OWNER'S MANUAL
TRINITY PRO 4-TIER NSF CORNER
WIRE SHELVING RACK
Model # TBFZ-0927 / TBFPBA-0927
Important / Important / Importante
FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS
Direct ives int elligent es
POUR DES DIRECTIVES D'ASSEMBLAGE 3D RAPIDES ET FACILES
Inst rucciones Int eligent es
PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D
DOWNLOAD THE FREE APP | TÉLÉCHARGER L'APPLICATION GRATUITE | DESCARGUE LA APLICACIÓN GRATUITA
Advertisement
Table of Contents
Related Manuals for TRINITY Pro TBFZ-0927
Summary of Contents for TRINITY Pro TBFZ-0927
- Page 1 OWNER’S MANUAL TRINITY PRO 4-TIER NSF CORNER WIRE SHELVING RACK Model # TBFZ-0927 / TBFPBA-0927 Important / Important / Importante FOR QUICK & EASY 3D ASSEMBLY INSTRUCTIONS Direct ives int elligent es POUR DES DIRECTIVES D’ASSEMBLAGE 3D RAPIDES ET FACILES Inst rucciones Int eligent es PARA INSTRUCCIONES DE ENSAMBLAJE RÁPIDAS Y SENCILLAS EN 3D...
-
Page 2: Parts List
PARTS LIST Your TRINITY PRO 4-Tier NSF Corner Wire Shelving Rack should include the following parts. Please inspect box contents to ensure you have received all components. If you are missing any parts, need assistance with assembly or have questions, please contact TRINITY Customer Service: 800.985.5506 or customerservice@trinityii.com. - Page 3 ASSEMBLY INSTRUCTIONS STEP 1 For easiest assembly, do not connect TOP POLES (C), MIDDLE POLES (B), and BOTTOM POLES (A) until A (5) E (10) instructed. Once connected, these will be posts for the Rack. Note that each POLE (A+B+C) has slight horizontal line indentations at 1”...
- Page 4 ASSEMBLY INSTRUCTIONS STEP 3 B (5) Screw MIDDLE POLE (B) into BOTTOM POLE (A). Repeat for each remaining MIDDLE POLE (B). STEP 4 On POLE (A+B), place 1 pair of SLIP SLEEVES (E) at desired height between SHELVES (D). Please make sure arrow E (10) D (1) faces up and word “TOP”...
- Page 5 ASSEMBLY INSTRUCTIONS STEP 5 Screw TOP POLE (C) into MIDDLE POLE (B). C (5) Repeat for each remaining TOP POLE (C). Note: Top of each TOP POLE (B) is indicated by a BLACK END CAP. STEP 6 On POLE (A+B+C), place 1 pair of SLIP SLEEVES (E) at desired height between SHELVES (D).
- Page 6 ASSEMBLY INSTRUCTIONS STEP 7 Feet Levelers are already screwed into BOTTOM POLES (A). Adjust as needed to ensure your shelving rack is level. © 2020 TRINITY - 800.985.5506...
-
Page 7: Service Parts List
SERVICE PARTS LIST – TBFZ-0927 Chrome Color TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-011-2543 Slip Sleeve XBK-98-010-2535 Feet Leveler ZSV-04-006-2475 Top Pole ZSV-04-043-2700 Bottom Pole ZSV-01-013-2523 Pole Connector XBK-23-004-2517 End Cap ZSV-04-007-2000... - Page 8 SERVICE PARTS LIST – TBFPBA-0927 Black Anthracite Color TRINITY Customer Service provides the following replacement parts: Part Number Description Part Number Description XBK-01-012-2543 Slip Sleeve XBK-98-010-2535 Feet Leveler PBA-04-006-2475 Top Pole PBA-04-043-2700 Bottom Pole ZSV-01-013-2523 Pole Connector XBK-23-004-2517 End Cap PBA-04-007-2000 Middle Pole PBA-03-041-2718...
-
Page 9: Care And Maintenance
CARE AND MAINTENANCE • Wipe with a dry cloth as needed to remove dust and dirt. • Avoid harsh, abrasive cleaners, and other corrosive chemicals. • The chrome color version (TBFZ-0927) is not recommended for outdoor use. © 2020 TRINITY - 800.985.5506... -
Page 10: Product Registration
PRODUCT REGISTRATION Thank you for purchasing a TRINITY PRO 4-Tier NSF Corner Wire Shelving Rack. In order to register your product and receive streamlined customer service, please fill out the following Product Registration Form and (1) fax the form to 310.347.4134 (2) complete the Product Registration Form online at www.trinityii.com or (3) scan and email the form to customerservice@trinityii.com. -
Page 11: Year Limited Warranty
Trinity International Industries (“Trinity”) warrants to the original consumer purchaser (“Purchaser”) of the TRINITY PRO 4-Tier NSF Corner Wire Shelving Rack (“Product”) that each Product shall be free from defects in workmanship and materials for a period of 1 year from the date of original purchase. Trinity’s obligation... - Page 12 CONTACT US QUESTIONS? NEED PARTS? WE ARE HERE TO HELP! Please feel free to contact us. There are no questions too small, or any problems too big. We’re committed to providing our customers with the highest level of service. TRINITY Customer Service TEL: 800.985.5506 FAX: 310.347.4134 EMAIL: customerservice@trinityii.com...
