows the following screen once you press 「Volume 」 icon ● How to control volume 1 It shows control pad after pressing 「 Volume 」 icon 2 You can control volume through +, - of volume control from assigned icon Caution : It gives you no sound if you make minimum level for calling and beep sound ※... -
Page 16: Ems Function (Device Control)
13. EMS function (Device control) ※ Each device tab is shown automatically after product booting In case a device is not properly connected, it does not appear. (In order to make sure device checking, please make power on again. ※ If the device is set to "Away"mode, the integrated devices for all lights off, gas valve control and standby power control are activated. - Page 17 2) Gas control : Press 「EMS」 → 「Gas」 in order to move to control screen. ● Gas valve status screen Open / Close : It shows the status of the assigned valve ● Individual valve close You can make the available valve close by pressing the switch located below ●...
- Page 18 3) Boiler control : Press 「EMS」 → 「Boiler」 in order to move to control screen. ● Temp control status screen ① Operating condition : The display highlighted in green means ON and grey means OFF. ② The upper temperature display : It shows the current temperature of the room ③...
- Page 19 4) Remote control : Press 「EMS」 → 「Remote control」 in order to move to control screen. ● Remote metering You can check the real time based following date by pressing [Requesting remote metering data] ① Water : It shows Water usage ②...
-
Page 20: Detoured Call
14. Detoured call In case away mode is activated, all the calls from lobby and individual door detour and talk with guard station ● ※ receiving sound might be lower as the call routs through many paths 15. Delivery notice When guard station makes delivery call to household, 「... - Page 21 4) Security function (Burglar sensor) Security1 function (Security1 activates after setting up) ※ After pressing 「 Security1 」 icon while standby status, it makes 「 Security1 」 icon and its function are activated. Burglar alarm rings(Police car sound) and signal delivers to guard station when it gets movement.
-
Page 22: Wiring
Diagram CAMERA VIDEO 485-B 485+A SLAVE_PHONE CONV VIDEO OUT CONV LOBBY VIDEO IN VIDEO OUT LB_VD_CONT CONV 1 CONV 2 CDP-1020ID GUARD CONV 3 DATA ALARM 1(FIRE) DC12V(+) ALARM 2(GAS) SENSOR BURG 1 DC12V(+) BURG 2(PIR) SENSOR EMERGENCY_ALARM_BUTTON FIRE_LADDER DC14V(+) - Page 23 Installing SLAVE phones ① Enter the ID which is an assigned number of each Slave phone for classifying ID in circumstance of installing more than 2 units. Duplicate number is not acceptable ② The ID of Master monitor is '1' and you can assign '2' from following devices Assigned ID is also used as ID for inter - communication ▣...
-
Page 24: Operation Tips
18. Operation tips Troubles Cause Remedy Replace camera to the Due to backlight, aperture Blackened visitor’ image place where there is no is respond too brightly in clear background ● backlight Due to foreign substance on Remove foreign Blurry screen substance with rug the lens ●... -
Page 25: Attention When In Use
If you still can’t correct an operating problem, contact your dealer. If your dealer is ▣ unable to solve your problem, contact Commax Customer Service. Please don’t open the cabinet and attempt to repair the unit, as this will void your warranty. -
Page 26: Specifications
21. Specifications Content Item Telephone: 2 wires, Door camera: 4 wires, Fire ladder : 2 wires, Lobby: 4 wires in common, Guard station : 8 wires in common, SLAVE : 6 wires, Wiring Emergency switch : 2 wires, Sensor: 12 wires Power Source , 1.8A Communication... - Page 27 513-11, Sangdaewon-dong, Jungwon-gu, Seongnam-si, Gyeonggi-do, Korea Int’l Business Dept. Tel. : +82-31-7393-540~550 Fax. : +82-31-745-2133 Web site : www.commax.com Printed In Korea / 2016.09.104 PM011020ID10...
